- Page 1 USER MANUAL User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022...
- Page 2 1 metre (m) = 1000 millimetres (mm) = 1.09 yards (yd) = 39.37 inches (in) The following stylistic conventions are used throughout this document: Point of interest Safety hazard § Section reference (hyperlink in PDF edition) Simpro partcode (hyperlink in PDF edition) Errors in this document should be reported by email to info@simpro.world.
- Page 3 User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 2...
-
Page 4: Table Of Contents
C ont ent s Product Overview ....................... 5 Key Features .......................... 6 Construction .......................... 6 Mechanism ..........................6 Safe Working Load ........................ 6 Duty cycle ..........................6 Service life ..........................7 Noise emissions ........................7 Environmental restrictions ....................7 Ingress protection ......................... 7 1.10 Layout of Parts ........................ - Page 5 Identified Hazards ......................... 23 5.3.3 Residual Hazards ........................... 26 Spare Parts ........................27 Warranty ........................29 EC Declaration of Conformity .................. 31 Notes ........................... 33 User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 4...
-
Page 6: Product Overview
It can empty wheelie bins and carts weighing up to 65kg. Whole-of-life environmental impact was considered from the start of the Ezi-MT design process, to create a truly eco-friendly product. The unique single-mast design uses 50% less steel than competing products, and is shipped flat-packed to reduce carbon emissions from shipping. -
Page 7: Key Features
– simply place the bin into the cradle and lift. 1.2 Construction The Ezi-MT machine consists of a steel frame with one vertical mast, a bin cradle, sheet-metal guarding, one braked winch, one grab handle, bracing and four castor wheels. -
Page 8: Service Life
> 65kg 5,000 cycles 1.7 Noise emissions In normal conditions, the noise emissions of the Ezi-MT are assessed as not exceeding ~40 ’ . Hearing protection is not required. ISO standards for machinery safety specify that noise emissions are to be measured in A- weighted decibels (dB(A)), a unit of volume which is adjusted to reflect the sensitivity of human hearing. -
Page 9: Layout Of Parts
4. If the machine is to be leased, then this manual shall accompany the machine. 5. This is a generic manual. Simpro reserves the right to change the design of our products at any time without notification. In cases where the manual does not correspond with the actual product, use the manual as a reference guide only, and contact your authorized Simpro agent for assistance if required. -
Page 10: Operating Instructions
2 . O p e rat in g Instruct io n s 2.1 Before operation Before operating a Ezi-MT, check that the machine is stable and safe to use as follows: 1. Machine is on level ground, with a slope of 1:12 or less. -
Page 11: Type-E Cradle (Standard)
EN840 wheelie bins from leading brands such as Europlast, Sulo, ESE, Weber, Craemer, OnePlastics and Trident. 2.2.2.2 Removing bins Using the grab-handle provided, gently remove the wheelie bin from the cradle. User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 10... -
Page 12: Type-C Cradle
2.2.3 Type-C Cradle 2.2.3.1 Emplacing bins Place the wheelie bin into the machine, positioned centrally against the cradle backplate. Take care that the cradle teeth are properly engaged with the bin combing; smaller bins such as 60L and 80L ‘ ’... -
Page 13: Emptying Bins
2. Place the full bin on the cradle, taking care that it is correctly positioned as per §2.2. 3. Brace your body by holding the grab-handle on the Ezi-MT mast with your left hand. Use your right hand to turn the winch handle in a clockwise direction until the bin reaches the inverted position. -
Page 14: Safety Norms
2.4 Safety Norms The following safety norms must be observed for the safe use of an Ezi-MT bin lifter. Only trained and authorised personnel are permitted to use the machine. Operators must read and obey the instructions displayed on the machine. - Page 15 Always keep hands and feet well clear of the bin and cradle when operating. Never place limbs, feet or foreign objects under or through the guarding panels. User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 14...
-
Page 16: Care And Maintenance
Contact your Simpro agent if repair or service work is required. All repair and service work must be carried out by qualified personnel. Replacement parts must be supplied by Simpro or an authorized Simpro agent, and must be of the same design and specification as the original parts. -
Page 17: Cradle Jams
Strap 1000000424 Handle 0950040044 The Ezi-MT is fitted with a high-quality industrial braked winch and a black nylon lifting strap. The winch uses an internal reduction gear arrangement, allowing the user to lift heavy bins. The winch and lifting strap are suitable for outdoors use and require no regular maintenance. -
Page 18: Preventative Maintenance Inspections
It is recommended to conduct regular preventative maintenance inspections (PMIs) of the Ezi-MT. This helps to ensure operator safety and extend the service life of the machine. PMI procedures are described in the following pages, with logs for recording the results. -
Page 19: Monthly Inspection Log
3.5.2 Monthly inspection log Service Checks Notes on repairs or Parts and Date Location Person complete maintenance required materials used User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 18... -
Page 20: Assembly, Handling, Transport & Storage
The Ezi-MT is usually delivered fully assembled. 4.2 Moving When the Ezi-MT is standing upright it can be easily moved on its castor wheels, using the grab-handle provided. To ensure stability, the cradle should be positioned approximately 100mm off the ground when moving. -
Page 21: Storage
4. Use a bicycle lock to secure the machine against theft and vandalism. For maximum security, the chain should be passed through the welded grab handle on the front of the mast, and around the winch handle. User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 20... -
Page 22: Safety Assessment
The following section is not a comprehensive site-specific Hazard and Risk Assessment, but an assessment of the risk factors that are intrinsic to the Ezi-MT design. Blank template spaces are provided for additional site-specific hazards. -
Page 23: Iso 12100:2010 Risk Assessment Model
Once a Risk Factor has been calculated, the risk can be evaluated using the following table: Risk Factor 6-10 11-50 51-100 101-500 501-1000 1001 + Evaluation Negligible Very Low Significant High Very High Extreme Unacceptable User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 22... -
Page 24: Identified Hazards
5.3.2 Identified Hazards The following hazards have been identified that are intrinsic to the Ezi-MT design. For each hazard a full Risk Evaluation has been completed and control measures described. Blank template spaces are provided at the end for machinery owners to identify, assess and control additional site-specific hazards. - Page 25 Powder should only be tipped in calm conditions, or a wind shield should be installed. Toxic substances that cannot be protected against with PPE should not be Comments dumped using an Ezi-MT. Alternative methods should be used. Repetitive Strain Injury (RSI) caused by excessive winch operation DPH: Risk Factor:...
- Page 26 Site-specific hazard: DPH: Risk Factor: Operator DPH: Risk Factor: Other persons Control measures Comments Site-specific hazard: DPH: Risk Factor: Operator DPH: Risk Factor: Other persons Control measures Comments Site-specific hazard: DPH: Risk Factor: Operator DPH: Risk Factor: Other persons Control measures Comments Site-specific hazard:...
-
Page 27: Residual Hazards
Posting signage, floor marking, or other warnings as appropriate. Taking steps to develop a culture of safety-awareness and open communication within the workplace. User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 26... -
Page 28: Spare Parts
6. S pare Parts The following table includes only the most common Ezi-MT spare parts as at the time of publication. Additional parts, accessories and prices may be viewed at the following web address: simpro.world/ezi-mt-spare-parts. Ref. Partcode Description QTY* BSK**... - Page 29 User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 28...
-
Page 30: Warranty
The Agent shall keep accurate records of the date of all machine trials, sales. etc. Simpro will, at its option, repair or replace any items that fail or prove defective within the Warranty period. - Page 31 Parts requiring replacement will be supplied by Simpro free of charge; in some cases, it may be necessary to source Parts locally if needed urgently, but Simpro must authorize this if the cost of the item exceeds $50.00 and is to be charged to Simpro.
-
Page 32: Ec Declaration Of Conformity
8 . E C D ec l arat io n of C onf o rm it y DECLARATION OF CONFORMITY ORIGINAL Business Name and Full Address of Manufacturer Simpro Handling Equipment Ltd 66 Rangi Road, Takanini 2105 Auckland, New Zealand Name and Address of Authorised Representative... - Page 33 User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 32...
-
Page 34: Notes
9. N ote s... - Page 35 User Manual // Simpro Ezi-MT Original Instructions // English // v40.0 // October 2022 // Page 34...
- Page 36 +64 9 634 7445 Takanini 2105 sales@simpro.world Auckland, New Zealand shop.simpro.world PO Box 74 @simpro.world Takanini 2245 Auckland, New Zealand @SimproWorld_Lifters User Manual // Simpro Ezi-MT Original Version // English // v40.0 // October 2022 // © 2022 Simpro Handling Equipment Ltd...
