WARNING
!
INSTALLATION AND OPERATION MANUAL
3,500 / 5,000 POUND CAPACITY
QUICKJACK
MODELS:
BL-3500
VER B
BL-5000
VER B
RECEIVING
The shipment should be thoroughly inspected as soon as it
is received. The signed Bill of Lading is acknowledgement
by the shipping carrier as receipt of this product as listed
in your invoice as being in a good condition of shipment. If
any of these goods listed on this Bill of Lading are missing
or damaged, do not accept goods until the shipping carrier
makes a notation on the freight bill of the missing or dam-
aged goods. Do this for your own protection.
QUICKJACK
PATENTED. ALL RIGHTS RESERVED
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION
INSTALLATION AND OPERATION YOU AGREE THAT YOU FULLY
UNDERSTAND AND
MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
By Ranger Products
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
AND
OPERATION.
COMPREHEND THE FULL CONTENTS OF THIS
BE SAFE
Your new jack was designed and built with safety in mind.
However, your overall safety can be increased with proper
training and thoughtful operation on the part of the operator.
DO NOT operate or repair this equipment without reading
this manual and the important safety instructions shown
inside. Keep this operation manual near the jack at all
times. Make sure that ALL USERS read and understand
this manual.
™
1
BY
PROCEEDING
MAN REV B 11-28-14
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-888-262-3880
Tel: 1-805-421-5114
www.quickjack.com
WITH
JACK
P/N 5900395

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUICKJACK BL-3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Ranger Products QUICKJACK BL-3500

Summary of Contents for Ranger Products QUICKJACK BL-3500

  • Page 1 Make sure that ALL USERS read and understand aged goods. Do this for your own protection. this manual. QUICKJACK ™ 1645 Lemonwood Dr. Santa Paula, CA. 93060, USA Toll Free 1-888-262-3880 By Ranger Products Tel: 1-805-421-5114 www.quickjack.com PATENTED. ALL RIGHTS RESERVED...

  • Page 2: Product Warranty

    Our comprehensive product warranty means more than a commitment to you; it’s also a commitment to the value of your new Ranger Product. For full warranty details and to register your new jack contact your nearest Ranger Products dealer or visit: www.quickjack.com...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Product Warranty ..................2 Specifications .

  • Page 4: Definitions Of Hazard Levels

    properly supervised. IMPORTANT NOTICE Allow unit operation only with all parts in place and Stay clear of any moving parts that can fall and cause injury. operating safely. These instructions must be followed to insure proper instal- Carefully inspect the unit on a regular basis and lation and operation of your jack.

  • Page 5: Important Safety Instructions

    QUICKJACK ™ SAFETY INSTRUCTIONS By Ranger Products IMPORTANT SAFETY INSTRUCTIONS Read these safety instructions entirely. Do not attempt to install this QuickJack if you have never been trained on basic vehicle jack installation procedures. Never attempt to lift components without proper lifting tools such as forklifts or cranes.

  • Page 6: Parts Inventory / Specifications

    PARTS INVENTORY Be sure to take a complete inventory of parts prior to beginning installation. Description Frame Assemblies Power Unit with Carrier Quick Connect Twin Hose Assembly Quick Connect Hoses Rubber Lift Blocks Frame Handles Parts Box (Packing List Enclosed) Power Unit with Twin Hose Assembly Frame...

  • Page 7: Tools Required / Getting Started

    TOOLS REQUIRED Open-End Wrench Set: SAE/Metric Phillips Screwdriver Socket And Ratchet Set: SAE/Metric Wrench sizes: 7/16”, 3/8”, 5/8”, 11/16” and 3/4” IMPORTANT NOTICE THESE INSTRUCTIONS MUST BE FOLLOWED TO ENSURE PROPER INSTALLATION AND OPERATION OF YOUR JACK. FAILURE TO COMPLY WITH THESE INSTRUCTIONS CAN RESULT IN SERIOUS BODILY HARM AND VOID PRODUCT WARRANTY.

  • Page 8: Installing Cylinder Fittings (Cont'd) / Installing Inflation Valves

    2. Install the 90º O-ring fittings and position the fittings at 2. Wrap the threads on the two air inflation valves with 10 o’clock. Teflon™ tape. When applying tape, wrap it three times in direction shown below. 3. Using a wrench, secure the fitting nut. 3.

  • Page 9: Pressurizing Air Bottle Cylinders / Power Unit Assembly

    STEP 6 Pressurizing Air Bottle Cylinders 1. IMPORTANT: Make sure lift frames are in the fully lowered position during the following procedures. 2. Remove dust cap from each air inflation valve. 6. Replace dust caps. The dust cap on each inflation valve helps to retain air.

  • Page 10: Power Unit Assembly (Cont'd)

    2. Remove protective shipping plugs from both power Install male quick-connect fitting to lower unit ports. double-male fitting. 3. Locate both double-male O-ring fittings, then wrap Securely tighten fitting. Teflon tape on pipe threads only - NOT O-RING SIDE. 4. Place one double-male O-ring fitting in the lower 8.

  • Page 11: Filling Power Unit Reservoir / Preparing Hoses

    STEP 8 STEP 9 Filling Power Unit Reservoir Preparing Hoses DURING THE START-UP PROCEDURE OBSERVE ALL OPERATING COMPONENTS AND CHECK FOR READ THE FOLLOWING PROCEDURES BEFORE PROPER INSTALLATION AND ADJUSTMENT. DO NOT ATTEMPTING TO CONNECT HOSES TO QUICKJACK ATTEMPT TO RAISE A LOAD UNTIL A THORUGH OP- AND POWER UNIT.
  • Page 12 4. Securely tighten female fitting as shown below. 8. Locate the two remaining male quick-connect fittings and attach to Short Leader Hoses as shown below. 5. Repeat same procedure for ALL four hose ends, as shown in the image below. 9.

  • Page 13: Jack Preparation

    STEP 10 Jack Preparation 1. Place both QuickJack frames on a stable floor VISUALLY CHECK QUICK-CONNECT FITTINGS FOR surface with both lock bars positioned outwards as CORRODING, CRACKING, DAMAGE OR illustrated below. EXCESSIVE WEAR. IF ANY OF THESE CONDITIONS EXIST, THE QUICK-CONNECT FITTINGS MUST BE REPLACED.

  • Page 14: Bleeding The Cylinders

    7. Make sure the power unit oil reservoir is full with 11. Cycle the jack up and down a few times to 2 quarts of automatic transmission fluid approximately half the lifting height, ensuring proper operation. 12. Engage safety bars and lower jack onto safeties by depressing the DOWN button.

  • Page 15: Bleeding The Cylinders (Cont'd) / Operation And Use

    2. Filling: Press the UP button on the power unit pendant Quick Frame Handles are easily installed by simply lifting control to slowly fill the hydraulic cylinders with oil; air and the jack frames and placing the end channel underneath the frame tubes as shown below.

  • Page 16: Typical Jacking Points / To Raise Jack Frames

    2. With vehicle in ready position, place each jack frame under the vehicle making sure to position the Rubber Lift Blocks at the factory recommended jacking points. Ensure vehicle is positioned with the center-of-balance placed midway on the jack frames. IF THE SPECIFIC VEHICLE LIFT POINTS ARE NOT IDENTIFIED OR IF THE VEHICLE HAS ADDITIONAL OR UNIQUELY POSITIONED PAYLOAD, HAVE A...
  • Page 17 ALWAYS MAKE SURE QUICKJACK FRAMES ARE PARALLEL WITHIN 2” AND ALIGNED EVENLY FRONT AND BACK AS SHOWN IN THE DIAGRAM. FAILURE TO DO SO COULD CAUSE QUICKJACK FRAMES TO BECOME UNSTABLE AND NOT REST SQUARELY ON FLOOR SURFACE. MUST BE PARALLEL WITHIN 2”...

  • Page 18: To Raise Jack Frames (Cont'd) / To Lower Jack Frames

    3. Operate the UP control until each jack platform makes contact with vehicle undercarriage. Check contact points. If required, slightly position Rubber Lift Blocks as needed. 4. When ready, raise vehicle keeping the UP button safety lock position has been reached. ALWAYS MAKE SURE THE SAFETIES ARE ENGAGED BEFORE ATTEMPTING TO WORK ON OR NEAR A VEHICLE.
  • Page 19 Important Operating Instructions QUICKJACK CANNOT BE RESPONSIBLE FOR DAMAGE OR INJURY RESULTING FROM, LACK OF MAINTENANCE OR UNSAFE USE OF THIS PRODUCT. READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE. FAILURE TO READ AND UNDERSTAND THE FOLLOWING WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE.

  • Page 20: Important Operating / Maintenance Instructions

    ALWAYS make sure lift frames are parallel within 2” and aligned evenly front and back. Failure to do so could cause lift frames to become unstable and not rest squarely on floor surface. DO NOT leave the controls while the jack is still in motion. DO NOT stand directly in front of the vehicle or in the bay when vehicle is being loaded into position.
  • Page 28 Every effort has been taken to ensure complete and accurate instructions have been included in this manual, however, possible product updates, revisions and or changes may have occurred since this printing. Quickjack™ reserves the QUICKJACK ™ By Ranger Products P/N 5900395...
