Cleveland CA1-E Specification Sheet

™
Cleveland
STEAMCRAFT
HIGH SPEED CONVECTION STEAMERS
Pronto Plus
COUNTER TYPE DESIGN
PRESSURELESS CONVECTION STEAMER
ELECTRIC STEAM GENERATOR, 8 KW
Cleveland Standard Features
I
DESIGN TYPE: Pressureless à la carte natural convection
steamer.
I
OPERATION: Electrically operated self-contained steam gen-
erator, with standby thermostat to hold water just below the
boil-ready to provide steam when called for.
I
CONTROLS: Mounted on a removable front panel. Controls
include an illuminated power switch, a cook switch with pilot
light and a 0 to 60 minute timer.
I
PERFORMANCE FEATURES:
AUTOMATICALLY CONTROLLED – Power switch automati-
cally supplies water to the generator and maintains unit on
standby. An electric low water cut-off protects the element
from burn out. Cook switch activates the pilot light and timer.
The electrical timer activates the steam generator when cook-
ing time is set. Switching the power off will automatically initi-
ate a generator blowdown sequence.
STEADY STEAM WATER CONTROL SYSTEM – This visual
control system automatically meters water to retain a steady
operating level, providing constant steam even while genera-
tor is refilling. Elements are activated only when the generator
is properly filled. Located at the front of the generator, this
exclusive visual control system combines a sight gauge, low
water cut-off and operating water level control. System is iso-
lated for easy cleaning and maintenance.
I
CONSTRUCTION: Cabinet is polished stainless steel con-
struction, with removable side and front panel for access to
internal components for service ease. Cooking compartments
are polished stainless steel welded construction with steam
entry and drainage ports. Fully-insulated and self-contained
with 8.0 KW electric element that provides ample steam for
full loads, which can be replaced without removing generator.
The structural design of the cabinet allows the cookers to be
stacked. Adjustable door handle and hinge assembly is made
of heavy gauge stainless steel. Door is insulated and provided
with a one-piece silicone replaceable gasket. Each grip han-
dle and latch provides positive latch and seal when door is
pushed or slammed shut. Pan support wire racks are stain-
less steel and have removable drip tray to collect condensate
from door.
I
FINISH: Polished stainless steel cooking compartment, exte-
rior front and sides, top and back. Control panel is durable
porcelain enamel. Legs - sanitary adjustable 4˝ / 102 mm
high, black high-impact plastic. NOTE: Legs may be removed
if unit is to be mounted directly on counter or sealed.
I
APPROVALS: Steamer is U.L., CSA. and N.S.F. approved
and listed. Unit is designed and constructed to meet N.S.F.
and known Health Department and Safety Standards or
codes.
I
APPLICATIONS: Vegetables (fresh and frozen), pasta, rice,
eggs, seafood, meat, poultry and potatoes. Reheat frozen or
refrigerated entrees or convenience foods.
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
® GENERATOR STYLE
Tel: 1-216-481-4900
Fax: 1-216-481-3782
MODEL: CA1-E
Options & Accessories
Ë Door - Left hand opening, specify
Ë Open Stands
Model PPSS -
Stainless Steel No.4 finish with shelf.
Legs - 2"/51mm square tubing
Bottom Shelf-Fixed.
Feet - Adjustable Stainless Steel
Web Site: www.ClevelandRange.com
Email: Steam@ClevelandRange.com
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
IV
SECT. PAGE
0707
3
