Trane A801X026AM2SAC Service Facts

Upflow/downflow/horizontal left/right gas-fired, single stage induced draft furnaces with high efficiency motor
Hide thumbs Also See for A801X026AM2SAC:

Advertisement

Quick Links

Download this manual
Service Facts
Upflow/Downflow/Horizontal Left/Right
Gas-Fired, Single Stage Induced Draft Furnaces
with High Efficiency Motor
U U p p f f l l o o w w , , D D o o w w n n f f l l o o w w , , H H o o r r i i z z o o n n t t a a l l R R i i g g h h t t / / L L e e f f t t
Single Stage
A801X026AM2SAC
A801X040AM3SAC
A801X040BM2SAC
A801X060BM3SAC
A801X060BM4SAC
A801X080BM4SAC
A801X080CM5SAC
A801X100CM5SAC
A801X120DM5SAC
N N o o t t e e : : Models may have a "T" in the 12th digit designating they meet
California less than 40 ng/J (NOx) emissions requirements.
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
March 2020
N N o o t t e e : : Graphics in this document are for
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
A A 8 8 0 0 1 1 X X - - S S F F - - 1 1 C C - - E E N N
representation only. Actual model may
differ in appearance.
