INDEX
02 ..........
03 ..........

Front Panel

04 ..........
04 ..........
04 ..........
05 ..........
Connetion Example
06 ..........
07 ..........
08 ..........

Warranty

TECHNICAL SPECIFICATION
Operation topology: Full range class D
12db/octave variable active Linkwitz-Riley crossover: 30Hz - 8kHz
Input impedance: 47k ohms
Frequency response: 18Hz - 8kHz (-3dB)
Variable subsonic filter: 18Hz - 120Hz
Fuse: MIDIVAL 60A (x 6) + GLASS 0.5A
Clip indicator
THD < 0.3%
SNR > 82.4dB
Damping factor > 100
Input sensitivity: 200mV – 1 V
Differential input signal
Cooling fans
Dimensions: 29.6"L x 2.5"H x 10.1"W
Weight: 29.8lb
These values are typical and may present some minor variation.
TECHNICAL SPECIFICATION
Output:
1 channel 10.000Wrms 1ohm - 12.6Vdc
1 channel6.000Wrms 2ohms - 12.6Vdc
1 channel 13.000Wrms 1ohm - 14.4Vdc
Current draw at full power(average music program): 476A*
*Equivalant to current draw with resistive load and sinusoidal signal at half power.
Front panel view
1.
Blue LED:
On
2.
Red LED:
Blinking - Output distorted (Clip) / Constant - Output short circuit
3.
Yellow LED: Fblinking - Low voltage battery / Constant - Fuse blown or missing)
4.
Gain Control
on
Clip
short
LOW Batt
fuse
1
2
3
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Viking 10000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Banda Audioparts Viking 10000

  • Page 1 TECHNICAL SPECIFICATION INDEX Output: 02 ..Technical Specification 03 ..Front Panel 1 channel 10.000Wrms 1ohm - 12.6Vdc 04 ..Power Supply, Signal Input and Power Output Sections 1 channel6.000Wrms 2ohms - 12.6Vdc 04 ..Clip Indicator 04 ..Subsonic and Crossover Controls 1 channel 13.000Wrms 1ohm - 14.4Vdc 05 ..
  • Page 2 CONNECTION EXAMPLES TECHNICAL SPECIFICATION Power supply section 1. Negative power input (ground): connect to car chassis. 2. Protection fuse: • . 3. Remote input: connect to radio/cd remote output. 4. Positive power input (+12Vdc): connect to baterry positive terminal. Signal input and power output section. 4+4ohms 5000Wrms subwoofer x 2 wired in parallel Positive speaker output Signal input (RCA)
