Wisenet TMC-GSFP Series Installation And Operation Manual

INSTALLATION AND OPERATION MANUAL
This manual serves the following

Model Names:

TMC-GSFPM
TMC-GSFP
TMC-GSFPPOEM
TMC-GSFP Series
10/100/1000MBPS ETHERNET MEDIA CONVERTERS
WITH 100FX AND 1000FX SUPPORT
The TMC-GSFP electrical-to-optical Ethernet media converters accept a 10/100
or 1000 Mbps electrical input and converts this to a 100 or 1000 Mbps optical
output (selected by a dip switch) and the 100/1000 Mbps optical input back to the
10/100/1000 Mbps electrical output. "Auto-Negotiating" is supported on the copper
interface side. These devices use either one or two optical fibers, depending upon
the selection of sold-separately SFP optical modules.
A PoE model, the TMC-GSFPPOEM meets the IEEE802.3af/IEE802.3at standard and
provides up to 30 watts of PoE+ power. The series also consists of a small size
single channel model, TMC-GSFPM, and a standard size, single-channel model,
TMC-GSFP. The standard size unit may be directly plugged into the SBP-C14 /
SBP-C03 Rack or operated as a standalone module. The small size unit operates as
standalone modules only.
TMC-GSFP SERIES
INS_TMC-GSFP[POE][M] 08/12/19 PAGE 1
