- Page 1 NETWORK VIDEO ENCODER Quick Guide SPE-110...
- Page 2 English WHAT’S INCLUDED As for each sales country, accessories are not the same. Network Video Encoder Quick Guide (Optional) Warranty card (Optional) Tapping screw Small machine screw Bracket 4-pin Terminal Block 2-pin Terminal Block...
- Page 3 CONNECTING WITH OTHER DEVICE * For details, refer to the “Installation and Connection” section of the manual. VIDEO IN RESET Camera DC 12V NETWORK / PoE Power Ethernet See the table below to connect your encoder to SSM. For more details, see “Setting up the system” in the manual. SSM 2.0 lower SSM 2.1 higher Device type...
- Page 4 NETWORK WIRING DIAGRAM ENCODER INTERNET ENCODER PPPoE or PPPoE or Broadband Cable Modem Cable Modem Router External Remote PC DDNS Server (Data Center, KOREA) Local PC MANUAL NETWORK SETUP Run <IP Installer_v2.XX.exe> to display the encoder search list. At the initial startup, both [Auto Set] and [Manual Set] will be grayed out. For encoders found with the IPv6 setting, these buttons will be grayed out as the encoders do not support this function.
- Page 5 c In the <Address> pane, provide the necessary information. d In the <Port> pane, provide necessary information. • HTTP Port : Used to access the encoder using the Internet browser, defaulted to 80. • VNP Port : Used to control the video signal transfer, defaulted to 4520. e Enter the password.
- Page 6 PASSWORD SETTING When you access the product for the first time, you must register the login password. When the “Password change” window appears, enter the new password. For a new password with 8 to 9 digits, you must use at least 3 of the following: uppercase/ lowercase letters, numbers and special characters.
- Page 7 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive. Correct Disposal of This Product (Waste Electrical &...
- Page 8 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 http://hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free : +1.877.213.1222 Direct : +1.201.325.6920 Fax : +1.201.373.0124 www.hanwhasecurity.com Hanwha Techwin Europe...
