AB5000™ System Installation / Preventative Maintenance Procedure
All service and maintenance, which involves disassembly of the AB5000
trained and certified service personnel. Replacement parts obtained from sources other than ABIOMED/IMPELLA
must not be used. Possible Electrostatic discharge precautions must be observed. Prior to servicing, check with
ABIOMED/IMPELLA technical support (USA 800-422-8666) (EUROPE +49-241 8860301) for available FCN
releases and Service Manual updates.
Item
Angled mirror
Lint free swab with 6" plastic handle
Hydraulic Load Simulator
Digital Voltmeter
Laptop Computer
Diagnostic Download Cable
Pump ID Connector
Pressure/Vacuum Gauge
Safety Analyzer (EUROPE ONLY)
[ ] 1. DECONTAMINATION
Prior to servicing, the AB5000
should be considered contaminated and universal safety precautions are to be taken. Gloves, masks, eye
protection, and protective garments are to be worn as required in the handling and decontamination of the
Console.
[ ] 2. UNCRATING
Uncrate the Console and Cart. Place the Hand Pump into the mounting bracket as required.
[ ] 3. EXTERNAL INSPECTION
Perform a thorough exterior inspection of the Console and Cart. Inspect for:
Turret rotation, panel damage, mechanical damage and any loose hardware.
[ ]
[ ] 4. INTERNAL INSPECTION
Remove Console from Cart. Remove the Console panels. Perform a thorough interior visual inspection.
(Inspect fittings, tubings, quick-connect tubing (insertion depth), cable connections, hardware).
Perform a general inspection of the compressor subassemblies, including but not restricted to,
[ ]
black debris in the rear bearing, tubing wear, mesh wear and electrical connections as per procedure
0015-7007.
[ ] 5. PERFORM REQUIRED FIELD CHANGES (FCNS) – CONTACT ABIOMED FOR CURRENT FCN
STATUS
ABIOMED, Inc. Proprietary and Confidential
AB5000™ System Console
AB5000™ AB Cart OR
iPulse Cart
Hand Pump
Time Meter
Date
Tested By
REQUIRED EQUIPMENT
Specification (or ABIOMED P/N for Specialized
Tools)
Miltex Mirror P/N 67-696/3 and Mirror Handle P/N 011-
26641 or equivalent
Abiomed PN 7000-0030 (Lint free swab with 6" plastic
handle) or equivalent
ABIOMED/IMPELLA P/N 0005-0070
Fluke 77 or Equivalent
Running Windows 2000 or Later, Serial Port
ABIOMED/IMPELLA P/N 0015-9612
ABIOMED/IMPELLA P/N 0055-0737
-200mmHg to +500mmHg min (Damping set to 1 sec.)
IEC601-1 Tester
TM
Console must be decontaminated. Unless otherwise known, the Console
S/N
S/N
S/N
Hrs.
TM
Console, must be performed by factory
0015-7309, RevH
Page 1 of 8
SOP-QA1000-T2, Rev. B
