iGen LSW-5 Quick Manual

Quick Guide for Stick Logger (WiFi)
Product Model: LSW-5
Notice:
Please read this manual carefully before using products and keep it in the place where O&M
providers can easily find.
Due to product upgrade and other factors,the content of this manual might change from time to
time.Please take actual product as standard and get latest manual from www.solarmanpv.com
or sales. Unless otherwise agreed herein,this manual will only be used as guidance.Any
statement,information or suggestion in this manual will not take any form of responsibility.
Without written permission,any content of this document(partly or entirely)cannot be extracted,
copied or transmitted in any form by any company or individual.
Warning:
1.Please power off during the installation.
1.Logger Installation
Interface 1
Fix inverter and logger with the screws. Please refer to the installation steps for
DB9 interface.
Fix logger to inverter com interface according the diagram.
Interface 2
Fix inverter and logger with aeronautical head.
Install the logger according to guide slot.
Tighten the cap in a clockwise direction.
Interface 3
Fix inverter and logger with USB head.
Install the logger according to guide slot.
Tighten the cap in a clockwise direction.
2.LED Indicator Lights Instruction
Light Implication
Communicate with router
Communicate with inverter
Logger running status
The normal operation status after the stick logger powered on:
1、Successful connection with the server: NET light keeps on after the stick logger powered on.
2、Normal operation: READY light flashes.
3、Successful connection with the inverter: COM light keeps on.
3.Abnormal Status Processing
If the data on platform is abnormal when the stick logger is running, please check the table below and according to
the status of indicator lights to complete a simple troubleshooting. If it still can not be resolved or indicator lights
status do not show in the table below, please contact our Customer Support.
(Note: Please using the following table query after power-on for 2mins.)
NET COM READY
Fault Description
Communicate
Any
Slow
with inverter
OFF
status
flash
abnormal
Communicate
Slow
OFF with router
ON
flash
abnormal
Connection to
Slow Slow
router normally,
ON
flash flash connection to
server abnormally
Power supply
OFF OFF
OFF
abnormal
Bluetooth
Any
Fast Any
network
status
flash status
distribution
Any Any Fast
Restore factory
status status flash
setting
Warning: Please make sure the stick logger is working properly
before you leave the site. If there is anything abnormal, please
do not leave the site and contact customer service at the first time.
Customer service number: 400-181-0512
If you have any technical queries about our products, please contact
us and provide the following information:
1. Product model and serial number of stick logger.
2. Product model and serial number of connected inverter.
Thank you for your support and cooperation!
4.Monitoring Platform
1.Download
If you are an end-user, it is recommended to use SOLARMAN Smart. Scan the QR
code below to download the APP or go to Android Market/App Store and search
"SOLARMAN Smart"to download.
Web entrance: https;//home.solarmanpv.com
Quick Guide
Instruction
1.Light off: Connection to the router failed.
2.On 1s/Off 1s (Slow flash): Connection to the router succeeded.
3.Light on: Connection to the server succeeded.
On 100ms/Off 100ms (Fast flash): Quick network distribution.
1.Light on: Logger connected to the inverter.
2.Light off: Connection to the inverter failed.
On 1s/Off 1s (Slow flash): Communicating with inverter.
1. Light off: Logger runs abnormally.
2.On 1s/Off 1s (Slow flash): Logger runs normally.
3.On 100ms/Off 100ms (Fast flash): Restore factory setting.
Fault Cause
1.Connection between stick
1.Check the connection between stick
logger and inverter loosen.
logger and inverter. Remove the stick
2.Inverter does not match
logger and install again.
with stick logger's
2.Check inverter's communication rate
communication rate.
to see if it matches with stick logger's.
1.Stick logger does not have 1.Check if the wireless network
a network. configured.
2.WiFi signal strength weak 2.Enhance WiFi signal strength.
1.Router network abnormal.
1.Check if the router has network.
2.Server point has been
2.Check router settings.
modified.
3.Contact Customer Service.
3.Network limited.
1.Connection between stick
1.Check the connection, remove the
logger and inverter loosen or
stick logger and install again.
abnormal.
2.Check inverter output power.
2.Inverter power insufficient.
3.Contact Customer Service.
3.Stick Logger abnormal.
1.Exit after 5min.
Normal
2.5s long press for rebooting.
3.10s long press for restoring.
1.Exit after 1min.
Normal
2.5s long press for rebooting.
3.10s long press for restoring.
SOLARMAN Smart
Solution
