Revision History Version Revision History Date Ver. 1.0 HW reference design, primary Aug. 2018 Ver. 1.1 Change the symbol of V_BCKP from button Aug. 2019 battery to power TXD connects 1K resistance in series R1.2 Update Copyright time Apr.
Page 3
UM220-IV M0 Hardware Reference Design Contens Minimum System Reference Circuit ..................1 Reference Circuit Using a Passive Antenna ................2 Attachment ..........................5...
Page 4
1. Minimum System Reference Circuit Supply 2.8V~3.6V power VCC Ground all GND pins of the module Connect RF_IN signal to antenna, note the 50 Ω impedance match on the circuit 100nF 100pF TIMEPULSE 100nF VCC_RF 68nH VBCKP V_BCKP VCC_IO RF_IN...
Page 5
UM220-IV M0 Hardware Reference Design 2. Reference Circuit Using a Passive Antenna To ensure the system performance, low noise amplifier and filter should be added between the passive antenna and the module RF_IN The VCC_RF output of the module is recommended for power supply with LNA ...
Page 6
3. Attachment Here are two options to avoid module startup abnormality caused by string power. Option 1 No external pull-up resistor is allowed to connect with the output pin TXD; Option 2 When the module is not powered on, make sure the IO port connected to the module is in high resistance state or low level to avoid string power.
