List Of Spare Parts - Compact Radial Engines MZ201 Instruction And Maintenance Manual

Fig. n?
1 Cranckshaft
2
Woodruff key
3
Bearing
4 Bearing
5 Cranckcase
6
Centering pins
7 Screw
8
Safety spring washer
9 Screw
10 Oil seal
11
Oil seal
12
Stud bolt
13 Fair-lead
14
Neadle cage
15 Piston pin
16 Piston
17
Piston pin retainer
18 Piston ring
19
Cylinder gasket
20
Cylinder
21 Nut
22 Washer
23
Cylinder head gasket
24 Cylinder head
25
Screw
26 Washer
27 Radial connection
28
Screw
29
Stator
30 Screw
31
Rotor
32 Ring gear with rubber joint
33 Screw
34
Spring washer
35 Self locking nut
36
Adapter
37
Rolling screw
38 Drum
39 Recoil starter small type
40
Drum
41 Recoil starter big type
42
Electric starter
43 Bendix
44 Nozzle
45
Braket
46
Self locking nut
47 Safety spring washer
48
Electronic ignition coil
49 Screw
50 Insulated faston
Designation Part number Quan.
3410003 1
UNI6606-3x3,7 1
6205JC3 1
6005JC3 1
3410001 1+1
3410007 2
UNI5931-6x50 2
3410008 29
UNI5931-6x45 6
3410024 1
3410031 1
3410012 4
3410076 1
3410004 1
3410005 1
3410025 1
3410006 2
3410026 2
3410021 1
3410013 1
3410019 7
UNI6592-8x16 5
3410014 1
3410015 1
UNI5931-6x35 9
UNI6592-6x12 31
3410041 1
UNI9327-6x20 11
3410052 1
UNI5931-6x25 4
3410049 1
3410028 1
UNI5931-6x10 6
UNI8840-10 2
3410062 2
3410047 1
UNI8110-6x15 7
3410045 1
3410046 1
3410145 1
3410146 1
3410035 1
3410059 1
3410042 1
3410065 1
3410050 2
3410020 2
3410075 1
UNI5931-6x15 2
3410073 1
Note
? 5 mm
M6
25-42-7NBR
25-37-7NBR
M8x25x5x15
18x22x22
? 76 - "A", "B", "C"
"A", "B", "C"
M8 CH10
"TS" type
Waved
M10x1
400W-Z14-sold with fig.43-44
Z14
M5
M5
6,3 mm
21
