ADJUSTING THE CARBURETTOR

Please see the separate "Tillotson"manual for high and low speed carburettor adjustment.
Throttle cable
- Once the throttle cable has been fitted, adjust the freeplay between the carburettor and the throttle lever by
adjusting the tensioning device.
- Set the throttle lever to minimum.
- Check that the throttle lever is free to move unimpeded and that the cable sheath has less than 1 mm of
freeplay (check by pulling the sheath). Adjust if nessacary
