BT- 48
WORKMATE
I M P O R TA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
0307
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.
Advertisement
Table of Contents
Related Manuals for Ironwood WORKMATE BT- 48
Summary of Contents for Ironwood WORKMATE BT- 48
- Page 1 BT- 48 WORKMATE I M P O R TA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of Before you begin assembly: the missing part(s) to: PARTS, Box 1420, Missoula, MT 59806 or call:...
-
Page 2: Parts Diagram
PARTS DIAGRAM Left Side Right Side 03430549 03430549 Panel Panel Back 03430541 03430541 Shelf 03430541 Divider 03430541 Panel Keyboard 03432252 Shelf... - Page 3 HARDWARE Shelf Slide 490260 2 pr. Slide Channel 490260 2 pr. Minifix Bolt 909834 19 ea. Varianta Screw 988060 12 ea. Minifix Cam 909810 19 ea. Wood Dowel 195000 12 ea. Confirmat Caster Bracket 402302 4 ea. 950100 4 ea. Screw Caster 402290...
-
Page 4: Before Starting Assembly
Using the Minifix System: Insert the Minifix Cams into the appropriate holes with the arrow facing outwards as shown. When screwing post into hole, Do Not over tighten. Screw post down until bottom face of post flange just touches board surface. ASSEMBLED DISASSEMBLED Using the #2 Phillips screwdriver,... -
Page 5: Right Side
Place the Divider Panel (J) as shown below and attach a Left Slide Channel (S1) using three Varianta Screws (H1). Attach a Right Slide Channel to the other side of the divider, opposite the Left Slide Channel. RIGHT SIDE LEFT SIDE Screw eight Minifix Bolts (H2) into the pre-drilled holes of the Right Side Panel (B) and Left Side... - Page 6 # 6a # 7a Insert six Minifix Cams (H4) into the Top Insert three Minifix Cams (H4) into the Panel (C) with the arrows of the cams Divider Panel (J) with the arrows of the facing out. cams facing out. # 7b Position the Divider Panel onto the Top FRONT...
- Page 7 Insert six Minifix Cams (H4) into the Insert four Minifix Cams into the Shelf # 8a # 10a (G) with the arrows of the cams facing Back Panel (D) with the arrows of the outwards. cams facing out. # 10b Position Shelf onto the Left Side Panel (A) and turn cams clockwise to secure.
- Page 8 # 11 # 12 Secure the Shelf to the Divider Panel (J) using two Confirmat Screws (H5) as shown. Position Right Side Panel (B) over the partially assembled unit insuring that the Minifix Bolts and Wood Dowels are inserted into the corresponding Minifix Cams and holes as shown.
- Page 9 Right Shelf Slides (S3&S4) using the Panhead Screws (H9) as shown. FINISHED EDGE FINISHED EDGE # 15 With the unit upright, slide the Keyboard Shelves (G) into the Shelf Slides as shown. Your Ironwood Workmate is now completely assembled and ready for use.
