VUEPOINT FPM50 Manual page 5

1/2 in.
CauTION
Avoid potential personal injuries or property
damage! Never drill into the mortar between the
blocks. Be sure the plastic anchors [06] seat flush
with the blocks. If there is a layer of drywall or
other material, this drywall or other material may
not exceed 5/8 inch [15.8 mm] in thickness.
>64 mm
(2.5 in.)
Do not overtighten the lag bolts! Tighten the
lag bolts [04] only until the washers [05] are
pulled against the wall plate [01].
6902-100060 <02>
CauTION
1-2
[01]
6x
>15 cm
(6 in.)
[06]
[05]
[04]
