002153.eps
Thank you for choosing the VuePoint FPM50 monitor mount. The FPM50 is designed to support
VMPL50 / FPM50 - full assembly
flat-panel monitors 30 - 50 inches (76 - 127 cm), and weighing no more than 59 kg (130 lbs.). The
FPM50 is adjustable, allowing ±12˚ of tilt.
Do not use this product for any purpose not explicitly specified by VuePoint. Improper
installation may cause property damage or personal injury. If you do not understand these
directions, or have doubts about the safety of the installation, contact VuePoint Customer
Service or call a qualified contractor. VuePoint is not liable for damage or injury caused by
incorrect mounting, assembly, or use.
Hardware and procedures for multiple mounting configurations are included. When
OPT
you see this symbol, choose the correct configuration to suit your needs. Not all
OPT
hardware included will be used.
CSAV, Inc. 2221 Hwy 36 West, Saint Paul, MN 55113 USA
Customer Service: 1-888-333-9952 • info@vuepointav.com • www.vuepointav.com
FPM50
(6902-100060 <02>)
CauTION
Advertisement
Related Manuals for VUEPOINT FPM50
Summary of Contents for VUEPOINT FPM50
- Page 1 (6902-100060 <02>) 002153.eps Thank you for choosing the VuePoint FPM50 monitor mount. The FPM50 is designed to support VMPL50 / FPM50 - full assembly flat-panel monitors 30 - 50 inches (76 - 127 cm), and weighing no more than 59 kg (130 lbs.). The FPM50 is adjustable, allowing ±12˚...
- Page 2 If you have any doubts about the ability of the wall to support the monitor, contact VuePoint Customer Service, or a qualified contractor. This product is not designed for use in metal stud walls!
- Page 3 [03] x 1 002154.eps 5/16 in. [04] x 6 [05] x 6 [06] x 6 VMPL50 / FPM50 - wall plate and brackets M8 x 16 mm M5 x 12mm M4 x 12 mm M6 x 12 mm [07] x 4...
- Page 4 3/16 in. 30.5 - 60.9 cm (12 - 24 in.) [01] 2.5 in. CauTION Do not overtighten the lag bolts! Tighten the lag bolts [04] only until the washers [05] are pulled against the wall plate [01]. [05] [04] 6902-100060 <02>...
- Page 5 1/2 in. >15 cm (6 in.) CauTION Avoid potential personal injuries or property damage! Never drill into the mortar between the blocks. Be sure the plastic anchors [06] seat flush with the blocks. If there is a layer of drywall or other material, this drywall or other material may not exceed 5/8 inch [15.8 mm] in thickness.
- Page 6 Use washer [21] with M4 or M5 hardware. Use washer [22] with M6 or M8 hardware. [07], [08], [15], [16], [09], [10] 002155.eps [21], [22] [17], [18] VMPL50 / FPM50 - Back of monitor 50 - Back of monitor 6902-100060 <02>...
- Page 7 [02] [03] [21], [22] [11], [12], Use washer [21] with M4 or M5 hardware. [13], [14] Use washer [22] with M6 or M8 hardware. [19], [20] [21] Use washer [21] with M4 or M5 hardware only. [15], [16], [17], [18] 6902-100060 <02>...
- Page 8 [24] HEaVY! You will need assistance with this step. 002164.eps VMPL50 / FPM50-Mount brackets to wall plate CauTION Avoid potential personal injuries or property damage! Be sure to install the safety bolts [23]. Periodic tightening [23] may be required. 6902-100060 <02>...
- Page 9 Use the tension knob [A] to adjust the pitch tension. VMPL50 / FPM50-Mount brackets to wall plate CSAV, Inc. and its affiliated corporations and subsidiaries intend to make this manual accurate and complete. However, CSAV makes no claim that the information contained herein covers all details, conditions, or variations.
