5.8.6 PORT1
The PORT1 is equipped on customer's request with one of the offered expansion ports:
Description and examples of expansion ports connection can be found in user's guide for
corresponding expansion port.
PORT1 cable plug into the RJ45 connector labeled as PORT1 (see figure below).
5.8.7 PORT2
The PORT2 is equipped on customer's request with one of the offered expansion ports:
PORT2 is available only in the Full version of the router! Description and examples of
expansion ports connection can be found in user's guide for corresponding expansion port.
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
RS232
RS485
RS422
ETHERNET
Figure 30: PORT1 cable connection
RS232
RS485
RS422
MBUS
5. ROUTER DESIGN
MBUS
CNT
SWITCH (together with PORT2)
SDH
SWITCH (together with PORT1)
WIFI
WMBUS
18
