  • Page 1 Intel Intel i845-PE mainboard for Intel Socket 478 processor for Intel Socket 478 processor for Intel Socket 478 processor for Intel Socket 478 processor for Intel Socket 478 processor TRADEMARK These specifications are subject to change without notice.

  • Page 2: Disclaimer Of Warranties

    DISCLAIMER OF WARRANTIES: THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT.
  • Page 3 Table of Contents Page Section 1 Introduction Section 2 Features Section 3 Installatio Easy Installation Procedure...
  • Page 4 Section 4 BIOS Setup Section 5 Driver Installation Appendix Appendix A Appendix B Appendix C Appendix D...

  • Page 5: Package Contents

    Introduction Section 1 INTRODUCTION Package Contents Contents Optional Items If you need the optional item, please contact your dealer for assistance. USER’S MANUAL Page 1-1...

  • Page 6: Chipset Components

    Introduction Intel Pentium 4 processors ® ® For more information about all the new features the Pentium 4 delivers check out the Intel website at http://www.intel.com Chipset Components ® ® Memory Controller Hub (MCH) I/O Controller Hub (ICH4) Page 1-2...

  • Page 7: Accelerated Graphics Port (Agp)

    Introduction Accelerated Graphics Port (AGP) Ultra ATA/66/100 Hardware Monitoring LAN (Optional) Page 1-3...
  • Page 8 Introduction Mainboard Form-Factor AT X Power Supply 5 1/4-inch 3 1/2-inch Figure 2: Summary of ATX chassis features Page 1-4...

  • Page 9: I/O Shield Connector

    Introduction I/O Shield Connector RJ45 LAN Joystick/Midi port Parallel Port (Optional) PS/2 Mouse PS/2 Keyboard COM2 USB 2.0 COM1 port Line-out/Front out (Lime) Line-in/Rear out (Light Blue) Mic-in/Center&Subwoofer(Pink) Figure 3: I/O ports Power-On/Off (Remote) Remote On/Off ® 12V 4-pin POWER SUPPLY 20-pin PW-ON Case (chassis) Power ON/OFF button (PW-ON)
  • Page 10 Introduction System Block Diagram Figure 5: System Block Diagram Page 1-6...

  • Page 11: Mainboard Features

    Section 2 FEATURES Mainboard Features Processor ® ® ® ® CPU: An Intel Pentium 4 Processor with HT Technology. ® Chipset: An Intel Chipset that supports HT Technology. BIOS: A BIOS that supports HT Technology and has it enabled. An operating system that supports HT Technology.
  • Page 12 .A=JKHAI Onboard PCI Devices Legacy IO Controller Audio Peripheral Interfaces Page 2-2...
  • Page 13 .A=JKHAI Front Panel Controller Expansion Slots Other Features Page 2-3...
  • Page 14 .A=JKHAI Form Factor Page 2-4...

  • Page 15: Installation

    Installation Section 3 INSTALLATION Page 3-1...

  • Page 16: Mainboard Layout

    Installation Mainboard Layout Page 3-2...

  • Page 17: Easy Installation Procedure

    Installation Easy Installation Procedure 3-1. CPU Installation 3-2. Jumper Settings 3-3. System Memory Configuration 3-4. Expansion Slots 3-5. Device Connectors 3-1 CPU Installation Figure 2 Figure 1 Pin 1 Step 1 Step 2 Page 3-3...
  • Page 18 Installation Figure 3 Figure 4 Step 3 Step 4 Figure 5 Figure 6 Step 5 Step 6 NOTES: Page 3-4...

  • Page 19: Jumper Settings

    Installation 3-2 Jumper Settings JCMOS: Settings: 1-2: Normal (Default) 2-3: Clear CMOS Page 3-5...

  • Page 20: Memory Layout

    Installation 3-3 System Memory Configuration Memory Layout <Figure 7> Bank 0/1 DDR DIMM 1 Synchronous DDR DIMM 2 Bank 2/3 DRAM <Table 1> * DDR SDRAM supports 64, 128, 256, 512MB and 1GB DIMM modules using 512Mb technology. NOTES: Page 3-6...

  • Page 21: Dimm Module Installation

    Installation DIMM Module Installation Figure 8 - DIMM notch Figure 9 - DIMM module clips before installation Figure 10 - DIMM module clip after installation Page 3-7...

  • Page 22: Installing An Expansion Card

    Installation 3-4 Expansion Slots AGP Slot PCI Slots AGP Slot PCI Slots Installing an Expansion Card Page 3-8...
  • Page 23 Installation AGP Card Installation Caution Page 3-9...
  • Page 24 Installation 3-5 Connectors RJ45 LAN Joystick/Midi port Parallel Port (Optional) PS/2 Mouse PS/2 Keyboard COM2 USB 2.0 COM1 port Line-out/Front out (Lime) Line-in/Rear out (Light Blue) Mic-in/Center&Subwoofer(Pink) Figure 11 - I/O Ports JCPU_FAN JPWR_FAN JCPU_FAN / JPWR_FAN / : JCPU_FAN JPWR_FAN +12V +12V...
  • Page 25 Installation .,, IDE1/IDE2: IDE1IDE2 When use two IDE drives, one must be set to Master mode and the other one to Slave mode. Refer to your disk drive user’s manual for information about select- ing the proper drive switch settings. IDE1/IDE2 PW1: PW12:...
  • Page 26 Installation CFPA MIC_In Front Line-out-R Rear Line-out-FR Rear Line-out-FL Front Line-out-L Settings Pins (5-6) & (9-10) Short (default): Only the onboard rear panel audio jack can be used. Pins (5-6) & (9-10) Open: Only front panel audio jack can be used. In 2-Channel audio mode, Mic-In is shared for both front panel and rear panel.
  • Page 27 Installation CUSB2/CUSB3: CUSB2 Data0- Data1- CUSB3 Data0+ Data1+ CAUTION ! Please make sure the USB cable has the same pin assignment. A different pin assignment may cause damage to the system. If you need the USB cable, please contact our retailer.
  • Page 28 Installation CFP: Front Panel Connector HD_LED PWR_LED PW_ON CFP / CIR / CSPK CIR: CSPK: Page 3-14...
  • Page 29 Installation 3-6 External Modem Ring-in Power ON and Keyboard Power ON Functions (KBPO) Modem-Ring Power ON Function Keyboard Power ON Function Step : NOTES: Page 3-15...
  • Page 30 Installation 3-7 STR (Suspend To RAM) Function ® Page 3-16...

  • Page 31: Bios Setup

    BIOS Section 4 BIOS SETUP Main Menu The BIOS setup screen and description are for reference only, and may not exactly match what you see on your screen. The contents of BIOS are subject to change without notice. Please visit our website for updates. Figure 1: CMOS Setup Utility...

  • Page 32: Standard Cmos Setup

    BIOS 4-1 Standard CMOS Setup Figure 2: Standard CMOS Setup...

  • Page 33: Advanced Bios Features

    BIOS 4-2 Advanced BIOS Features Figure 3: BIOS Features Setup...
  • Page 34 BIOS...
  • Page 35 BIOS...
  • Page 36 BIOS Boot Seq & Floppy Setup...
  • Page 37 BIOS...

  • Page 38: Advanced Chipset Features

    BIOS 4-3 Advanced Chipset Features Figure 4: Chipset Features Setup...
  • Page 39 BIOS...

  • Page 40: Integrated Peripherals

    BIOS 4-4 Integrated Peripherals Figure 5: Integrated Peripherals...
  • Page 41 BIOS Onboard IDE Device Setup...
  • Page 42 BIOS Onboard PCI Device Setup...
  • Page 43 BIOS Onboard I/O Chip Setup...
  • Page 44 BIOS...

  • Page 45: Power Management Setup

    BIOS 4-5 Power Management Setup Figure 6: Power Management...
  • Page 46 BIOS...
  • Page 47 BIOS...
  • Page 48 BIOS...
  • Page 49 BIOS ** Reload Global Timer Events **...

  • Page 50: Pnp/Pci Configuration

    BIOS 4-6 PNP/PCI Configuration Figure 7: PNP/PCI Configuration Setup...
  • Page 51 BIOS IMPORTANT! If using PCI cards on shared slots, make sure that the drivers support “Shared IRQ” or that the cards don’t need IRQ assignments. Conflicts will arise between the two PCI groups that will make the system unstable or cards inoperable.

  • Page 52: Pc Health Status

    BIOS 4-7 PC Health Status Figure 8: PC Health Status...
  • Page 53 BIOS...

  • Page 54: Frequency/Voltage Control

    BIOS 4-8 Frequency/Voltage Control [ 8 X ] Figure 9: Frequency/Voltage Control...
  • Page 55 BIOS Insert...
  • Page 56 BIOS Clock Generation for EMI...

  • Page 57: Defaults Menu

    BIOS 4-9 Defaults Menu...
  • Page 58 BIOS 4-10 Supervisor/User Password Setting...
  • Page 59 BIOS 4-11 Exiting BIOS Save & Exit Setup Exit Without Saving ...
  • Page 60 BIOS Page Left Blank...

  • Page 61: Section 5 Driver Installation

    USB V2.0 (README.HTM) DRIVER MANUAL CD EXPLORER EXIT Step 1 : Click “INTEL CHIPSET INF FILES” to install chipset driver. Step 2 : Click “AC’97 AUDIO DRIVER” to install audio driver. Step 3 : Click “REALTEK LAN DRIVER” to install LAN driver. (Optional) Step 4 : Click “USB V2.0 DRIVER (README.HTM)”...
  • Page 62 Drivers Installation Realtek Sound Manager Quick User-guide Introduction <Figure 1> Sound Effect: <Figure 2> Page 5-2...
  • Page 63 Drivers Installation Equalizer: <Figure 3> Speaker Configuration: <Figure 4> Page 5-3...

  • Page 64: Drivers Installation

    Drivers Installation Speaker Configuration: <Figure 5> Speaker Test: <Figure 6> “Speaker Test” Page 5-4...
  • Page 65 Drivers Installation SPDIF-In: <Figure 7> SPDIF-Out: <Figure 8> Page 5-5...
  • Page 66 Drivers Installation Connector Sensing: <Figure 9> Connector Sensing: <Figure 10> Page 5-6...
  • Page 67 Drivers Installation Connector Sensing: <Figure 11> General: <Figure 12> Page 5-7...
  • Page 68 Drivers Installation Page Left Blank Page 5-8...

  • Page 69: Functional Descriptions

    Appendix Appendix A A-1 Realtek Media Player User’s Guide Realtek     Media Player Platform " 06 - Reo Speedwagon " & 06-Reo Speedwagon - K 03:31 Functional Descriptions A. Playback Windows Display...
  • Page 70 Appendix B. Playback Function Controls e l l y t i t i d t o l C. Playback Controls...
  • Page 71 Appendix D. Seeking bar E. Title/Play List Windows F. Title/Play List Edit Controls G. Title/Play List Scroll bar H. Recording Function Controls I. REC/Playback Time Display...
  • Page 72 Appendix J. Platform Display Panel Controls K. Equalizer Control Panel...

  • Page 73: Update Your System Bios

    Appendix Appendix B B-1 Update Your System BIOS XXXX XXXX XXXXX xxxxx.bin...
  • Page 74 Appendix XXXX XXXXX xxxxx.bin xxxxx.bin XXXX XXXXX xxxxx.bin xxxxx.bin XXXX XXXXX xxxxx.bin F10 : Exit F1 : Reset...

  • Page 75: Eeprom Bios Remover

    Appendix Appendix C C-1 EEPROM BIOS Remover Do not remove the BIOS chip, unless instructed by a technician and only with a PLCC IC extractor tool. The BIOS socket is fragile may be damaged if an improper method to replace the BIOS chip is applied.
  • Page 76 Appendix Page Left Blank...

  • Page 77: Ghost 7 Quick User's Guide (Optional)

    Appendix Appendix D D-1 GHOST 7 Quick User’s Guide (Optional) Ghost7 Ghost.exe Main Menu Description of Menu Ghost Disk Partition. Disk Partition Check Disk...
  • Page 78 Appendix There are 3 hard disk functions: Important! Disk To Disk (Disk Cloning) Source drive Destination drive...
  • Page 79 Appendix Disk To Image (Disk Backup) Disk From Image(Restore Backup)
  • Page 80 Appendix Destination drive Partition...
  • Page 81 Appendix 1. Partition To Partition 2. Partition To Image 3. Partition From Image Partition To Partition (Partition Cloning) Partition To Image (Partition Backup)
  • Page 82 Appendix Partition From Image (Restore Partition)
  • Page 83 Appendix Check...
  • Page 84 Appendix How to Reinstall Windows in 2 Minutes This chapter guides you how to setup your computer properly and, if necessary, reinstall Windows Ghost Recover Floppy Recover CD Emergency Recover Floppy Windows Office Windows, Ghost Original.gho Windows Autoexec.
  • Page 85 Appendix Autoexec.bat B a c k u p B a c k u p B a c k u p B a c k u p B a c k u p Restore Restore Restore Restore Restore [General Windows] [Windows and Application Programs].
  • Page 86 Appendix Recover CD [Introducing Ghosts Functions] D-10...
