- Page 1 222i6L www.philips.com/welcome EN User manual Customer care and warranty Troubleshooting & FAQs...
-
Page 2: Table Of Contents
4.1 Resolution & Preset Modes....11 5. Power Management ......12 6. Regulatory Information ......13 7. Customer care and warrant .....15 7.1 Philips’ Flat Panel Monitors Pixel Defect Policy ..........15 7.2 Customer Care & Warranty ....17 8. Troubleshooting & FAQs ....21 8.1 Troubleshooting ...........21... -
Page 3: Important
1. Important • Please use approved power cord provided 1. Important by Philips all the time. If your power cord is missing, please contact with your local This electronic user’s guide is intended for service center. (Please refer to Customer anyone who uses the Philips monitor. -
Page 4: Notational Descriptions
1. Important • Temperature: 0-40°C 32-95°F 1.2 Notational Descriptions • Humidity: 20-80% RH The following subsections describe notational Important information for Burn-in/Ghost conventions used in this document. image Notes, Cautions and Warnings • Always activate a moving screen saver Throughout this guide, blocks of text may be program when you leave your monitor accompanied by an icon and printed in bold or unattended. -
Page 5: Disposal Of Product And Packing
From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails This marking on the product or on its... -
Page 6: Setting Up The Monitor
1. Place the monitor face down on soft and smooth surface taking care to avoid scratching or damaging the screen. 2.1 Installation Package contents 222i6L Register your product and get support at www.philips.com/welcome Quick Start 2. Attach the base column with the monitor until it clicks into position. -
Page 7: Operating The Monitor
2. Setting up the monitor Connecting to your PC 2.2 Operating the monitor Front view product description 222i6L DC power input Model 222i6L VGA input Kensington anti-theft lock Connect to PC 1. Connect the power cord to the back of the monitor firmly. - Page 8 On-Screen Display. You can use this as a On-Screen Display (OSD) is a feature in all reference when you want to work your way Philips LCD monitors. It allows an end user to around the different adjustments later on. adjust screen performance or select functions...
-
Page 9: Remove Base Stand And Base
2. Setting up the monitor Resolution notification 2.3 Remove Base Stand and Base This monitor is designed for optimal Remove the Base Stand performance at its native resolution, 1920 × 1080 @ 60 Hz. When the monitor is powered Before you start disassembling the monitor on at a different resolution, an alert is displayed base, please follow the instructions below to on screen: Use 1920 ×... -
Page 10: Image Optimization
3. Image Optimization 3. Image Optimization 3.1 SmartContrast What is it? A unique technology that dynamically analyzes displayed content and automatically optimizes an LCD monitor's contrast ratio for maximum visual clarity and viewing enjoyment, stepping up backlighting for clearer, crisper and brighter images or dimming backlighting for clear display of images on dark backgrounds. -
Page 11: Technical Specifications
4. Technical Specifications 4. Technical Specifications Picture/Display Monitor Panel Type TFT-LCD Backlight Panel Size 21.5" W (54.6 cm) Aspect Ratio 16:9 Pixel Pitch 0.248 × 0.248 mm Brightness 220 cd/m² SmartContrast 10,000,000:1 Contrast Ratio (typ.) 600:1 5ms Response Time (typ.) Optimum Resolution 1920 ×... - Page 12 Finish Glossy/Texture Note 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net for registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet.
-
Page 13: Resolution & Preset Modes
4. Technical Specifications 4.1 Resolution & Preset Modes Maximum Resolution 1920 × 1080 @ 60 Hz (analog input) 1920 × 1080 @ 60 Hz (digital input) Recommended Resolution 1920 × 1080 @ 60 Hz (digital input) H. freq (kHz) Resolution V. -
Page 14: Power Management
'wake up' automatically. The following table shows the power consumption and signaling of this automatic power saving feature: 222i6L: Power Management Definition VESA Video H-sync V-sync Power Used LED Color Mode 20 W (typ.) -
Page 15: Regulatory Information
RoHs directive mandating restrictions on hazardous substances in electrical and 根据中国大陆《电子信息产品污染控制管理办法》（也 称为中国大陆RoHS），以下部分列出了本产品中可能 electronic equipment have been adhered to 包含的有毒有害物质或元素的名称和含量 in order to make Philips monitors safe to use throughout its life cycle. 本表适用之产品 显示器（液晶及CRT） 有毒有害物质或元素 E-Waste Declaration for India 有毒有害物质或元素... - Page 16 6. Regulatory Infomation 《废弃电器电子产品回收处理管理条例》提示性 说明 为了更好地关爱及保护地球，当用户不再需要此产品或 产品寿命终止时，请遵守国家废弃电器电子产品回收处 理相关法律法规，将其交给当地具有国家认可的回收处 理资质的厂商进行回收处理。...
-
Page 17: Customer Care And Warrant
No manufacturer can guarantee types of bright dot defects. that all panels will be free from pixel defects, but Philips guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This notice explains the different types of pixel defects and defines acceptable defect levels for each type. - Page 18 In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT Monitor panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
-
Page 19: Customer Care & Warranty
7.2 Customer Care & Warranty For warranty coverage information and additional support requirement valid for your region, please visit www.philips.com/support website for details. You may also contact your local Philips Customer Care Center number listed below. Contact Information for WESTERN EUROPE region:... - Page 20 +375 17 217 3389 Bulgaria LAN Service +359 2 960 2360 Croatia MR Service Ltd +385 (01) 640 1111 Czech Rep. Asupport 420 272 188 300 +372 6519900(General) Estonia FUJITSU +372 6519972(workshop) Georgia Esabi +995 322 91 34 71 +36 1 814 8080(General) Hungary Profi Service +36 1814 8565(For AOC&Philips only) Kazakhstan Classic Service I.I.c. +7 727 3097515 +371 67460399 Latvia ServiceNet LV +371 27260399 +370 37 400160(general) Lithuania UAB Servicenet +370 7400088 (for Philips) Macedonia +389 2 3125097 Moldova Comel +37322224035 Romania Skin +40 21 2101969...
- Page 21 Tel: +852 2619 9639 Mon.~Fri. 9:00am-6:00pm Macau Technology Ltd. Macau: Sat. 9:00am-1:00pm Tel: (853)-0800-987 Tel: 1 800 425 6396 REDINGTON INDIA India SMS: PHILIPS to Mon.~Fri. 9:00am-5:30pm 56677 +62-21-4080-9086 Mon.~Thu. 08:30-12:00; 13:00- PT. CORMIC (Customer Hotline) Indonesia 17:30 SERVISINDO PERKASA +62-8888-01-9086 Fri.
- Page 22 7. Customer care and warranty +84 8 38248007 Ho Chi Minh City FPT Service Informatic +84 5113.562666 Mon.~Fri. 8:00-12:00, 13:30-17:30 Vietnam Company Ltd. - Ho Chi Danang City Sat. 8:00-12:00 Minh City Branch +84 5113.562666 Can tho Province EA Global Supply Chain (02) 655-7777; Philippines Mon.~Fri. 8:30am~5:30pm Solutions ,Inc. 6359456 Armenia Azerbaijan Georgia Firebird service centre +97 14 8837911 Sun.~Thu. 09:00 - 18:00 Kyrgyzstan Tajikistan Soniko Plus Private...
-
Page 23: Troubleshooting & Faqs
• Disconnect the monitor from mains power after you have tried these solutions, contact source immediately for safety Philips customer service representative. • Contact with Philips customer service representative immediately. Common Problems Imaging Problems No Picture (Power LED not lit) Image is not centered • Make sure the power cord is plugged into... -
Page 24: General Faqs
× 1080 @ 60 Hz. application if your LCD monitor will display • Shut down your computer, disconnect your unchanging static content. old monitor and reconnect your Philips • Severe” burn-in” or “after-image” or “ghost LCD monitor. image” symptoms will not disappear and • Turn on your monitor and then turn on... - Page 25 When handling the monitor, PC, workstation or Mac? make sure that there is no pressure or Ans.: Yes. All Philips LCD monitors are fully force applied to the panel surface side. compatible with standard PCs, Macs This may affect your warranty conditions.
- Page 26 8. Troubleshooting & FAQs period of time after the power has been switched off. Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your LCD monitor will display unchanging static content.
- Page 27 © 2014 Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. Specifications are subject to change without notice. Version: M6222i10...
