220V8/221V8/222V8/221i8
www.philips.com/welcome
EN User manual
1
Customer care and warranty 25
Troubleshooting & FAQs
29

Advertisement

Table of Contents
loading

Related Manuals for Philips 221V8

Summary of Contents for Philips 221V8

  • Page 1 V Line 220V8/221V8/222V8/221i8 www.philips.com/welcome EN User manual Customer care and warranty 25 Troubleshooting & FAQs...

  • Page 2: Table Of Contents

    5.1 Resolution & Preset Modes ... 22 6. Power Management ....23 7. Customer care and warranty . 25 7.1 Philips’ Flat Panel Monitors Pixel Defect Policy ....25 7.2 Customer Care & Warranty ..28 8. Troubleshooting & FAQs ..29 8.1 Troubleshooting ......29...

  • Page 3: Important

    DC power cord for normal operation. 1.1 Safety precautions and • Please use approved power cord maintenance provided by Philips at all times. If your power cord is missing, please Warnings contact your local service center. Use of controls, adjustments or...
  • Page 4 1. Important tilt angle maximum is exceeded, the • Oil-based cleaning solutions may monitor damage will not be covered damage the plastic parts and void under warranty. the warranty. • Do not knock or drop the monitor • Unplug the monitor if you are not during operation or transportation.

  • Page 5: Notational Descriptions

    1. Important Uninterrupted display of still or 1.2 Notational Descriptions static images over an extended The following subsections describe period may cause “burn-in”, also notational conventions used in this known as “after-imaging” or “ghost document. imaging”, on your screen. • “Burn-in”, “after-imaging”, or Notes, Cautions and Warnings “ghost imaging”...

  • Page 6: Disposal Of Product And Packing Material

    From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end- of-life management primarily entails This marking on the product or on participation in national take-back...

  • Page 7: Setting Up The Monitor

    2. Hold the monitor base stand with Power both hands and firmly insert the base stand into the base column. * DVI * VGA (220V8/220V8L5) 221i8/221V8/221V8L/221V8LD/221V8LS/ 221V8A/222V8LA V Line/i Line 221V8/222V8/221i8 Quick Start Register your product and get support at www.philips.com/welcome...
  • Page 8 2. Setting up the monitor Connecting to your PC 221i8/221V8/221V8L/221V8LS 220V8L/220V8LL 2 3 4 AC power input HDMI input AC power input VGA input VGA input Audio output Kensington anti-theft lock Kensington anti-theft lock 220V8/220V8L5 221V8LD 2 3 4 5...
  • Page 9 2. Setting up the monitor 221V8A Connect to PC 1. Connect the power cord to the back of the monitor firmly. 2. Turn off your computer and unplug its power cable. 2 3 4 5 3. Connect the monitor signal cable to the video connector on the back of your computer.

  • Page 10: Operating The Monitor

    2. Setting up the monitor 220V8/220V8L5/221i8/221V8/221V8LD/ 2.2 Operating the monitor 221V8LS/221V8L Description of the control buttons 220V8L/220V8LL Switch monitor’s power ON and OFF. Switch monitor’s power Access the OSD menu. ON and OFF. Confirm the OSD Access the OSD menu.
  • Page 11 Description of the On Screen Display What is On-Screen Display (OSD)? On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window.
  • Page 12 2. Setting up the monitor 221i8/221V8/221V8L/221V8LD/221V8LS/ 220V8/220V8L5/220V8L/220V8LL 221V8A/222V8LA Main menu Sub menu LowBlue Mode 1, 2, 3,4  Input    (220V8/ 220V8L5) Picture Picture Format Wide Screen, 4:3  Brightness 0~100 Contrast 0~100  Sharpness 0~100 SmartResponse O , Fast, Faster, Fastest ...
  • Page 13 2. Setting up the monitor Resolution notification 221i8/221V8/221V8A/221V8L/221V8LS/221V8LD/222V8LA This monitor is designed for optimal Main menu Sub menu performance at its native resolution, LowBlue Mode 1, 2, 3,4 1920 × 1080. When the monitor is Input powered on at a different resolution, an HDMI 1.4...

  • Page 14: Remove The Base Assembly For Vesa Mounting

    2. Setting up the monitor Note 2.3 Remove the Base Assembly This monitor accepts a 100mm x 100mm for VESA Mounting VESA-Compliant mounting interface. Before you start disassembling the VESA Mounting Screw M4. Always monitor base, please follow the contact manufacturer for wall-mount instructions below to avoid any possible installation.

  • Page 15: Image Optimization

    SmartImage is an exclusive, leading This mode significantly enhances edge Philips technology that analyzes readability and productivity when the content displayed on your screen. you're working with spreadsheets, Based on a scenario you select,...

  • Page 16: Smartcontrast

    Developed for wellbeing, content. SmartContrast dynamically Philips LowBlue Mode setting uses controls contrast and adjusts a smart software technology to backlighting for clear, crisp, bright...

  • Page 17: Adaptive Sync (221I8/221V8/222V8)

    4. Adaptive Sync • AMD Radeon R9 290X 4. Adaptive Sync • AMD Radeon R9 290 (221i8/221V8/222V8) • AMD Radeon R9 285 • AMD Radeon R7 260X • AMD Radeon R7 260 ■ Processor A-Series Desktop and Adaptive Sync Mobility APUs •...

  • Page 18: Technical Specifications

    DVI x 1 (HDCP 1.4) 222V8LA: VGA x 1, HDMI 1.4 x 1 (HDCP 1.4), DisplayPort 1.2 x 1 (HDCP 1.4) Input Signal Separate Sync, Sync on Green 221i8/221V8/221V8L/221V8LS/221V8LD: Audio out Audio In/Out 221V8A: Audio-in, Earphone output 222V8LA: Audio-in, Audio out Convenience...
  • Page 19 5.Technical Specifications English, German, Spanish, Greek, French, Italian, Hungarian, Dutch, Portuguese, Brazil Portuguese, OSD Languages Polish, Russian, Swedish, Finnish, Turkish, Czech, Ukranian, Simplified Chinese, Traditional Chinese, Japanese, Korean Other Convenience VESA mount (100x100mm), Kensington Lock Plug & Play Compatibility DDC/CI, sRGB, Windows 10/8.1/8/7, Mac OS X Stand Tilt -5 / +20 degree...
  • Page 20 5.Technical Specifications On mode: White, Standby/Sleep mode: White Power LED indicator (blinking) Power Supply Built-in, 100-240V AC, 50-60Hz Power(221i8/221V8) AC Input AC Input AC Input Consumption Voltage at Voltage at Voltage at 100VAC , 60Hz 115VAC , 60Hz 230VAC, 50Hz Normal Operation 17.6 W (typ.)
  • Page 21 5.Technical Specifications Power(221V8L/221V8LS) AC Input AC Input AC Input Consumption Voltage at Voltage at Voltage at 100VAC , 60Hz 115VAC , 60Hz 230VAC, 50Hz Normal Operation 15.0 W (typ.) 15.0 W (typ.) 15.0 W (typ.) Sleep (Standby mode) 0.5 W (typ.) 0.5 W (typ.) 0.5 W (typ.) Off mode...
  • Page 22 221V8AB/221V8L/221V8LS/221V8LD/222V8LA: (WxHxD) 565 x 440 x 111 mm 221i8: 542 x 447 x 118 mm Weight 220V8L5: 2.71 kg 220V8LL: 2.70 kg 220V8/220V8L: 2.58 kg Product with stand 221V8/221i8: 2.60 kg 221V8A: 2.61 kg 221V8L/221V8LS/221V8LD: 2.69 kg 222V8LA: 2.79 kg...
  • Page 23 500 to 1060hPa (Non-operation) Environmental and energy ROHS Packaging 100% recyclable Specific Substances 100% PVC BFR free housing Cabinet Color White/Black Finish Texture Note This data is subject to change without notice. Go to www.philips.com/support to download the latest version of leaflet.

  • Page 24: Resolution & Preset Modes

    5.Technical Specifications 5.1 Resolution & Preset Modes Maximum Resolution 1920 x 1080 @ 60 Hz (VGA/DVI) 1920 x 1080 @ 75 Hz (HDMI/DP) Recommended Resolution 1920 x 1080 @ 60 Hz (VGA/HDMI/ H. freq Resolution V. freq (Hz) (kHz) 31.47 720x400 70.09 31.47...

  • Page 25: Power Management

    6.Power Management 221i8/221V8 6. Power Management Power Management Definition If you have VESA DPM compliance display card or software installed in VESA Power Video H-sync V-sync Mode Used Color your PC, the monitor can automatically reduce its power consumption when 17.7 W...
  • Page 26 6.Power Management 221V8LD Power Management Definition VESA Power Video H-sync V-sync Mode Used Color 16.8 W (typ.) Active White 19.7 W (Max.) Sleep 0.5 W White (Standby (typ.) (blink) mode) 0.3 W Off mode (typ.) 222V8LA Power Management Definition VESA Power Video H-sync V-sync Mode...

  • Page 27: Customer Care And Warranty

    Pixel Defect Policy sub pixels together appear as a single white pixel. When all are dark, the three Philips strives to deliver the highest colored sub pixels together appear as a quality products. We use some single black pixel. Other combinations...
  • Page 28 TFT Monitor bright dot is 30 percent brighter than panel in a Philips flat panel monitor neighboring dots. must have pixel or sub pixel defects exceeding the tolerances listed in the Black Dot Defects following tables.
  • Page 29 7.Customer care and warranty BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 5 or fewer...

  • Page 30: Customer Care & Warranty

    Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below.

  • Page 31: Troubleshooting & Faqs

    • Contact with Philips customer • First, ensure that the power button service representative immediately. on the front of the monitor is in the...
  • Page 32 "burn-in", also Service contact information listed in known as "after-imaging" or "ghost Important information manual and imaging", on your screen. "Burn-in", contact Philips customer service "after-imaging", or "ghost imaging" representative. is a well-known phenomenon in * Functionality different according to LCD panel technology.

  • Page 33: General Faqs

    Philips LCD monitor. the panel surface side. This may • Turn on your monitor and then turn affect your warranty conditions.
  • Page 34 “ghost image” symptoms any PC, workstation or Mac? that will not disappear and cannot be repaired. The damage mentioned above Ans.: Yes. All Philips LCD monitors are is not covered under your warranty. fully compatible with standard PCs, Macs and workstations.
  • Page 35 “Attention” to show the unlock/lock status as shown below illustrators.       Q14: Where can I find Important information manual mentioned in EDFU? Ans.: Important information manual can be download on the Philips website support page.
  • Page 36 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are regis- tered trademarks of Koninklijke Philips N.V. and are used under license.
