SPECIFICATIONS

GENERAL
Power Requirement
Power Consumption
Temperature
Operating position
Dimensions (W x H x D)
Weight
Format
Tape Width
Tape Speed
Maximum Recording Time with full-size cas-
sette
VIDEO
Signal system
Recording system
Input
Output
Signal-to-Noise ratio
Horizontal resolution
AUDIO
Recording system
Input
Output
Frequency Range
Signal to Noise Ratio
Audio Distortion
TUNER
Tuning system
RF Output
TIMER
Memory programmable
Back up time
Clock exactness
ACCESSORIES
Provided Accessories
* Design and specification can be subjected to change without notice.
CHANNEL COVERAGE
SYSTEM
CHANNEL
INPUT/OUTPUT JACK TYPE
Model
Jack Type
AC 230V, 50Hz
Max. 17W (in REC mode)
5×C ~ 35×C (Operating)
-20×C ~ 60×C
Horizontal only
360 x 90 x 288 (mm)
Approx. 3.85 Kg
VHS standard
12.65mm
(SP) : 23.39mm/sec
(LP) : 11.70mm/sec
(SP) :240min, with E-240 video cassette
(LP) :480min, with E-240 video cassette
PAL/SECAM colour and CCIR monochrome signals, 625 lines/50 fields
Rotary two-head helical scan with a slant double-azimuth combination video
head
1.0Vp-p, 75ohms, unbalanced
1.0Vp-p, 75ohms, unbalanced
45dB (Rhode & Schwarz noise meter) with NETTETE IMAGE control at cen-
ter position
240 lines with NETTETE IMAGE control at center position
Longitudinal track
-8dBm, (CENELEC standard),more than 47 k-ohms, unbalanced
-6dBm, (CENELEC standard), less than 1k-ohms, unbalanced(100k-ohms,
load)
100Hz to 8,000Hz
More than 38dB
Less than 3% (SP)
Voltage synthesized tuner Programmable V/S 99CH (Hyper band)
UHF channel 21~69 (52)
99 CH
Less than 1 Hour
In accordance with the exactness of power supply frequency (50Hz)
Remote control unit, RF Cable, Battery
SECAM-L
PAL, SECAM-B/G, PAL-I/I
PAL, SECAM-B/G, D/K, HYPER BAND
VHF Ch 2~12
UHF Ch 21~69
CATV Ch X,Y,Z S1~S41
EUROPE
SCART Type
Asia, South Africa, Australia
RCA Jack (Phone Jack)
6
PAL-I
UHF Ch 21~69
