Daewoo DVST8S4 Series Service Manual page 30

LOC. PART-CODE PART-NAME
R527 HRFS273JBA R CHIP
R529 HRFS201JBA R CHIP
R534 HRFS103JBA R CHIP
R536 HRFS103JBA R CHIP
R539 HRFS431JBA R CHIP
R547 HRFS332JBA R CHIP
R555 HRFS820JBA R CHIP
R562 HRFS103JBA R CHIP
R565 HRFS103JBA R CHIP
R566 HRFS103JBA R CHIP
R567 HRFS103JBA R CHIP
R569 HRFS103JBA R CHIP
R570 HRFS103JBA R CHIP
R578 HRFS104JBA R CHIP
R582 HRFS103JBA R CHIP
R606 HRFS750JBA R CHIP
R611 HRFS750JBA R CHIP
R654 HRFS221JBA R CHIP
R656 HRFS273JBA R CHIP
R657 HRFS473JBA R CHIP
R688 HRFS221JBA R CHIP
R830 HRFS103JBA R CHIP
R831 HRFS103JBA R CHIP
RJ001 HRFS000-BA R CHIP
RJ002 HRFS000-BA R CHIP
RJ201 HRF8000-EA R CHIP
RJ202 HRF8000-EA R CHIP
RJ203 HRF8000-EA R CHIP
RJ241 HRFS000-BA R CHIP
RJ242 HRFS000-BA R CHIP
RJ281 HRF8000-EA R CHIP
RJ301 HRF8000-EA R CHIP
RJ341 HRFS000-BA R CHIP
RJ398 HRFS000-BA R CHIP
RJ399 HRF8000-EA R CHIP
RJ503 HRF8000-EA R CHIP
RJ544 HRF8000-EA R CHIP
RJ545 HRF8000-EA R CHIP
RJ582 HRF8000-EA R CHIP
RJ586 HRFS000-BA R CHIP
RJ587 HRF8000-EA R CHIP
RJ588 HRFS000-BA R CHIP
RJ589 HRF8000-EA R CHIP
RJ590 HRF8000-EA R CHIP
RJ593 HRF8000-EA R CHIP
RJ596 HRF8000-EA R CHIP
RJ597 HRFS000-BA R CHIP
RJ599 HRF8000-EA R CHIP
RJ604 HRF8000-EA R CHIP
RJ605 HRF8000-EA R CHIP
RJ606 HRF8000-EA R CHIP
PART-DESC. REMARK
1/16 27K OHM J 1608
1/16 200 OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 430 OHM J 1608
1/16 3.3K OHM J 1608
1/16 82 OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 100K OHM J 1608
1/16 10K OHM J 1608
1/16 75 OHM J 1608
1/16 75 OHM J 1608
1/16 220 OHM J 1608
1/16 27K OHM J 1608
1/16 47K OHM J 1608
1/16 220 OHM J 1608
1/16 10K OHM J 1608
1/16 10K OHM J 1608
1/16 0 OHM 1608
1/16 0 OHM 1608
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/16 0 OHM 1608
1/16 0 OHM 1608
1/8 0 OHM 3216
1/8 0 OHM 3216
1/16 0 OHM 1608
1/16 0 OHM 1608
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/16 0 OHM 1608
1/8 0 OHM 3216
1/16 0 OHM 1608
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/16 0 OHM 1608
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
1/8 0 OHM 3216
LOC. PART-CODE PART-NAME
RJ644 HRFS000-BA R CHIP
RJ646 HRFS000-BA R CHIP
RJ648 HRFS000-BA R CHIP
RJ899 HRFS000-BA R CHIP
Z0012 PVMPJRE210 MAIN RADIAL AUTO AS
C001 CEXF1C100A C ELECTRO
C004 CEXF1A101A C ELECTRO
C013 CEXF1C470A C ELECTRO
C015 CEXF1C470A C ELECTRO
C016 CEXF1H478A C ELECTRO
C055 CEXF1C100A C ELECTRO
C057 CEXF1C100A C ELECTRO
C059 CEXF1H339A C ELECTRO
C061 CEXF1C100A C ELECTRO
C063 CEXF1H109A C ELECTRO
C064 CEXF1C100A C ELECTRO
C065 CEXF1C100A C ELECTRO
C066 CEXF1C100A C ELECTRO
C068 CEXF1C100A C ELECTRO
C151 CEXF1C470A C ELECTRO
C152 CEXF1H109A C ELECTRO
C154 CEXF1H109A C ELECTRO
C158 CEXF1H479A C ELECTRO
C201 CEXF1C100A C ELECTRO
C204 CEXF1C220A C ELECTRO
C205 CEXF1C470A C ELECTRO
C208 CEXF1H479A C ELECTRO
C210 CEXF1C220A C ELECTRO
C213 CEXF1H478A C ELECTRO
C214 CEXF1C330A C ELECTRO
C219 CEXF1C220A C ELECTRO
C222 CMXM2A183J C MYLAR
C223 CEXF1H479A C ELECTRO
C225 CMXM2A333J C MYLAR
C259 CEXF1C100A C ELECTRO
C260 CEXF1C100A C ELECTRO
C261 CEXF1C100A C ELECTRO
C262 CEXF1C100A C ELECTRO
C264 CEXF1C100A C ELECTRO
C265 CEXF1C100A C ELECTRO
C270 CEXF1C100A C ELECTRO
C272 CEXF1C470A C ELECTRO
C273 CEXF1C100A C ELECTRO
C274 CEXF1H229A C ELECTRO
C275 CEXF1C100A C ELECTRO
C276 CEXF1C470A C ELECTRO
C278 CEXF1C100A C ELECTRO
C279 CEXF1C470A C ELECTRO
C283 CEXF1C470A C ELECTRO
C291 CEXF1C100A C ELECTRO
C292 CEXF1C100A C ELECTRO
29
ELECTRICAL PARTS LIST
PART-DESC. REMARK
1/16 0 OHM 1608
1/16 0 OHM 1608
1/16 0 OHM 1608
1/16 0 OHM 1608
DVST9S4D-AS
16V RSM 10MF 5X7
10V RSM 100MF 6.3X7
16V RSM 47MF (5X7) TP
16V RSM 47MF (5X7) TP
50V RSM 0.47MF 4X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
50V RSM 3.3MF 4X7
16V RSM 10MF 5X7
50V RSM 1MF (4X7) TP
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 47MF (5X7) TP
50V RSM 1MF (4X7) TP
50V RSM 1MF (4X7) TP
50V RSM 4.7MF 4X7
16V RSM 10MF 5X7
16V RSM 22MF (5X7)
16V RSM 47MF (5X7) TP
50V RSM 4.7MF 4X7
16V RSM 22MF (5X7)
50V RSM 0.47MF 4X7
16V RSM 33MF (6.3X7) TP
16V RSM 22MF (5X7)
100V 0.018MF J (TP)
2
50V RSM 4.7MF 4X7
100V 0.033MF J (TP)
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 10MF 5X7
16V RSM 47MF (5X7) TP
16V RSM 10MF 5X7
50V RSM 2.2MF (4X7) TP
16V RSM 10MF 5X7
16V RSM 47MF (5X7) TP
16V RSM 10MF 5X7
16V RSM 47MF (5X7) TP
16V RSM 47MF (5X7) TP
16V RSM 10MF 5X7
16V RSM 10MF 5X7
