- Page 1 User Manual MPTP-TU50S 50m USB 2.0 Extender Kit All Rights Reserved Version: MPTP-TU50S_2021V1.0...
- Page 2 50m USB 2.0 Extender Kit over CAT5E/6/7 Cable Statement Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real products. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 50m USB 2.0 Extender Kit over CAT5E/6/7 Cable Introduction Thanks for choosing the MPTP-TU50S extender kit which consists of a transmitter (Tx) and a receiver (Rx). It serves as a four in one USB hub and extends USB 2.0 signal up to 50 meters over a Cat5e/6/7 cable.
- Page 4 50m USB 2.0 Extender Kit over CAT5E/6/7 Cable Transmitter Panel Description Name Description ① HOST Type-B USB port to connect with the computer. ② Power LED Illuminates green when the unit is powered on. RJ45 connector for a CAT5e/6/7 Ethernet cable to connect the transmitter ③...
- Page 5 50m USB 2.0 Extender Kit over CAT5E/6/7 Cable System Diagram Note 1: This picture is for reference only. The specific scheme is subject to real devices. Note 2: This transmission distance between TX and RX is affected by the followings: ⚫...
