- Page 1 User Manual MP-HDFB-4K 4K Optical Fiber Extender All Rights Reserved Version: MP-HDFB-4K_2016V1.0...
- Page 2 4K Optical Fiber Extender Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model and its logo are trademarks.
-
Page 3: Safety Precautions
4K Optical Fiber Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. - Page 4 4K Optical Fiber Extender Introduction MP-HDFB-4K is a mini optical fiber extender for 4K resolution. It contains a transmitter （MP-HDFB-4KT）and a receiver（MP-HDFB-4KR）. Compatible with multi-mode and single-mode fiber, it extends graphic TMDS signals up to 400m/300m via single-mode cable/ multi-mode cable.
- Page 5 Step3. Insert MP-HDFB-4KR into the HDMI port of a HDMI sink device (e.g. a monitor). Step4. Plug DC 5V power adapters to the USB ports of both MP-HDFB-4KT and the MP-HDFB-4KR. Note: Connect MP-HDFB-4KT/ MP-HDFB-4KR with HDMI source/ sink directly or...
- Page 6 4K Optical Fiber Extender Specification Model MP-HDFB-4KT MP-HDFB-4KR Spec Input Input Signal 1 HDMI 1 Optical Fiber Input Connector 19-pin Type A male HDMI LC connector Signal HDMI1.4 Optical Fiber Output Output 1 Optical Fiber 1 HDMI Output Connector LC connector...
- Page 7 4K Optical Fiber Extender Troubleshooting & Maintenance Problems Causes Solutions Color losing or vague/ Poor quality of the HDMI double image in HDMI Change for qualified cable. cable (if used) display Not been powered Power up the unit Power led isoff, operations Make sure power adapter is don’t work Poor contact of USB port...
- Page 8 4K Optical Fiber Extender After-sales Service If there appear some problems when running the device, please check and deal with the problems referring to this user manual. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for two years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
