- Page 1 User Manual MP-TP-T70S-H1 18G HDMI 2.0 Extender over CAT5e/6 All Rights Reserved Version: MP-TP-T70S-H1_2020V1.0...
- Page 2 18G HDMI 2.0 Extender over CAT5e/6...
- Page 3 1. Product Introduction The MP-TP-T70S-H1 is a point-to-point HDMI extender set for HDMI V2.0 and IR signals; this kit supports 4K/UHD video @ 60Hz with 4:4:4 Chroma sampling, as well as HDMI data rates up to 18Gbps and HDCP 2.2 compliant. The MP-TP-T70S-H1 provides HDMI transmission up to 230 feet (70 meters) for 4K@60Hz 4:4: 4, or 262 feet (80 meters) for 1080p over single CAT5e/6 cable.
- Page 4 18G HDMI 2.0 Extender over CAT5e/6 2. Panel Description Transmitter Panel Description 1. CAT OUT: Connects to the CAT IN port of receiver by CATx cable. It supports 12V PoC and the transmitter can be powered from the receiver. The green LED illuminates when power is applied.
- Page 5 18G HDMI 2.0 Extender over CAT5e/6 Receiver Panel Description 1. CAT IN: Connects to the CAT OUT port of transmitter by CATx cable. It supports 12V PoC and the receiver can be powered from the transmitter. The green LED illuminates when power is applied.
- Page 6 18G HDMI 2.0 Extender over CAT5e/6 3. Specification Transmitter Input (1) SOURCE Input Connector (1) 19-pin type-A female HDMI Output (1) DISPLAY, (1) CAT OUT Output Connector (1) 19-pin type-A female HDMI, (1) RJ45 Control (1) IR IN, (1) IR OUT, (1) RS232 Control Connector (2) 3.5mm mini jacks, (1) 3-pin terminal block Receiver...
- Page 7 18G HDMI 2.0 Extender over CAT5e/6 Connection Diagram Catx: HDMI: RS232: Receiver IR Emitter 4K TV 4K Blu-Ray Projector Remote Note: ▪ The IR and RS232 commands cannot be triggered simultaneously. ▪ The CATx cable length should not be less than 15 meters for best video output.
- Page 8 18G HDMI 2.0 Extender over CAT5e/6...
