Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM3010T-7PK
ASSEMBLY RATING
Tools Required For Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
Allen Wrench
easy and 5 being difficult). For some
(Included)
products, two persons are recommended.
EASY
DIFFICULT
2 PERSONS RECOMMENDED
Page 1 of 7
Rev: 18-06-21
Advertisement
Related Manuals for Furniture of America CM3010T-7PK
Summary of Contents for Furniture of America CM3010T-7PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3010T-7PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Bolt Ø5/16"x2-3/4" Table Top #B x 8pcs #2 x 4pcs Table Leg Lock Washer Ø5/16"...
- Page 4 Align table legs (#2) to the table top (#1), then secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Page 4 of 7...
- Page 5 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs x 6 #1 x 1pc x 6 Bolt Ø1/4"x3-1/8" Chair Back #B x 4pcs x 6 #2 x 1pc x 6 Cushion Seat Bolt Ø1/4"x2-1/2"...
- Page 6 Insert dowel (#F) to the center hole of the chair back (#1), then align seat (#2) to the chair back (#1). Secure two center holes of the seat (#2) to chair back (#1) by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs...
- Page 7 Align front legs (#3) to the holes of the seat (#2), then secure by using bolts (#B) with washers (#D,E). #B x 4pcs #D x 4pcs #E x 4pcs ASSEMBLY IS COMPLETED Page 7 of 7...
