Summary of Contents for Furniture of America Julia CM3014T
- Page 3 10pcs...
- Page 4 2) Prepare 3 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#B). Align mounting plate (#7) to the holes of the legs (#5) and pedestal (#4). Secure by using bolts (#B). #A x 3pcs #B x 3pcs #D x 6pcs #E x 6pcs 3) Prepare 3 bolts assembly by inserting lock washer (#D), then flat...
- Page 5 Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#A). Align stretcher (#8) to the holes of the pedestal (#4). Secure by using bolts (#A), then cover holes by using wooden plug (#G). Prepare 8 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C).
- Page 6 Prepare 8 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C). Align mounting plate (#7) to the holes of the table top (#1). Secure by using bolts (#C). Turn lever to open.
- Page 7 Extend table (#1), then place leaf (#2). Turn lever to lock. Adjust leveler of the base according to ground level.
