Boreas Reference Manual • Configuring and Monitoring Boreas
Warning Messages
Initialisation restarted - change
in latitude detected
Initialisation restarted - Change
in COG lever arm detected
Warning - Check latitude, value
out of range
Table 25: Coarse Heading Alignment - Warning Messages

9.1.3 Configuration Menu

These menus contain the set of configuration settings for Boreas.

9.1.3.1 Filter Options

Ensure that the filter option is selected for all applications. For most standard applications, the other filter
options can be left at their defaults.
See 8.1 Filter Initialisation
support@advancednavigation.com.
Figure 37: Boreas Web UI Filter Options Page

9.1.3.2 Data Ports

The Data Ports page allows you to specify which data packets or messages are output on a periodic basis and
at what rate via a range of serial and Ethernet ports.
Note: The GPIOs and auxiliary port are configured in the Data Ports page only if they are being used as
serial transmit and receive lines. To configure GPIOs as digital or frequency inputs or outputs, use the
9.1.3.5 GPIO page.
The default ANPP format packets enabled for the primary port are the
and the 11.4.9 Raw Sensors Packet
require. Other ANPP format state packets can be enabled as required.
v1.2
Description
Initialisation has been automatically restarted due to a significant change
in latitude.
Initialisation has been automatically restarted due to a change in the
Centre of Gravity (COG) lever arm configuration.
A discrepancy between the current latitude and the coarse alignment
algorithm has been detected. Check the current latitude is correct.
for more information on these specific settings. If you require assistance, contact
(ID #28) at 20 Hz and these typically provide all the data that a user will
Page 59
11.4.1 System State Packet (ID #20)
11 Oct 2022
