FarmOnline+ Datalink Technical User Guide English For other language variants of this document we refer to: Español Para otras variantes del idioma de este documento, visite: Français Pour les versions dans d'autres langues de ce document veuillez consulter: http://docs.skov.com/1253 604432 • 2022-09-27...
Page 3
The date of change appears from the front and back pages. Note • All rights belong to SKOV A/S. No part of this manual may be reproduced in any manner whatsoever without the expressed written permission of SKOV A/S in each case.
5 Setup ................................ 17 Setup FarmOnline Datalink's internet connection.............. 17 Setup FarmOnline+ Datalink as a device in FarmOnline+ via MySKOV ...... 18 Enter the device key from FarmOnline+ in FarmOnline+ Datalink........ 18 Setup of input sensors on FarmOnline+ Datalink .............. 19 Add location of input sensors in FarmOnline+ ..............
FarmOnline+ Datalink is developed for data collection in various parts of the agricultural industry. This can be automatic collection from input sensors e.g. temperature sensors and/or the user's manual entries of data. The collected data is then made available to the digital service FarmOnline+.
FarmOnline+ Datalink 2 Product survey 131545 FarmOnline+ Datalink EU 131546 FarmOnline+ Datalink CN 131547 FarmOnline+ Datalink AP 131548 FarmOnline+ Datalink NF 131549 FarmOnline+ Datalink LA Inputs (11). Of which 5, where DOL 12 can be connected and 6 where wa- ter meter/feed counter can be connected.
Page 7
FarmOnline+ Datalink 140252 DOL 114 humidity and temperature sensor, 2 m cable 140253 DOL 114 humidity and temperature sensor, 5 m cable The DOL 114 is a dual-purpose temperature and humidity sensor that can be used for monitoring the livestock house relative air humidity and temper- ature.
Page 8
FarmOnline+ Datalink 140333 DOL 18 v2 elec. sub-pressure sensor 100 Pa Sensor for measuring the pressure level in the house. DOL 18 hose set must be ordered separately. 140235 DOL 18 hose set Hose set for DOL 18 electronic sub-pressure sensor.
FarmOnline+ Datalink 3 Mounting guide 3.1 Recommended tools Below is a list of the tools recommended for the installation. Item Description Crosshead screwdriver Screwdriver straight slot (2 pcs.) Hammer Tape measure Drill kit Cordless drill Spirit level PC with internet connection...
FarmOnline+ Datalink 3.2 Mounting on the wall The FarmOnline+ Datalink must be installed where it is not exposed to frost or direct sunlight. 1. Loosen the screws (A) that hold the front panel in place. 2. Lift out the front panel.
Page 11
FarmOnline+ Datalink 43 CM 10 CM 1. Place the display (D) at eye level for the daily user. 2. Remember free space: - above the cabinet (43 cm), so that the front panel can be placed on top of the cabinet base (E) during ser- vicing.
FarmOnline+ Datalink 4 Installation guide The FarmOnline+ Datalink must be connected to cables for input sensors power supply and any Ethernet net- work. 4.1 Electrical connection Installation, servicing and troubleshooting of all electrical equipment must be carried out by quali- fied personnel in compliance with the applicable national and international standard EN 60204-1 and any other EU standards that are applicable in Europe.
FarmOnline+ Datalink 4.3 Connection of external antenna In order to ensure optimum conditions as regards quality and stability of the connection, it is important to comply with all requirements as well as specifications. At mounting, it should be ensured that: •...
FarmOnline+ Datalink 4.4 Connection of input sensors The FarmOnline+ Datalink can be connected to up to 11 input sensors of the following type: Input sensor Limit value (gives direct data transmission) DOL 114 (humidity) DOL 114 (temperature) 0.5 °C DOL 12 (temperature) 0.5 °C...
Page 15
FarmOnline+ Datalink Figure 3: Connections to main I/O B2-A B2-B B15-A B15-B DOL 12 Water meter Feed counter DOL 114 (Temp & RH) DOL 53 (NH3) DOL 119 (CO2) DOL 16 (LUX) DOL 18 (PA) Table 3: Connection options for each type of input sensor Note that the DOL 12 temperature sensor can only be connected to B4/B5, B7/B8, B9/B10, B17/18 or B20/21.
FarmOnline+ Datalink 4.5 Connection of power supply 1. Run the power cable through a cable gland (A). Make sure that it fits tightly by means of a sealing ring. 2. Connect the wires to the 230 V power supply input L-N-PE (B).
5 Setup 5.1 Setup FarmOnline Datalink's internet connection The FarmOnline+ Datalink´s internet connection must be setup via a wired LAN connection. As a backup, a wireless internet connection can be set up via a 4G modem. See section Connection of network [} 12] and Connection of external antenna [} 13] for cable connection.
• Company setup in MySKOV, loading of license (performed by the supplier). • Farm and associated houses created in MySKOV. 1. Open an Internet browser on a PC and go to MySKOV (my.skov.com). Log in with a user profile that has an Admin role.
FarmOnline+ Datalink 5.4 Setup of input sensors on FarmOnline+ Datalink Press to go to the page for setup of input sensors. Press A Tool to edit, move or delete of an input sensor. B Tool to add a new input sensor.
FarmOnline+ Datalink 5.5 Add location of input sensors in FarmOnline+ 1. Open an Internet browser on a PC and go to MySKOV. 2. Click the (Connection) and select the tab Sensors. All input sensors connected to the datalink are shown here.
The page Settings allows you to set the time and select a device view to suit the geographical location of the FarmOnline+ Datalink. In addition, there is access to resetting the device and to the legal terms of use of it and to information about the software.
FarmOnline+ Datalink 6 User guide 6.1 Batch The Batch page allows you to start and stop a batch and to see and register the number of animals in the house. Press to open the page. Press Batch start. Then select production form (broiler, breeder, pig or layer), stocking date and number of animals.
Page 23
FarmOnline+ Datalink Batch stop (Move out) This happens by all animals being moved out (Move out). Confirm that you want the move the animals out. Historical data on the front page for the finished batch will only be visible until you start a new batch.
FarmOnline+ Datalink 6.2 Input sensors The Sensor page allows you to view registrations from the con- nected input sensors. Press to open the page. Press one of the cards to see registrations for the last 24 hours, 1 week or 1 month.
FarmOnline+ Datalink 7 Maintenance The device requires no maintenance to function correctly. Note that the service life will be extended if it stays connected all the time, as this will keep it dry and free from condensation. Over The Air software update The software of the device is updated automatically over the network.
FarmOnline+ Datalink 8 Troubleshooting instructions General about troubleshooting a wireless system Wireless system errors can normally be divided into two categories: permanent errors and periodical errors. Permanent errors Permanent errors are usually due to the fact that one or several parts of the equipment do not work as intended.
FarmOnline+ Datalink 9 Technical data Electrical V AC Rated voltage 115, 200 and 230/240 V AC Operating voltage 103.5-264 Frequency 50/60 Output Max. power consumption Main module 0-10 V input 0-10 V input 0-10 V input (2) 0-10 V output (2) Outputs/power supply: 2 x 15 V DC power supply +/- 10 % max.
