Ice container
G
Open the door of the compartment and then lift the container.
When installing the container, ensure the bottom of the container aligns with the
compartment frame.
Containers for small and large items
H
Open the door of the compartment, and remove
1
the container for small items.
Caution The container for slim items cannot be removed.
Container for slim items
Container for small items
When installing the container for large items, insert the tabs on the left and right sides of the container into the rectangular sockets in the frame.
Similarly, when installing the container for small items, ensure the left and right tabs of the align outside the container for large items.
Attach the accessory case with the word "REAR" in the back side. If it is not set correctly, it may cause abnormal noise at opening and
closing, as well as cause the half opening door.
Pull the compartment out all the way. Then, holding
1
both sides of the compartment, lift it slightly and then
slowly pull it out so that the front of the compartment
rests on the floor.
Rectangular sockets
in the frame
When opening the compartment, be careful not to get your feet caught between the
CAUTION
compartment and the floor.
Water might drip from behind the lower container.
Incorrect installation of the containers or partition might cause the compartment to make strange sounds when it is
opened and closed or might prevent the compartment from being closed completely.
Incorrect installation of the upper container might damage the container or other
NOTE
parts of the refrigerator.
After installing the upper container, slide it in and out a few times to ensure it is installed
correctly.

Drawer doors

(ice compartment, upper and lower freezer compartments, and vegetable compartment)
Ice compartment and upper freezer compartment
and upper freezer container
(ice compartment)
Left and right tabs
Left and right tabs
Rectangular
sockets in
the frame
Upper and lower containers
I
2
Left and right tabs
Frame
Bottom of
the container
Frame
(lower freezer compartment)
Lift up the Lower freezer case.
2
Container for
large items
Frame
(vegetable compartment)
Lift and remove the upper
container.
Upper container
Lower freezer compartment and vegetable compartment
(upper freezer compartment)
Back
REAR
Front
Remove the lower container by pulling it
3
forward and up.
Caution
The partition cannot be removed.
Lower
container
Frame
REAR
63
