請務必詳閱「安全上之注意事項」。 請妥善保管本使用說明書與保証書。如將電冰箱 交給他人在別的場所使用或者交給回收工廠,請 將本使用說明書隨電冰箱一同轉交。 Thank you for purchasing a Hitachi refrigerator. This refrigerator is designed for home use only. Do not use this refrigerator for commercial use or for any purpose other than storing food. Please read this manual to ensure correct usage and safety.
Page 2
節省能源的使用方法 Energy-saving tips 1. 減少冰箱門的開閉,且開門時間切勿過長 開閉次數多,冷氣向外流失,保冷效果差。 2. 切勿塞滿過多的食物 如果塞滿過多的食物,冷氣循環不良,不僅無法讓冰箱內均一冷卻,而且還會消耗電力。存放食物時請保留適度的間隙。 3. 將熱的食物放冷之後再放入冰箱 如果將熱的食物放入冰箱,冰箱內部的溫度升高,周邊食物的溫度也會隨之升高。 4. 冰箱周邊應保留適當的間隙 如果周邊不留間隙,冰箱將無法散熱,造成電力浪費。 5. 更換受損的冰箱門墊圈 墊圈受損後所產生的間隙可使冷氣流失,造成電力浪費。如要檢查墊圈是否受損, 可將名片等夾在冰箱門之間, 如果名片滑落, 說明冰箱門無法夾緊,請更換墊圈。 1. Minimize how frequently you open refrigerator doors and how long doors are kept open. 2. Do not store too much food in the refrigerator. Leave space between items in the refrigerator. Storing too much food in the refrigerator prevents the circulation of cold air, leading to uneven cooling and increased energy consumption.
Page 37
CONTENTS SAVING ENERGY ・・・・・・・・・・・・・・・・・・・・・・・・・・・ BEFORE USE ・・・・・・・・・・・・・・・・・・・ Using “Energy Saving” mode ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・ SAFETY PRECAUTIONS “eco” indicator ・・・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ BEFORE USE “Door” indicator ・・・・・・・・・・・・・・・・・・・・・ Setting up the refrigerator MAINTENANCE ・・・・・・・・・・・・・・・・・・・・ PARTS AND FUNCTIONS Name of each compartment, temperature guide, MAINTENANCE ・・・・・・・・・・・・・・・・・・・・・・・・・・・・...
SAFETY PRECAUTIONS Be sure to follow these precautions. Failure to follow these safety precautions might result in injury or damage to property. ■The following labels are used to indicate the severity of ■The following symbols are used to injury or damage that might result if precautions are ignored. indicate actions that are prohibited and those that are required.
Page 39
WARNING Power cord and power source Ensure your hands are dry Unplug the power cord before you handle the power cord. before performing ・Handling the power cord with wet maintenance on the hands might result in electric shock. refrigerator. Performing maintenance while the This appliance can be used by children aged from 8 power cord is plugged...
Page 40
Handling, service and installation of used the symbol on the left from the compressor flammable refrigerant shall be done by or the refrigerator. Hitachi authorized service companies or service engineer only. In case of emergency If the refrigerator is Do not disassemble, repair, or modify malfunctioning, unplug it.
Page 41
CAUTION Moving the refrigerator Do not move the refrigerator by using its When moving the refrigerator, wheels, as this might damage the floor. grasp the handles for moving ・Lay a protective sheet or cloth along the the refrigerator. path where the refrigerator will be moved, If you hold other parts of the to prevent the floor from being damaged.
BEFORE USE Setting up the refrigerator Choose a location for the refrigerator. Ensure the floor is sturdy and level. Leave space around the refrigerator for ventilation. If the refrigerator is to be placed on a surface that might deform or (See the figure on the right.) At least 5 cm above At least 5 cm above...
Page 43
Clean the interior of the refrigerator. P.59-61 Wipe down the interior surfaces of the refrigerator by using a wet sponge or dishcloth, and then dry the interior surfaces by using a paper towel or dry dishcloth. Wash the water supply tank and water filter. Notes: 1.
PARTS AND FUNCTIONS Name of each compartment, temperature guide, and examples of stored food P.46 Refrigerator compartment P.48 Vacuum compartment Shelf: About 2˚C to 6˚C Pocket: About 2˚C to 9˚C About -2˚C to 0˚C Daily foods Vienna sausage Milk Ice compartment Vegetable compartment P.50 P.54...
Functions of the control panel The control panel consists of a display area and buttons for operating the control panel. The control panel display is normally off, and can be turned on by touching the button. Touch the buttons for operating the control panel to change the settings of the refrigerator. Information area P.58 Indicates that the refrigerator is running in eco mode.
REFRIGERATOR COMPARTMENT Refrigerator compartment Parts Cold air vent Interior LED light Upper and middle Height-adjustable shelf height-adjustable shelves Shelf (fixed) Lower height-adjustable shelf Egg Stand Shelf (fixed) Double shelf Handle Do not place foods with high water content or canned drinks directly in front of the cold air vent, as they might freeze or rupture, REQUEST especially if the temperature setting is set to “...
Adjusting the temperature of the refrigerator compartment In general, leave the setting on “■■” . In summer or during other warm periods, if the refrigerator is not sufficiently cold, change the temperature setting to “■■■” . Touch on the control panel to activate the control panel. Temperature guide for All indicators turn on, and then some will turn off to reflect the current settings.
VACUUM COMPARTMENT Vacuum compartment LED light Lights up the vacuum compartment when the Handle refrigerator doors are open. Vacuum pump Vacuum release valve (blue) Lift the handle to unlock the valve and Vacuum compartment release the vacuum. You might hear a (with aluminum tray) hissing sound as air enters the compartment.
Changing the vacuum compartment setting Touch button on the Control Panel to turn on the indicator lamp. All indicator lamps turn on, and then the current settings are displayed. Touch button to change the settings as you like. The display switches in sequence as shown below every time the button is touched. The temperature is set to “On”...
ICE COMPARTMENT (Automatic ice maker) Ice compartment Water supply tank Control panel (Holds about 1.0 liter) Display fill line Making button Ice container Max fill line “Water Supply” indicator lamp Automatic ice maker Store ice here Ice scoop Automatic (Keep the ice scoop here when you are not ice maker using it.) Ice compartment...
Amount of ice that can be stored and time required to make ice Model R-HWS480K type Storable amount When ice cubes are level About 140 ice cubes Set to “On” Time required to About 110 minutes to 140 minutes make 12 ice cubes Set to “Quick”...
FREEZER COMPARTMENTS Upper freezer compartment Lower freezer compartment Upper freezer compartment Lower freezer compartment Provides a lot of storage, organized into three easy-to-reach containers. Useful for storing foods used on a daily basis and foods that are partially used. Useful for long-term storage, and for storing ice cream and other foods that melt easily. Container for slim items ※Quick Freezing”...
Adjusting the temperature of the freezer compartments At the time of purchase, the temperature setting of each compartment is set to “■■” . In general, leave the setting on “■■” . In summer or during other warm periods, if the refrigerator is not sufficiently cold, change the temperature setting to “■■■” . Touch on the control panel to activate the control panel.
VEGETABLE COMPARTMENT Vegetable compartment Space for tall items Platinum catalyst case Odor particles and ethylene gas emitted by vegetables are converted into carbon dioxide, helping vegetables stay fresh longer. Upper container Upper container Lower container ※When removing it, remove the partition first. The partition may fall.
Tips for storing vegetables ■Types of food recommended to be kept at room temperature We recommend that the following types of food be kept in a cool location away from direct sunlight: garlic, onion, potatoes, sweet potatoes, squash, and whole (uncut) pumpkins. ■Risk of damage due to low temperatures Some foods might change color or lose flavor if stored in the vegetable compartment for an extended period of time.
VARIOUS FUNCTIONS Detailed temperature adjustment (refrigerator and freezer compartments) You can adjust the temperature settings for the refrigerator and freezer compartments in more detail by selecting from a total of 11 settings. Open the door of the lower freezer compartment. Touch on the control panel to activate the control panel.
Door alarm If a refrigerator door* is left open for more than 1 minute, the refrigerator will emit a warning sound. * The alarm works for doors of the refrigerator compartment, ice compartment, and lower freezer compartment. It does not work for the doors of the upper freezer compartment or vegetable compartment. Duration when door is 1 minute 2 minutes...
SAVING ENERGY Using “Energy Saving” mode To save energy, use “Energy Saving” mode, which lowers the cooling power of each compartment. If “Energy Saving mode is on, and the doors of the refrigerator compartment are left open for more than 30 seconds, the door alarm will sound, and the interior LED lights of the refrigerator compartment and vacuum compartment will dim to save energy.
MAINTENANCE WARNING Unplug the refrigerator before performing maintenance. ■Cleaning the refrigerator Keep the refrigerator clean by wiping away dust, spilled foods, and other residue as soon as you notice them. In addition, we recommend that you perform a detailed cleaning of all parts (including those not visually accessible) at least once a year. Power plug Door gaskets Once or twice a year...
MAINTENANCE (continued) Vacuum compartment Water supply tank Once a month Once a week Remove the vacuum compartment. Remove the water supply Cover tank and its cover. P.62 For details on how to remove the vacuum compartment: Be sure to remove any items stored in the vacuum compartment. Open the tank by removing the cover in Gasket the directions indicated by the arrows.
Cleaning the ice maker Before using the ice maker for the first time or if you have not used the ice maker in over a week. WARNING Do not touch the mechanical parts of the automatic ice maker. (Touching these parts might result in injury.) Wash the ice tray and other parts that come in contact with water.
HOW TO REMOVE/INSTALL PARTS Before removing any part of the refrigerator, remove all items stored in or on the relevant part. CAUTION Do not remove any refrigerator parts other than those listed in this section. To remove or clean parts not listed in this section, contact a customer service center. Do not remove or wash the platinum catalysts in the vacuum compartment and vegetable compartment.
Ice container and upper freezer container (ice compartment) (upper freezer compartment) Open the door of the compartment and then lift the container. Bottom of When installing the container, ensure the bottom of the container aligns with the the container compartment frame. Frame Containers for small and large items (lower freezer compartment)
TROUBLESHOOTING If you experience any problems with the refrigerator, first check the table below and try the suggested solution. Problem Check Solution Please wait. It might take 24 hours or more for the refrigerator to become sufficiently cold. Leave spaces between items stored in the The refrigerator refrigerator, and minimize how frequently you open and close the Have 24 hours passed since the refrigerator was installed?
Page 65
Problem Check Solution The ice maker is turned off. Set the ice maker to “On” or “Quick” . Is the ice maker’ s “Off” indicator on? P.50, 51 The water supply tank needs to be refilled. Refill the water supply Is the “Water” indicator on the control panel on? tank.
Page 66
TROUBLESHOOTING (continued) Problem Check Solution (Checklist) Three or more In the provided checklist, mark ( indicators of the the indicators that are blinking. Then, “Save”, Check each of the six “Fridge” and “Freezer” refrigerator or “Save” contact a customer service center and indicators to see if they are blinking or off.
Problem Check Solution P.49 Is the “Vacuum” setting set to “Off”? Change the setting to “ On”. Is the handle partially raised? Press the handle down firmly to lock the vacuum compartment. If the handle is not secure, a vacuum state cannot be achieved. Push Did you press the handle down firmly to lock the vacuum the vacuum compartment all the way in, and then press the handle compartment?
Page 68
TROUBLESHOOTING (continued) Problem Check Solution This does not indicate any problem in the refrigerator’ s function. There is a plastic The refrigerator has many plastic parts. As the refrigerator get colder, the plastic odor. odor should gradually dissipate. Is the water supply tank or water filter dirty? Have the ice To prevent the accumulation of viscous liquid and the formation of slime or P.60, 61 cubes been sitting in the ice container for a long time?
Page 69
Problem Check Solution I felt an electric shock when You might feel static shock when you touch the refrigerator, but this does not indicate I touched the refrigerator. any problems in its functions or any safety issues. This refrigerator emits electromagnetic radiation. Do not install the refrigerator near TV The refrigerator is interfering with sets, radios, or interphones.
Moving or transporting the refrigerator Remove all items (including ice) stored in Place a piece of cloth below the refrigerator. the drainage outlet*. Tilt the refrigerator backward Dispose of any water in the water supply to drain any water left in tank or ice container.
有關碳氫化合物的冰箱 可容納的食品重量 NOTES ON NON-CFC REFRIGERATORS/GUIDE ON TOTAL STORABLE WEIGHT 有關碳氫化合物的冰箱 有關碳氫化合物的冰箱 Notes on non-CFC refrigerators ● 本冰箱所使用冷媒及其他斷熱材料皆無使用氟氯化碳,而是使用碳氫化合物。碳氫化合物不會破壞地球臭氧層,對地球溫 室效應的影響非常小,屬於環保物質。 ● 碳氫化合物為可燃型物質。冷媒密封於冷媒迴路管中,在一般的使用情況下應該不會發生外洩。 但萬一有冷媒管線損壞的情況發生,請遠離火源及避免使用電器用品,將門窗打開以利空氣流通。之後,請立即與經銷商 或日立技術中心聯絡。 This refrigerator uses hydrocarbons, instead of chloro uorocarbons (CFCs), in its refrigerant and insulation materials. ● Hydrocarbons do not damage the ozone layer, have minimal impact on global warming, and are thus considered comparatively environment-friendly.
AFTER-SALES SERVICE 關於售後服務 Please contact one of the following Hitachi customer service centers if the power cord is damaged or maintenance is required. If the refrigerator malfunctions, immediately unplug the power cord, and contact a customer service center to request repair.
