- Page 1 SQUIRT-R LOOP POWERED INDICATOR INSTRUCTION MANUAL KESSLER-ELLIS PRODUCTS 10 Industrial Way East Eatontown, NJ 07724 800-631-2165 • 732-649-7100 Fax: 732-649-7099 http://www.kep.com 99357 01/14/2021...
-
Page 2: Table Of Contents
INDEX SPECIFICATIONS................1 DIMENSIONS ..................2 TYPICAL WIRING ................2 DEFINITIONS ..................3 PROGRAMMING FLOWCHART ............5 ERROR CODES ................7 BATTERY REPLACEMENT ..............7 DECODING PART NUMBER ............7 WARRANTY ..................7... -
Page 3: Specifications
SPECIFICATIONS Description: INPUTS: Featuring up to 4 1/2 digits of display, the Squirt-R is a loop Signal Input: powered indicator capable of accepting either linear or square Full Scale Range: 4 to 20 mA DC root 4-20 mA inputs. Numeric password protection prevents Loop Voltage Drop: 6 Volts Maximum unauthorized access to the menu. -
Page 4: Dimensions
SQUIRTR-0 SQUIRTR-1 Outside Dotted Line Shows 3.582" Dia. Bolt Circle 1.20 Outside Panel Dimension .125" Holes to be 120° Apart .992 (30.5) (2.54) 1.20 (25.2) (4.00" Diameter) 3.062" (77.77) (30.5) Dia. Cutout 3.0120 DIAMETER Panel .900 (22.8) 2.875 Cutout (73) 2.875 4.00 (73) -
Page 5: Definitions
DEFINITIONS ent code : (enter code) This prompt will only appear if the panel lock is ON. Enter the password code to enter the program menu. Press the ↑ key to increment each digit. Press the ← key to step to the next digit to the left. Press the E key to enter the 4 digit code. If the entered code is correct, the display will advance to the next menu prompt (CLr tot). - Page 6 DEFINITIONS (continued) : (calibrate; yes or no) Select to calibrate the unit, select to skip the calibration procedure. Press the ↑ key to select YES or NO. Press the E key to enter the displayed selection. : (calibrate low) Apply an accurate 4 mA signal to the input and press the E key. If the cal LO DONE cal lo calibration is successful the unit will display "...
-
Page 7: Programming Flowchart
PROGRAMMING FLOWCHART NOTE: All menu selections are saved upon exiting the program menu and returning to the run mode. When making menu changes, do not remove loop power until returning to the run mode. RATE Press the M key to enter the programming menu. RUN MODE TOTAL If panel... - Page 8 PROGRAMMING FLOWCHART (continued) Continued From Previous Page 0000 Press the key to increment each individual digit of the rate low setting. RATE LOW Press the key to advance to the next digit. (4mA) rate LO Press the E key to enter the displayed value. Press the M key to skip and keep the existing value.
-
Page 9: Error Codes
ERROR CODES 0000 This error message is displayed when the "RATE LO" value is set equal to or higher than the "RATE HI" value. Press to re-enter the "RATE LO" and "RATE HI" values. RATE ERR done This error message is displayed when the "CAL LO" or "CAL HI" input is set at a value which is out of range (see "CAL LO"...
