KitchenAid Architect Series II KGCD807X Dimension Manual

PRODUCT MODEL NUMBERS
KGCD807X
GAS SUPPLY REQUIREMENTS
Type of Gas
Natural Gas:
This cooktop is design-certified by CSA International for use with
Natural gas or, after proper conversion, for use with LP gas.
This cooktop is factory set for use with Natural gas. If converting to
LP gas, see the "LP Gas Conversion" instructions provided in the
package containing literature. The model/serial rating plate located on
the underside of the cooktop base has information on the types of
gas that can be used. If the types of gas listed do not include the
type of gas available, check with the local gas supplier.
LP Gas Conversion:
Conversion must be done by a qualified service technician.
No attempt shall be made to convert the cooktop from the gas
specified on the model/serial rating plate for use with a different gas
without consulting the serving gas supplier. See the Gas Conversion
instructions provided in the package containing literature.
Gas Supply Line
Provide a gas supply line of " (1.9 cm) rigid pipe to the cooktop
location. A smaller size pipe on longer runs may result in insufficient
gas supply. Pipe-joint compounds that resist the action of LP gas
must be used. Do not use TEFLON
tubing size should be " minimum. Usually, LP gas suppliers
determine the size and materials used in the system.
Flexible metal appliance connector:
If local codes permit, use a " or
tubing gas connector, designed by CSA to connect the cooktop to
the rigid gas supply line.
†® TEFLON is a registered trademark of E.I. Du Pont De Nemours and
Company.
ELECTRICAL REQUIREMENTS
A 120 volt, 60 Hz, AC only, 15-amp, fused electrical circuit is
required. A time-delay fuse or circuit breaker is also recommended. It
is recommended that a separate circuit serving only this cooktop be
provided.
PRODUCT DIMENSIONS
30" (76.2 cm) Cooktop
A
A. 21 " (54.8 cm) with stainless steel trim or
21½" (54.6 cm) without stainless steel trim
B. 19 " (50.1 cm) screw head to screw head
C. Model/serial rating/clearance plate location
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
30" (76.2 CM) GAS DOWNDRAFT COOKTOP
®† tape. With LP gas, piping or
" I.D. flexible stainless steel
B
C
CUTOUT DIMENSIONS
H
I
J
A. 28 " (72.7 cm) maximum
B. 19 " (50.6 cm) maximum
C. 9 " (21.6 cm)
D. 6 " (17.2 cm)
E. 2 " (5.4 cm) minimum space to front edge of cooktop
F. Floor exhaust option
G. 6 " (15.6 cm) for 6" (15.2 cm) vent system and 5 " (13.1 cm) for
5" (12.7 cm) vent system
H. 9 " (21.6 cm)
I. 13 " (33.9 cm) from the top of the countertop surface
J. Wall exhaust option
D
E
G
A. 29 " (76.1 cm) without
stainless steel trim
B. 30 " (76.3 cm) with
stainless steel trim
C. 12 " (31.6 cm) centerline of
cooktop to centerline of gas
manifold pipe
D. 7 " (18.6 cm)
E. 3 " (9.2 cm)
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
A
D
C
F
G
A
B
C
H
I
J
F. 15" (38.1 cm)
G. 2 " (5.5 cm) recommended
minimum cabinet to motor
clearance
H. 14 " (36.4 cm)
I. 11 " (29.9 cm)
J. " (72.1 cm) screw head to
screw head
B
E
F
Page 1 of 2
Ref. W10305290A
8/25/10
