M240 V4 Series IP
MODEM User Manual
M240 V4 Series IP MODEM
This user manual is suitable for the following model:
Modem
M240-G V4
M240-L V4
M240-L1 V4
M240-LG V4
Add：Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China.
Web: www.yifanwireless.com
M240 V4 Series IP MODEM User Manual
Version
V1.0.0
Product Name:M240 V4
User Manual
Product Type
GPRS IP MODEM
CAT4 LTE IP MODEM
Cat1 IP MODEM
GPS+LTE IP MODEM
Xiamen Yifan Communication Technology Co., Ltd
Add：Floor 14th, No.370, Chengyi Street, Jimei District,
XiaMen, China
Tel：+86 592-6101492
Fax: +86 592-5222813
http://www.yifanwireless.com
Hotline：+86 592 6101492
Total
page36
Zip Code: 361000
Fax：+86 592 5222813
.
1
/ 35
Advertisement
Table of Contents
Related Manuals for Yifan M240 V4 Series
Summary of Contents for Yifan M240 V4 Series
- Page 1 M240 V4 Series IP MODEM User Manual Version M240 V4 Series IP V1.0.0 MODEM User Manual Product Name:M240 V4 Total page36 M240 V4 Series IP MODEM User Manual This user manual is suitable for the following model: Modem Product Type...
- Page 2 M240 V4 Series IP MODEM User Manual Files Revised Record Date Version Remark Author 2021-07-30 V1.0.0 Original / 35 Add：Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China. Web: www.yifanwireless.com Hotline：+86 592 6101492 Fax：+86 592 5222813...
- Page 3 Trademark Notice Yifan and Yeacomm are all registered trademarks of Xiamen Yifan Communication Technology Co., Ltd., illegal use of the name of Yifan, trademarks and other marks of Yifan is forbidden, unless written permission is authorized in advance. / 35 Add：Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China.
- Page 4 M240 V4 Series IP MODEM User Manual Note:There may be different components and interfaces in different model,please in kind prevail. / 35 Add：Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China. Web: www.yifanwireless.com Hotline：+86 592 6101492 Fax：+86 592 5222813...
-
Page 5: Table Of Contents
M240 V4 Series IP MODEM User Manual Contents Chapter 1 Brief Introduction of Product ..................6 1.1General ..........................6 1.2 Features and Benefits ......................7 1.3 Working Principle ......................8 1.4 Specifications ........................8 Chapter 2 Installation Introduction ..................... 10 2.1 General .......................... -
Page 6: Chapter 1 Brief Introduction Of Product
Chapter 1 Brief Introduction of Product 1.1General M240 V4 Series IP MODEM is a kind of cellular terminal device that provides data transfer by public cellular network. It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It... -
Page 7: Features And Benefits
M240 V4 Series IP MODEM User Manual 1.2 Features and Benefits Design for Industrial Application High-powered industrial cellular module High-powered industrial 32 bits CPU Support low power consumption mode, including multi-sleep and trigger modes to reduce the power consumption ... -
Page 8: Working Principle
M240 V4 Series IP MODEM User Manual Working Principle The principle chart of the IP MODEM is showed in Figure 1-2： SRAM& RTC Module FLASH WDT Module Indicator Lights Antenna Cellular RS232/RS485/RS422 Module Module SIM/UIM Interface Power Module User Interface... - Page 9 M240 V4 Series IP MODEM User Manual Note:There may be different components and interfaces in different model,please in kind prevail. Power Input Item Content Standard DC 12V/0.5A Power Range DC 5~36V Power Consumption （ Communication power consumption differs from different modules）...
-
Page 10: Chapter 2 Installation Introduction
M240 V4 Series IP MODEM User Manual Chapter 2 Installation Introduction 2.1 General The IP MODEM must be installed correctly to make it work properly. Warning: Forbid to install the IP MODEM when powered! 2.2 Encasement List Name Quantity Remark... - Page 11 M240 V4 Series IP MODEM User Manual sheath (Pay attention to put the side which has metal point outside), and insert card sheath back to the SIM/UIM card outlet. Warning: Forbid to install SIM/UIM card when powered! Installation of antenna Screw the SMA male pin of the antenna to the female SMA outlet of the IP MODEM tightly.
-
Page 12: Power
M240 V4 Series IP MODEM User Manual Installation of cable M240 V4 adopts industrial terminal block interface, the recommendatory cable is 28-16AWG. Adapter（Rating Output 12VDC/0.5A） Cable Color Power Output Polarity Black&White Anode Black(with letters) Cathode RS232 Cable Cable Color DB9-M Pin Number... -
Page 13: Indicator Lights Introduction
M240 V4 Series IP MODEM User Manual 2.5 Indicator Lights Introduction The IP MODEM provides three indicator lights: “Power”, “ACT”, “Online”. Indicator Status Introduction Power IP MODEM is powered off IP MODEM is powered on No data communication Blink Data is communicating IP MODEM hasn’t logged on network... -
Page 14: Chapter 3 Configuration
M240 V4 Series IP MODEM User Manual Chapter 3 Configuration 3.1 Connection Before configuration, It’s necessary to connect the IP MODEM with the PC by the shipped RS232 or RS232-485 conversion cable as following. 3.2 Configuration Introduction There are two ways to configure the IP MODEM: Configuration software tool: All the settings are configured through the shipped software tool. -
Page 15: Ip Modem's Parameters Configuration
M240 V4 Series IP MODEM User Manual 3.3 IP Modem’s Parameters Configuration There are data settings in HEX format in the parameters, for the HEX format, the data must be hexadecimal characters, and the number of characters cannot be an odd number. -
Page 16: Re-Power Ip Modem
M240 V4 Series IP MODEM User Manual 3.3.2 Re-Power IP Modem After Re-power IP MODEM, The configure tool will make it enter configure state. At the same time, the software will load current settings from IP MODEM and displays on the right configure columns. - Page 17 M240 V4 Series IP MODEM User Manual Device ID ID number for the device. 8 characters Phone No. Phone number Character This item is only valid when the Work Mode is PROT. If this item is set Escapes to No, IP MODEM will transfer meaning to 0xfd and 0xfe. To know detail transfer meaning method, please refer “IP MODEM Transfer Meaning...
- Page 18 M240 V4 Series IP MODEM User Manual SMS from the binding phone number will send to Serial port. Pone No 1st Group Bind phone number. Max phone number is 5 for one group Pone No 2nd Group Pone No 3rd Group...
- Page 19 M240 V4 Series IP MODEM User Manual HTTP Request Mode Can select GET and POST Mode MTCP/MRTU IP MODEM will convert data from Modbus TCP to modbus RTU when recieve data from server,also will convert data from Modbus RTU to Modbus TCP when sending data to server via the serial port in device.
- Page 20 M240 V4 Series IP MODEM User Manual password Receive Topic It should be configured with the send topic of another client Send Topic It should be configured with the recieve topic of another client Custom protocol：Client mode It support TCP and UDP protocol with custom heart and login packet.
- Page 21 M240 V4 Series IP MODEM User Manual software can makes IP MODEM into sleep state in idle time. When there is application data to transmit, IP MODEM can be triggered online ready for data transmission. There are total five methods to make IP MODEM online.
- Page 22 M240 V4 Series IP MODEM User Manual Data Trigger On If it was empty, any data form serial can trigger the IP Modem. The first frame data will be discarded because the IP modem was in deep sleep state. If it is not empty, only the data matching to the “online data” can trigger the IP Modem.
-
Page 23: Data Service Center Settings
M240 V4 Series IP MODEM User Manual CALL Phone No. Any phone number call can wake up IP Modem, if the trigger number is empty. Otherwise only the trigger phone number call can trigger the IP Modem. Any phone number’s SMS can wake up IP Modem, if the trigger SMS Phone No. - Page 24 M240 V4 Series IP MODEM User Manual 3.4.1 Data Service Center IP MODEM support two Data Service Center methods to transmit data. Main and Backup: IP MODEM always tries to connect with the Main DSC. If fails to connect with Main DSC, it will connect with Backup DSC at once Note：If no Backup DSC exists, please configure the Backup DSC same as Main DSC.
- Page 25 M240 V4 Series IP MODEM User Manual 3.4.2 Multi-Center Connection Check This item is valid only when the “Data Center Number” is greater than 1. When one of the configured data center lost connection, IP MODEM will try to reconnect after the configured reconnect interval Reconnect Int.(s)
-
Page 26: Serial Port
M240 V4 Series IP MODEM User Manual 3.5 Serial port IP MODEM support two individual serial ports, RS232 and RS485. All the three ports can enter configuration state. The default parameters of the port with baudrate 115200, data property 8N1 The data from the three port can bind to Data center. -
Page 27: Io Function
M240 V4 Series IP MODEM User Manual Close: send to none RS485 Same as above 3.6 IO function IP MODEM support 3 digital I/O and 2 Analog input,can custom data string to query data or trigger IO state. 3.6.1 Digital I/O... -
Page 28: Dial
M240 V4 Series IP MODEM User Manual 3.6.2 Analog Input Disable or enable ADC Port support COM/GPRS/ SMS ADC type Electricity:support 4~20MA current input Voltage:support 0~5V,can customize to support 10V/15V Report Type Query/Time/IO Trigger Top Limit Sensor measurement range upper limit... - Page 29 M240 V4 Series IP MODEM User Manual PPP Auth AUTO,PAP and CHAP QueryNetMode Search the network mode for the 4G network Net Mode Net Mode AUTO EVDO WCDMA TD-SCDMA CDMA 3.7.2 PPP Redial Re-dial Interval(s) The interval between ppp dial in second...
-
Page 30: Global Parameters
M240 V4 Series IP MODEM User Manual 3.8 Global Parameters 3.8.1 Data Frame Parameters Bytes Interval(MS) The time interval used to determine whether the serial data frame transmission has completed, IP MODEM will send the serial data to the center when two bytes transmit time interval larger than this item value.(in milliseconds) -
Page 31: Device Manage
M240 V4 Series IP MODEM User Manual 3.9 Device Manage 3.9.1 Device Manage Center Parameters The IP Modem send device status information to the Device Manage Center. The information include network signal, network status, traffic flow and so on. The Device Manage Center also query and configure the device parameters. -
Page 32: Operation
M240 V4 Series IP MODEM User Manual 3.10 Operation SIM Check To check if simcard inserted or install ok? Signal Inquery the signal strength of simcard network Time Setting Synchronize local time Read log information of IP Modem Factory the IP Modem’s parameters... -
Page 33: Chapter 4 Application Case
M240 V4 Series IP MODEM User Manual Chapter 4 Application Case 4.1 Modem connect to data center In this application,the client can communicate with the server side by gprs network. IP modem configuration Configure server IP and port： Fill in the APN from your simcard provider: Repower modem,wait it connected to server. -
Page 34: Sms To Configure Modem
M240 V4 Series IP MODEM User Manual 4.2 SMS to Configure Modem You can send SMS to configure modem via mobile phone Step one Enable SMS Manage function in modem：set SMS sender's phone number，the password is the one set in the modem.it can be digit or letter. - Page 35 M240 V4 Series IP MODEM User Manual If set succesfully,you will receive a return SMS with Config OK： 35 / 35 Add：Floor 14,A06 building, No.370,Chengyi Street,Jimei District, Xiamen,China. Web: www.yifanwireless.com Hotline：+86 592 6101492 Fax：+86 592 5222813...
