M260 Series IP MODEM User Manual
The user manual is suitable for the following model:
Document Version
V2.0.0
Product Name：M260
Model
M260-G
GPRS IP MODEM
M260-H
WCDMA IP MODEM
M260-EV
EVDO IP MODEM
M260-L
LTE IP MODEM
Limited.
Yifan Industry
Add：Room 618, No.12,Gaodian Road, HuLi District,
XiaMen, China
Tel：+86 592-6101492
Fax: +86 592-5222813
http://www.yifanwireless.com
Product Type
Zip Code: 361000
Page
Total:35
Advertisement
Table of Contents
Related Manuals for Yifan M260 Series
Summary of Contents for Yifan M260 Series
- Page 1 Document Version Page M260 Series IP MODEM User V2.0.0 Manual Product Name：M260 Total:35 M260 Series IP MODEM User Manual The user manual is suitable for the following model: Model Product Type M260-G GPRS IP MODEM M260-H WCDMA IP MODEM M260-EV...
- Page 2 M260 Series IP MODEM User Manual Files Revised Record Date Version Remark Author 2016.6.1 V1.0.0 build 1 modify the baud rate description 2017.1.9 V1.0.1 2 add network mode setting 2017.1.9 V1.0.2 1 delete some useless function 2017.10.10 V2.0.0 Change of company address Yifan Industry Co., Ltd.
- Page 3 Yifan Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Yifan are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
-
Page 4: Table Of Contents
M260 Series IP MODEM User Manual Contents Contents Chapter 1 Brief Introduction of Product..................... 5 1.1 General..........................5 1.2 Features and Benefits......................5 1.3 Working Principle........................6 1.4 Specifications........................7 Chapter 2 Installation Introduction....................10 2.1 General..........................10 2.2 Encasement List........................10 2.3 Installation and Cable Connection.................. -
Page 5: Chapter 1 Brief Introduction Of Product
Chapter 1 Brief Introduction of Product 1.1 General M260 series IP MODEM is a kind of cellular terminal device that provides data transfer by public cellular network. It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It... -
Page 6: Working Principle
M260 Series IP MODEM User Manual Power range: DC 5~36V Stability and Reliability Support hardware and software WDT Support auto recovery mechanism, including online detect, auto redial when offline to make it always online RS232/RS485/RS422 port: 15KV ESD protection ... -
Page 7: Specifications
M260 Series IP MODEM User Manual SRAM& RTC Module FLASH WDT Module Indicator Lights Antenna Cellular RS232/RS485/RS422 Module Module SIM/UIM Interface Power Module User Interface Figure1-2 IP Modem principle chart 1.4 Specifications Cellular Specification Item Content M260-G GPRS IP MODEM... - Page 8 M260 Series IP MODEM User Manual CDMA2000 1X RTT, IS-95 A/B EVDO Rev. A: Download speed 3.1Mbps, Upload speed 1.8Mbps Bandwidth EVDO Rev. B: Download speed 14.7Mbps, Upload speed 5.4Mbps (optional) <23dBm TX power <-104dBm RX sensitivity M260-L LTE IP MODEM...
- Page 9 M260 Series IP MODEM User Manual Terminal Block Antenna SIM/UIM Port Interface Note: There may be different components and interfaces in different model,please in kind prevail. Power Input Item Content Standard Power DC 12V/0.5A Power Range DC 5~36V Power Consumption...
-
Page 10: Chapter 2 Installation Introduction
M260 Series IP MODEM User Manual Chapter 2 Installation Introduction 2.1 General The IP MODEM must be installed correctly to make it work properly. Warning: Forbid to install the IP MODEM when powered! 2.2 Encasement List Name Quantity Remark IP MODEM host... - Page 11 M260 Series IP MODEM User Manual Installation of SIM/UIM card: Firstly power off the IP MODEM, and press the out button of the SIM/UIM card outlet with a needle object. Then the SIM/UIM card sheath will flick out at once. Put SIM/UIM card into the card sheath (Pay attention to put the side which has metal point outside), and insert card sheath back to the SIM/UIM card outlet.
-
Page 12: Power
M260 Series IP MODEM User Manual Installation of cable: M260 adopts industrial terminal block interface. The recommendatory cable is 28-16AWG. The detail description of standard layout adapter and communication cables as is following: Adapter（Rating Output 12VDC/0.5A） ： Cable Color Power Output Polarity Black &White Alternate... -
Page 13: Indicator Lights Introduction
M260 Series IP MODEM User Manual above 4W. We recommend user to use the standard DC 12V/0.5A power adaptor. 2.5 Indicator Lights Introduction The IP MODEM provides three indicator lights: “Power”, “ACT”, “Online”. Indicator State Introduction Light Power IP MODEM is powered on... -
Page 14: Chapter 3 Configuration
M260 Series IP MODEM User Manual Chapter 3 Configuration 3.1 Configuration Connection Before configuration, It’s necessary to connect the IP MODEM with the configure PC by the shipped RS232 or RS232-485 conversion cable as following. 3.2 Configuration Introduction There are two ways to configure the IP MODEM: Configuration software tool: All the settings are configured through the shipped software tool. -
Page 15: Ip Modem's Parameters Configuration
M260 Series IP MODEM User Manual 3.3 IP Modem’s Parameters Configuration 3.3.1 Run the Configure Tools The “Serial” area shows the current serial port settings. To configure IP MODEM, please choose the correct serial port which connects to IP MODEM, and the baud-rate is 115200 with no parity, then open the serial port. -
Page 16: Re-Power Ip Modem
M260 Series IP MODEM User Manual 3.3.2 Re-Power IP Modem After Re-power IP MODEM, The configure tool will make it enter configure state. At the same time, the software will load current settings from IP MODEM and displays on the right configure columns. - Page 17 M260 Series IP MODEM User Manual PhoneNo. Phone number Transfer Meaning This item is only valid when the WorkMode is PROT. If this item is set to 0, IP MODEM will transfer meaning to 0xfd and 0xfe. To know detail transfer meaning method, please refer “IP MODEM Transfer Meaning...
- Page 18 M260 Series IP MODEM User Manual Pone No 1st Group Bind phone number. Max phone number is 5 for one group Pone No 2nd Group Pone No 3rd Group Pone No 4th Group Show Phone Number If send phone number to serial port or not...
- Page 19 M260 Series IP MODEM User Manual Base Protocol TCP or UDP DeviceMode Client Mode: the IP Modem work as a client. Login&Heartbeat Enable: custom login and heart packet Disable: no login and heart packet. The flowing items can be ignored.
- Page 20 M260 Series IP MODEM User Manual methods to make IP MODEM online. AUTO IP MODEM always keeps online SMSD send a special short message to make IP MODEM online. Any phone number’s SMS can wake up IP Modem, if the trigger number is empty. Otherwise only the trigger phone number’s SMS can trigger the IP Modem.
- Page 21 M260 Series IP MODEM User Manual Data Trigger On If it was empty, any data form serial can trigger the IP Modem. The first frame data will be discarded because the IP modem was in deep sleep state. If it is not empty, only the data matching to the “online data” can trigger the IP Modem.
- Page 22 M260 Series IP MODEM User Manual CALL Phone No. Any phone number call can wake up IP Modem, if the trigger number is empty. Otherwise only the trigger phone number call can trigger the IP Modem. Any phone number’s SMS can wake up IP Modem, if the trigger SMS Phone No.
-
Page 23: Data Service Center Settings
M260 Series IP MODEM User Manual 3.3.4 Data Service Center Settings Settings on this page are the parameters related to Data Service Center (DSC). 3.3.4.1 Data Service Center IP MODEM support two Data Service Center methods to transmit data. Main and Backup: IP MODEM always tries to connect with the Main DSC. If fails to connect with Main DSC, it will connect with Backup DSC at once Note：If no Backup DSC exists, please configure the Backup DSC same as Main DSC. - Page 24 M260 Series IP MODEM User Manual data. 3.3.4.2 Multi-Center Connection Check This item is valid only when the “Data Center Number” is greater than 1. When one of the configured data center lost connection, IP MODEM will try to reconnect after the configured reconnect interval Reconnect Int.(s)
-
Page 25: Serial Port
M260 Series IP MODEM User Manual Check Times >= 3 times 3.3.5 Serial port IP MODEM support three individual serial ports, Port1, Port2 and RS485. All the three ports can enter configuration state. The default parameters of the port with baudrate 115200, data property 8N1 The data from the three port can bind to Data center. -
Page 26: Dial
M260 Series IP MODEM User Manual 8N1 --- 8 Databit, No parity, 1 Stopbit 8E1 --- 8 Databit, Even parity, 1 Stopbit 8O1 --- 8 Databit, Odd parity, 1 Stopbit Bind： Center1: the data from the port send to center 1... - Page 27 M260 Series IP MODEM User Manual Network User name/password GPRS/WCDMA/ empty Username/password CDMA/EVDO card/card PPP Auth AUTO,PAP and CHAP QueryNetMode Search the network mode for the 4G network Net Mode Net Mode AUTO EVDO WCDMA TD-SCDMA CDMA 3.3.6.2 PPP Redial...
-
Page 28: Global Parameters
M260 Series IP MODEM User Manual 3.3.7 Global Parameters 3.3.7.1 PPP Link Check PPP Link Check adopt LCP echo method to check the link status. Once the check failure’s times meet the max times. The IP Modem will re-dial. Lcp Echo... -
Page 29: Device Manage
M260 Series IP MODEM User Manual 3.3.8 Device Manage 3.3.8.1 Device Manage Center Parameters The IP Modem send device status information to the Device Manage Center. The information include network signal, network status, traffic flow and so on. The Device Manage Center also query and configure the device parameters. -
Page 30: Miscellaneous
M260 Series IP MODEM User Manual 3.3.9 Miscellaneous Login Enter configuration state while IP Modem normal work. Send parameters to IP Modem WriteParam Read All parameters of IP Modem ReadParam Read log information of IP Modem ReadLog Factory the IP Modem’s parameters... -
Page 31: Appendix
M260 Series IP MODEM User Manual Appendix The following steps describe how to make IP MODEM enter configure state with the Windows XP Hyper Terminal. 1. Press “Start””Programs””Accessories””Communications””Hyper Terminal” 2. Input connection name, choose “OK” 3. Choose the correct COM port which connect to IP MODEM, choose “OK”... - Page 32 M260 Series IP MODEM User Manual Bits per second: 115200 Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Re-power IP MODEM, put mouse focus on the Hyper Terminal and press “s” key continuously until IP MODEM enter configure state as following Yifan Industry Co., Ltd.
- Page 33 M260 Series IP MODEM User Manual 7. IP MODEM has entered configure state, you can configure the parameters through AT command. Yifan Industry Co., Ltd. Page 33 of 33 Tel: +86 592 6101492 Fax:+86 592 5222813 Email: admin@yifanwireless.com , admin@yi-fan.com.cn...
