取扱説明書&操作方法 ENGLISH DUAL FUEL GENERATOR JAPANESE CHAMPION GENERATOR 5500W SAVE THESE INSTRUCTIONS Important Safety Instructions are included in this manual. 本取扱説明書は大切に保管してください。 安全に関する重要な事項が記載されています。...
Page 3
Record the model and serial numbers as well as date and place of purchase for future reference. Have this information available when ordering parts and when making technical or warranty inquiries. Champion Power Equipment Support Model Number CPG5500E2DF-J...
MANUAL CONVENTIONS Please familiarize yourself with the following symbols. The safety symbol and key words are safety warnings. Follow all safety messages to avoid accidents or injury. DANGER CAUTION DANGER indicates an imminently hazardous CAUTION used without the safety alert symbol situation which, if not avoided, will result in death indicates a potentially hazardous situation which, if or serious injury.
SAFETy RULES WARNING DANGER Generator produces powerful voltage. Read this manual thoroughly before operating your generator. Failure to follow instructions could result DO NOT touch bare wires or receptacles. in serious injury or death. DO NOT use electrical cords that are worn, damaged or frayed.
Page 6
SAFETy RULES WARNING CAUTION Rapid retraction of the starter cord will pull hand and Improper treatment or use of the generator can arm towards the engine faster than you can let go. damage it, shorten its life and void your warranty. Unintentional startup can result in entanglement, traumatic amputation or laceration.
Page 7
SAFETy RULES Fuel Safety When adding or removing Petrol: Turn the generator off and let it cool for at least two DANGER minutes before removing the fuel cap. Loosen the cap slowly to relieve pressure in the tank. PETROL, PETROL VAPOURS AND LIQUID Only fill or drain fuel outdoors in a well-ventilated area.
Page 8
ASSEMBLy Install the Support Leg Your generator requires some assembly. This unit ships from our factory without oil. It must be properly serviced 1. Attach the support leg to the generator frame with with fuel and oil before operation. flange bolt and flange lock nuts. If you have any questions regarding the assembly of your 2.
Page 9
ASSEMBLy Add Engine Oil Add Engine Oil Cont’d. CAUTION NOTE Check oil often during the break-in period. Refer to the DO NOT attempt to crank or start the engine before Maintenance section for recommended service intervals. it has been properly filled with the recommended type and amount of oil.
Page 10
ASSEMBLy Add Fuel (Petrol) Add Fuel (Petrol) Cont’d. 1. Use clean, fresh, regular unleaded fuel. WARNING 2. DO NOT mix oil with fuel. 3. Clean the area around the fuel cap. Pouring fuel too fast through the fuel screen may 4.
Page 11
ASSEMBLy Connecting Liquid Petroleum Gas (LPG) Cylinder Connecting LPG Cylinder Cont’d. 1. Make sure the fuel valve on the generator is in the off CAUTION position. 2. Attach the LPG hose (included) to the LPG hose Do not allow children to tamper or play with the connector on the side of the generator and tighten cylinder or hose connections.
Page 12
ASSEMBLy Generator Location Grounding Never operate the generator inside any building! (See The generator system ground connects the frame to the safety warnings section). In some areas generators must ground terminals on the power panel. The system ground is be registered with the local utility company. Generators connected to the AC neutral wire.
OPERATION Fuel Selector Switch Dual Frequency Operation Guide The fuel selector switch on the front panel of the 1. Turn the frequency switch to your selected option generator is designed specifically to choose between the before start the generator. (As Decal shows on the top fuel source desired, Petrol or LPG.
Page 14
OPERATION Starting the Engine Cont’d. Starting the Engine Cont’d. 11. PULL-TO-PRIME: Pull the starter cord slowly until NOTE resistance is felt and then pull rapidly. Pull with For restarts with hot engine in hot ambient > 30°C “100% Choke” 1-2 times until you feel a few (86°F) keep choke lever in “75% Choke”...
Page 15
OPERATION Starting the Engine Cont’d. Stopping the Engine Cont’d. NOTE NOTE Observing frost on LPG containers and regulators When turning off the generator after LPG operation, make is common during operation and normally is not sure the LPG cylinder knob is in the fully closed position. an indication of a problem.
Page 16
OPERATION Do Not Overload Generator Capacity Follow these simple steps to calculate the running and starting watts necessary for your purposes. 1. Select the electrical devices you plan on running at the same time. 2. Total the running watts of these items. This is the amount of power you need to keep your items running.
MAINTENANCE AND STORAGE The owner/operator is responsible for all periodic Oil Cont’d. maintenance. NOTE WARNING Once oil has been added, a visual check should show oil about 1-2 threads from running out of the fill hole. Never operate a damaged or defective generator. If using the dipstick to check oil level, DO NOT screw in the dipstick while checking.
Page 18
Replace fuel line and LPG hose Adjustments *To be performed by knowledgeable, experienced owners or Champion Power Equipment certified dealers. The air-fuel mixture is not adjustable. Tampering with the governor can damage your generator and your Generator Maintenance electrical devices and will void your warranty.
Page 19
MAINTENANCE AND STORAGE Storage Generator Battery The generator should be started at least once every 14 This product is equipped with an automatic battery days and allowed to run for at least 20 minutes. For charging circuit. The battery will receive charging longer term storage, please follow these guidelines.
TROUBLESHOOTING No fuel Add fuel Generator will not start Faulty spark plug Replace spark plug Unit loaded during start up Remove load from unit Fill crankcase to the proper level Low oil level Place generator on a flat, level surface Generator will not start;...
SPECIFICATIONS PARTS LIST # Part Number Description # Part Number Description 122.070100.07 Fuel Tank Cap 2.03.040 Washer 8 x 24 x 3 Ø Ø 122.070300.03 Fuel Filter 1.93.08 Lock Washer 8 Ø 24.070800.00 Reversal Valve 1.5789.0835 Flange Bolt M8 x 35 2.06.006 Clamp, 7 x 1 Ø...
SPECIFICATIONS ENGINE PARTS LIST # Part Number Description # Part Number Description 21.061300.00 Handle, Recoil, Soft 47.021000.00 Cover, Cylinder Head 1.5789.0608 Flange Bolt M6 x 8 45.020001.02 Breather Tube 46.061100.00.2 Cover, Recoil Starter, Black 47.020100.00 Bolt, Cylinder Head Cover 45.060005.00 Spring, Recoil Starter 2.08.039 Drain Bolt M12 x 1.5 x 15...
