Technical Information
SMART TC°
Connected room thermostat
Product evolutions, compatibilities and functionalities
JS
1. Compatibilities
The SMART TC° connected room thermostats are available in two versions:
-
package AD324 (without Gateway) : for compatible appliances (native R-BUS) which can be identified thanks to the
logo on the nameplate and the connection board.
package AD311 (with Gateway) for appliances who need a GTW 16 Gateway (ON/OFF or Opentherm connection).
-
APPLIANCES
Pack no.
• STRATEO
• HPI-M
• ALEZIO S V200 (MIV-4S / MIV-S)
•
• CFU C, CFU, CF
• NEOVO S
• NEOVO CONDENS with logo
Compatible
products
• NEOVO ECONOX with logo
• MODULENS O PRO
• NANEO S
• ELIDENS C140
• EVODENS - AMC
• EVODENS PRO
• INNOVENS PRO MCA160
• VM DIEMATIC EVOLUTION
QM
SMART TC
native R-BUS (without Gateway)
AD324
ALEZIO S, ALEZIO S COMPACT
No IT2686B-en
ON / OFF :
• ALEZIO EVOLUTION, ALEZIO COMPACT
• ALEZIO O HYBRID
• ALEZIO G HYBRID
• NEOVO CONDENS
• NEOVO ECONOX
• PREMYS
• ZENA EcoNox / MSN
• EUCALIA
• RONDALIS
OpenTherm or ON/OFF :
• MCX
• MPX
• NANEO EMC-M / PMC-X
• TWINEO
• VIVADENS MCR / MCR PLUS
1/8
28/09/2021
SMART TC
with GTW16 Gateway
AD311
28-09-2021-IT2686B-en
Advertisement
Related Manuals for DeDietrich SMART TC
Summary of Contents for DeDietrich SMART TC
- Page 1 No IT2686B-en 28/09/2021 1. Compatibilities The SMART TC° connected room thermostats are available in two versions: package AD324 (without Gateway) : for compatible appliances (native R-BUS) which can be identified thanks to the logo on the nameplate and the connection board.
-
Page 2: Operating Conditions
From factory, the SMART TC are delivered in version 1.56.7. If there is no WiFi network, where the SMART TC° is installed, perform the manual updating of the SMART TC° software (this is possible from SMART TC version 1.30), as described below : 1. - Page 3 (1) SMART TC is not compatible with a cascaded system. (2) SMART TC is compatible with a cascaded system, from SMART TC software version 1.64.6. (3) Use of the pump integrated in the boiler for the DHW circuit and the direct heating circuit. When connected to the SCB-10 PCB, the pump integrated in the boiler is not used for the circuit: so a load pump must also be connected to the SCB-10 PCB.
- Page 4 APPENDIX ALEZIO S… 1 circuit (+ DHW) APPLIANCE 2 circuits HPI-M 1 circuit (+ DHW) APPLIANCE STRATEO 1 circuit (+ DHW) APPLIANCE 28-09-2021-IT2686B-en...
- Page 5 2 circuits (+ DHW) APPLIANCE 1 circuit (+ DHW) Parameters to check in the Installer level : Parameters to check in the Installer level : menu button and select Installation setup : - Press - Press menu button and select Installation setup : - Sub-menu CUHG-08 >...
- Page 6 NANEO-S APPLIANCE 2 circuits 1 circuit (+ DHW) NEOVO – NEOVO S – CFU C, CFU, CF 2 circuits APPLIANCE 1 circuit (+ DHW) EVODENS PRO AMC 45-115 2 circuits APPLIANCE 1 circuit Parameters to check in the Installer level : Parameters to check in the Installer level : - Press menu button and select Installation setup :...
- Page 7 INNOVENS PRO MCA 160 2 circuits APPLIANCE 1 circuit Parameters to check in the Installer level : Parameters to check in the Installer level : menu button and select Installation setup : menu button and select Installation setup : - Press - Press - Sub-menu CUHG-06 >...
- Page 8 MODULENS O PRO APPLIANCE 1 circuit 2 circuits Parameters to check in the Installer level : Parameters to check in the Installer level : - Press menu button and select Installation setup : - Press menu button and select Installation setup : - Sub-menu CUOH-02 >...
