Paramount MX User Guide
Axis Parameters
Max Position Error
Periodic Error Correction Parameters
PEC Motor to Worm Gear
Ratio
PEC Cutoff Speed
PEC Harmonics
PEC Ratio 1
PEC Ratio 2
PEC Ratio 3
PEC Scale
PEC Teeth on Gear
PEC Worm Periods
System Parameters
Mount Type
Sync Version
82 | P a g e
Description
The maximum number of encoder tics from target before the Bisque TCS
aborts slewing or tracking and begins to emit position error beeps.
Specifies the gear ratio between the motor and the worm gear.
Set to two times the sidereal rate, this insures periodic error correction is
not applied to higher slew rates. Attempting to apply PEC at high slew
speed results in very labored sounding slews.
The number of harmonics to use when TheSkyX computes optimal PEC
curve.
The first gear ratio between the motor and worm.
The second gear ratio between the motor and worm.
The third gear ratio between the motor and worm.
The scale in arcseconds per pixel of the imaging system used to generate
the PEC tracking log file.
The number of teeth on the gear for determination of the time required
for one turn of the worm.
•
The Paramount ME's right ascension gear has 576 teeth.
•
The Paramount MX right ascension and declination gears have
375 teeth.
Number of worm revolutions to use in PEC curve determination.
Defines the physical telescope mounting type:
0 = German Equatorial Mount (GEM)
1 = Asymmetric equatorial fork mount
0 = Paramount ME, Paramount MX and Bisque TCS mounts.
1 = Paramount GT-1100S mount.
