Technical Specifications

KD-HDMIWPTX
Connectors:
One HDMI input connector
›
Two CAT5 output connectors labeled "Data" and "Control"
›
Power:
External AC-DC power supply included (5 Volt DC @ 1 Amp, 110-240 VAC, 50-60 Hz)
›
Mechanical:
No Fan Noise
›
Product Weight < 1Lb
›
Molded white ABS plastic face plate
›
Metal HDMI cable clip (1)
›
Resolutions Supported:
All resolution up to 1080p/60Hz
›
Dimensions:
HxWxL = 4.75 in x 2 in x 3.25 in
›

Important Product Warnings:

1. Connect HDMI, PCM and CAT5 cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access
spaces.
3. If installing the KD-HDMIWPTX into wall or mounting bracket into sheet-rock,
provide proper screw support with bolts or sheet-rock anchors.

Safety Instructions.

Please be sure to follow these instructions for safe
operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or
6.
other apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the
device has been damaged in any way including:
Damage to the power supply or power plug
➔
Exposure to rain or moisture
➔
