Key Digital
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital
is at the forefront of the video industry for Home
Theater Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers. We
provide total video system solutions because we know
and help drive the technology, the industry, the business,
and all the latest up-and-coming standards. But most
of all, we know exactly what you need for your unique
application - the right solution.
521 East 3rd Street, Mount Vernon, NY 10553
::
::
Phone
914.667.9700 Fax
914.668.8666
::
Web
www.keydigital.com
, led by digital video pioneer Mike Tsinberg,
®
Rev 0 – July 2007
KD-HDMIWPTX
HDMI CAT5 Wall Plate Cable Extender
TRANSMITTER with Coaxial Digital Audio Connection
Operating Manual
®
The KD-HDMIWPTX is an HDMI and PCM to CAT5 wall plate extender transmitter capable
of resolutions up to 1080P and can be used with or without the supplied power adapter.
This device is intended for use with Key Digital's KD-HDMIXWPRX, KD-CAT5XHDMI*
or KD-CAT5XCAT5.
Advertisement
Related Manuals for Key Digital KD-HDMIWPTX
Summary of Contents for Key Digital KD-HDMIWPTX
- Page 1 Operating Manual ® The KD-HDMIWPTX is an HDMI and PCM to CAT5 wall plate extender transmitter capable of resolutions up to 1080P and can be used with or without the supplied power adapter. This device is intended for use with Key Digital’s KD-HDMIXWPRX, KD-CAT5XHDMI* or KD-CAT5XCAT5.
-
Page 2: Table Of Contents
Instructions..........KD-HDMIWPTX....... -
Page 3: Installation Instructions
(receiver) to convert back to HDMI. Additionally, they can feed the KD-CAT5XCAT5, which is a CAT5 extender, to make longer CAT5 runs more reliable. * Note that when used with the KD-CAT5XHDMI, the PCM input port of the KD-HDMIWPTX is not available on the receiving KD-CAT5XHDMI... -
Page 4: Dvi Applications For The Kd-Hdmiwptx
Page DVI applications for the KD-HDMIWPTX The KD-HDMIWPTX can also be used to extend DVI video cable runs. For these applications, use DVI to HDMI (Key Digital model number KD-MFHDMI) adapters to feed the HDMI input of the KD-HDMIWPTX. -
Page 5: Technical Specifications
Connect HDMI, PCM and CAT5 cables before providing power to the unit. Test for proper operation before securing unit behind walls or in hard to access spaces. If installing the KD-HDMIWPTX into wall or mounting bracket into sheet-rock, provide proper screw support with bolts or sheet-rock anchors. Safety Instructions. -
Page 6: How To Contact Key Digital
Page How to Contact Key Digital ® Repairs and Warranty Service To obtain a Returned Materials Authorization (RMA) number, please contact: › Phone: 1-914-667-9700 ➔ E-mail: rma@keydigital.com ➔ Technical Support For technical questions about using our products, please contact us at either: ›...
