Summary of Contents for Bollng BU-CP-80D2
- Page 1 HD POE IP CAMERA Quick Start Guide Version: V2.0 Please read this manual carefully before using this product and keep it for future reference.
-
Page 2: Service Guarant Ee
Service Guarant ee If you have any other questions,pls contact the customer service em ail address at the first time.Itwould be better for us to improve our se rvice efficiency that if you can write down your E-mailaddress,the m odel of the product and the order number you bought. -
Page 3: Remot E View Ing
1. Remot e View ing View footage on your mobile devices with our app. You can either scan the provided QR code below or search Danale in the app store. It is all on the web: Software and complete instruction manual available on https://www.ebulwark.com/pages/download-center 2. -
Page 4: Specification
SPECIFICATION Camera BU-CP-80D2 Image Sensor 1/2.8" Sony CMOS Effective Pixels 8 megapixels Electronic Shutter AUTO, 1/25s ~ 1/100000s Minimum illuminance 0.01Lux@F1.2(AGC ON), 0Lux IR on Other AGC,Motion Detection,Privacy Mask,Flip,Rotate,RIO,OSD overlay Day/Night Auto/Color/(B/W)/Timing White Balance Auto/Manual BLC /HLC Support 2D/3D DNR... - Page 5 3. Dimensions...
-
Page 6: Installing The Camera
4. Installing the Camera 4.1.Dissembling the Trim Ring Rotate the trim ring counterclockwise to remove itfrom the camera. 4.2.Drill the Holes 1) Attach the supplied drill template to the position where you want to fix thecamera. 2) Drill the screw holes and the cable hole on the ceiling according to the drill template. -
Page 7: Cable Extension Options
5. Cable Extension Options Extend the cable run for your camera. Additional extension cable separately, as below: Max Cable Run Cable Type Distance CAT5e [or higher] Ethernet cable 300ft {92m} You can use a Rj45 coupler or switch {not included} to connect male ends of Ethernet cable together. - Page 8 Attention: This camera includes an Auto Mechanical IR Cut Fitter. When the camera changes between Day/Night viewing modes, an audible clicking noise may be heard from the camera. This clicking is nomal, and indicates that the camera filter is working. Once successfully connected the camera with POE router or POE NVR, the green signal light of the R 45 interface will...
-
Page 9: Default Ip, Username And Password
Attention: This Camera is only Compatible with select NVRs(5MP Resolution or Above input). If you would like to use it with NVR like 1080p, should modify the resolution of the camera accessing the web interface. Regulated 12V 1A Power supply is required 8. -
Page 10: Troubleshooting
WARNING/CAUTION u Use the camera only with compatible NVR which support resolution 5.0 megapixel or above. If your NVR only support 1080P, need to modify the resolution of cameras through web interface of the camera. Need help? Please mail: tech@ebulwark.com Read this guide carefully and keep it for future reference Use the camera...
