- Page 1 Air conditioner Installation manual AC∗∗∗NX∗S∗C • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference. DB68-07420A-01...
-
Page 2: Table Of Contents
This manual explains how to install an indoor unit with a split system with two SAMSUNG units. The use of other types of units with different control systems may damage the units and invalidate the warranty. - Page 3 Do not attempt to repair, move, alter or reinstall the unit. If performed by unauthorized personnel, these operations may cause electric shocks or fires. D o not place containers with liquids or other objects on the unit. Do not disassemble and alter the heater at your own discretion. All the materials used for the manufacture and packaging of the air conditioner are recyclable. ...
-
Page 4: Preparation For Outdoor Unit Installation
Preparation for outdoor unit installation The air conditioner uses R-410A refrigerant. (Unit : mm) A Type: AC052NX∗SEC B Type: AC071NX∗SEC C Type: AC090NX∗SEC 4 English... - Page 5 D Type: AC100NX∗SGC / AC120NX∗SGC / AC140NX∗SGC / AC160NXMSGC Moving the Outdoor Unit by Wire Rope Fasten the outdoor unit by two 8m or longer wire ropes as shown at Wire rope the figure. To prevent from damage or scratches, insert a piece of cloth between the outdoor unit and rope, then move the unit. Plate protection cloth ...
-
Page 6: Deciding On Where To Install The Outdoor Unit
Air Guide Duct (This product is not Stereo provided by Samsung) 200mm I f the outdoor unit is installed at a height, ensure that its base is firmly fixed in position. Make sure that the water dripping from the drain hose runs away correctly and safely. When you install the outdoor unit at wayside, you should install it above 2m height or make sure that the heat from the outdoor unit shouldn't be in direct contact with passersby. - Page 7 Check the condition of the product periodically. ˗ Check the installation site every 3 months and perform anti-corrosion treatment such as R-Pro supplied by SAMSUNG (Code : MOK-220SA) or commercial water repellent grease and wax, etc., based on the product condition.
- Page 8 Deciding on where to install the outdoor unit Space Requirements for Outdoor Unit When installing 1 outdoor unit (Unit : mm) ❋ ❋ When the air outlet is opposite the wall ❋ ❋ When the air outlet is towards the wall 2000 or more 300 or more 600 or more...
- Page 9 When installing more than 1 outdoor unit (Unit : mm) ❋ ❋ When the air outlet is towards the wall 300 or more 600 or more 600 or more 600 or more ❋ ❋ When 3 sides of the outdoor unit are blocked by the wall 300 or more 300 or more 600 or more...
-
Page 10: Outdoor Unit Installation
Outdoor unit installation The outdoor unit must be installed on a rigid and stable base to avoid any increase in the noise level and vibration, particularly if the outdoor unit is to be installed in a location exposed to strong winds or at a height, the unit must be fixed to an appropriate support(wall or ground). - Page 11 Outdoor Unit Support Designed to cut off Outdoor residual vibration Unit from outdoor unit Outdoor Unit to rack. (not sup- Anchor bolt Support plied with product) Base Surface OUTDOOR UNIT INSTALLED ON THE WALL BY RACK - Ensure the wall will be able to suspend the weight of rack and outdoor unit ; - Install the rack close to the column as much as possible ;...
-
Page 12: Connecting The Cable
Connecting the cable Two electronic cables must be connected to the outdoor unit. The connection cord between indoor unit and outdoor unit. The power cable between outdoor unit and auxiliary circuit breaker. Specially for Russian and European market, before installation, the supply authority should be consulted to determine the supply system impendance to ensure compliance. - Page 13 Specification for circuit breaker and power supply cord Power supply cord is not supplied with air conditioner. - Select the power supply cord in accordance with relevant local and national regulations. - Wire size must comply with the applicable local and national code. - Specifications for local wiring power supply cord and branch wiring are in compliance with local cord.
- Page 14 Connecting the cable Between Indoor and Outdoor Connection cable Specifications(Common in use) Indoor Power supply Home Server Communication Cable Power Supply Max/Min(V) Indoor Power cable 220-240V~, 50Hz ±10% 1.5mm² ,3wires 0.75-1.5mm²,2wires 0.75mm²,2wires ↑ Power supply cords of parts of appliances for outdoor use shall not be lighter than polychloroprene sheathed flexible cord.
- Page 15 Wiring Diagram of Power Cable When using ELCB for 1 phase Power Supply Electrical component box 1(L) 2(N) MCCB ELCB Cable tie Cable clamp Communication cable Main power cable Indoor Power Indoor Unit When using ELCB for 3 phase Power Supply Electrical component box MCCB 1(L) 2(N)
- Page 16 Connecting the cable Wiring Diagram of Connection Cord 3 phase 1 phase Indoor Unit Indoor Unit 2(N) 1(L) 1(L) 2(N) 1(L) 2(N) L1(R) L2(S) L3(T) 1(L) 2(N) Cable tie Cable tie Cable clamp Cable clamp Communication cable Main power cable Main power cable Communication cable Indoor Power...
- Page 17 Connecting the Power Terminal Connect the cables to the terminal board using the compressed ring terminal. Cover a solderless ring terminal and a connector part of the power cable and then connect it. Silver solder Nominal Nominal dimensions dimensions Standard Standard...
-
Page 18: Extending The Power Cable
Extending the power cable 1. Prepare the following tools. Connection sleeve Contraction tube Tools Crimping pliers Insulation tape (mm) (mm) Spec MH-14 20xØ6.5(HxOD) Width 19mm 70xØ8.0(LxOD) Shape 2. As shown in the figure, peel off the shields from the rubber and wire of the power cable. Power cable - Peel off 20 mm of cable shields from the pre-installed tube. CAUTION • For information about the power cable specifications for indoor (Unit: mm) - Page 19 5. Wrap it with the insulation tape twice or more and position your contraction tube in the middle of the insulation tape. Three or more layers of insulation are required. f Method 1 f Method 2 Insulation tape Insulation tape 40 mm 35 mm 6.
-
Page 20: Connecting The Refrigerant Pipe
Connecting the refrigerant pipe Refrigerant piping system Pipe length or height AC090NX∗SEC AC100NX∗SGC Refrigerant piping system table AC052NX∗SEC AC120NX∗SGC AC071NX∗SEC AC140NX∗SGC AC160NXMSGC Max. allowable length Actual pipe length L0 + H + L1 30 m or less 50 m or less Allowable height length Actual pipe length 15 m or less... -
Page 21: Connecting Up And Removing Air In The Circuit
Connecting up and removing air in the circuit CAUTION • W hen installing, make sure there is no leakage. When recovering the refrigerant,ground the compressor first before removing the connection pipe. If the refrigerant pipe is not properly connected and the compressor works with the service valve open, the pipe inhales the air and it makes the pressure inside of the refrigerant cycle abnormally high, It may cause explosion and injur y. -
Page 22: Cutting/Flaring The Pipes
Connecting up and removing air in the circuit CAUTION • C onnect the indoor and outdoor units using pipes with flared connections (not supplied). For the lines, use insulated, unwelded, degreased and deoxidized copper pipe, (Cu DHP type to ISO 1337 or UNI EN 12735-1), s uitable for operating pressures of at least 4200kPa and for a burst pressure of at least 20700kPa. -
Page 23: Performing Leak Tests
Performing leak tests LEAK TEST WITH NITROGEN (before opening valves) In order to detect basic refrigerant leaks, before recreating the vacuum and recirculating the R-410A, it’s responsable of installer to pressurize the whole system with nitrogen (using a cylinder with pressure reducer) at a A(Gas) pressure above 2 bar, less than 40 bar (gauge). -
Page 24: Insulation
Insulation Once you have checked that there are no leaks in the system, you can insulate the piping and hose. To avoid condensation problems, place an insulator around each refrigerant pipe. NOTE • W hen insulate the pipe, be sure to overlap the insulation. • Y ou have to use more than 120°C insulation(T13.0 or thicker Acrylonitrile Butadien Rubber) for the gas refrigerant pipe. -
Page 25: Using Stop Valve
Using stop valve To Open the Stop Valve 1. Open the cap and turn the stop valve counterclockwise by using a hexagonal wrench. 2. Turn it until the axis is stopped. NOTE • D o not apply excessive force to the stop valve and always use special instruments. Otherwise, the stopping box can be damaged and the back sheet can leaks. • I f the watertight sheet leaks, turn the axis back by half, tighten the stopping box, then check the leakage again. If there is no leakage any more, tighten the axis entirely. -
Page 26: Adding Refrigerant
Adding refrigerant The outdoor unit is loaded with sufficient refrigerant for the standard piping. Thus, refrigerant must be added if the piping is lengthened. This operation can only be performed by a qualified refrigeration specialist. For quantity of adding refrigerant, refer to page 26. 1. -
Page 27: Pump Down Procedure
Pump down Procedure Pump down will be carried out when an evaporator is replaced or when the unit is relocated in another area. WARNING • After installing the product, be sure to perform leak tests on the piping connections. After pumping down refrigerant to inspect or relocate the outdoor unit, be sure to stop the compressor and then remove the connected pipes. -
Page 28: Checking Correct Grounding
Checking correct grounding If the power distribution circuit does not have a grounding or the grounding does not comply with specifications, an grounding electrode must be installed. The corresponding accessories are not supplied with the air conditioner. 1. Select an grounding electrode that complies with the specifications given in the illustration. -
Page 29: Testing Operations
Testing operations 1) Check the power supply between the outdoor unit and the auxiliary circuit breaker. f 1 phase power supply : L1, L2 f 3 phase power supply: L1, L2,L3,N 2) Check the indoor unit. 1) Check that you have connected the power and communication cables correctly. (If the power cable and communication cables one mixed up or connected incorrectly, the PCB will be damaged.) 2) Check the thermistor sensor, drain pump/hose, and display are connected correctly. - Page 30 Testing operations 5) View Mode : When the K4 switch is pressed, you can see information about our system state as below. Short Display contents SEG1 SEG2 SEG3 SEG4 Unit push Order frequency Current frequency The number of current indoor Hundred's Ten's digit Unit digit units digit The sensor for outdoor air °C intake Discharge sensor °C Eva-In sensor Ten's digit Unit digit °C...
-
Page 31: Troubleshooting
Troubleshooting Display Explanation Remark Compressor down due to outdoor freezing detection Compressor down due to outdoor overload protection Compressor down due to protection control of the discharge temperature sensor 3Phase power source miss wiring error Error about protection control Outdoor of operation temperature range in of the outdoor unit heating(Over36℃) Control due to the condenser temperature sensor when...
