MAKSIWA CBC/2.MR Instruction Manual

Edgebander with extension table
Hide thumbs Also See for CBC/2.MR:
Table of Contents

Advertisement

Quick Links

Download this manual
CBC/2.MR
Edgebander with Extension Table
INSTRUCTION MANUAL
ATTENTION: READ THIS MANUAL BEFORE USING THE MACHINE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CBC/2.MR and is the answer not in the manual?

Questions and answers

Related Manuals for MAKSIWA CBC/2.MR

Summary of Contents for MAKSIWA CBC/2.MR

  • Page 1 CBC/2.MR Edgebander with Extension Table INSTRUCTION MANUAL ATTENTION: READ THIS MANUAL BEFORE USING THE MACHINE.
  • Page 2 Congratulations, you just purchased the CBC/2.MR Maksiwa Edgebander, which was developed with the Maksiwa’s highest standards of technology and quality. Your CBC/2.MR Maksiwa Edgebander allows you to have the highest productivity in woodworking. It should be noted that to use this machine with maximum efficiency, you should read and understand the instructions in this manual.
  • Page 3 Furthermore, the manual must be kept to hand and within the vicinity of the machine so that it is accessible to operators when using, maintaining or repairing the machine. Maksiwa International Inc. 4100 N Powerline Rd, Suite D3 Pompa-...

  • Page 4: Table Of Contents

    Contents 1. General..................................05 1.1 Symbol legend ..............................05 1.2 Information on the operating instructions ....................05 1.3 Liability and warranty.............................05 1.4 Copyright................................06 1.5 Spare parts..............................06 1.5 Disposal .................................06 2. Safety Regulations...............................07 2.1 Workspace..............................07 2.2 Personal Safety.............................07 2.3 Machine Safety..............................04 3. Description................................10 3.1 Specifications ..............................10 4.

  • Page 5: General

    1 General 1 General 1.1 Symbol legend Important technical safety instructions in this manual are marked with symbols. These instructions for work safety must be followed. In all these particular cases, special attention must be paid in order to avoid accidents, injury to persons or material damage.

  • Page 6: Copyright

    1 General manual must be read carefully before commencing any work on or with this machine. The manufacturer shall not be liable for damage and/or faults resulting from the disregard of instructions in the manual. The text and images do not necessarily represent the delivery contents. The images and graphics are not depicted on a 1:1 scale.

  • Page 7: Safety Regulations

    2 Safety Regulations 2 Safety Regulations Read all instructions in this manual. Failure to follow all instructions listed below may result in personal injury and equipment damage. WARNING: When using electrical equipment, always follow the safety precautions to reduce risk of fire, electric shock and personal injury. The manufacturer declares that they are not liable for damages to person(s) or object(s) which may be caused by failure to comply with the safety regulations.

  • Page 8: Machine Safety

    2 Description 2.3 Machine Safety • The motor of this machine can emit sparks, and can ignite flammable gases. • Extension cables. Make sure your extension cord is in good condition. When using an extension, be sure of their ability to transmit the electrical current used by your product. An undersized cord will cause drop in voltage resulting in loss of power and overheating.
  • Page 9 CAUTION: Do not connect the unit to the power outlet until all instructions have been read and understood. Always tighten the adjustment tabs before using the machine. Think: “I can prevent accidents”. Do not operate the machine unless the guards are in their proper places. Always use protective goggles.

  • Page 10: Description

    3 Description 3 Description The CBC/2.MR Maksiwa Edgebander is loaded with an extension table and 2 interchangeable glue pots, Maksiwa’s CBC/2.MR Cabinet Edgebander works with the most commonly used edge banding materials such as PVC, ABS, Paper and Wood. 3.1 Specifications •...

  • Page 11: Installation

    • All equipment MAKSIWA are tested at the factory. If this machine does not work, check the electrical supply. • Check the compatibility of your outlet and plug the machine. Do not do patches and adaptations.
  • Page 12 4 Installation 4.1 - Mount the 2nd Glue Pot using the the 4 Allen Screws, as shown in the following photo: 5. Open the extension tables according to your need, making sure to fit the latches into the side holes as shown in the picture: Leveling Feet 6.
  • Page 13 4 Installation 8. Remove the screws from the Glue Cover before connecting the equipment to a power source, enabling the operation of the machine. 9. Use locking bracket to prevent the Glue Pot to move, as shown below. 10. The machine is already equipped with cable and plug. ATTENTION: Use 1-Phase - 110V Power Supply...

  • Page 14: Adjustments

    Do not allow the glue pot to run low, as this can cause failures application of the glue. NOTE: The quality of glue is critical. MAKSIWA recommends glues that work in the range of 130°C to 180°C. Above that, high temperature glues can damage by over work machine and electrical components.
  • Page 15 2. EDGE TAPE The CBC/2.MR Cabinet Edgebander With Dual Pot is designed to work with PVC, ABS, paper and wood edge banding that are not pre-glued on straight pieces. Use tapes that are at least 4 mm wider than the wooden panel.

  • Page 16: Operation

    • Transmission chain damaged. • Dirt Glue axis or glue pot. The dust coming from saw machines can lock the axis. Keep your CBC/2.MR as distantly as possible of saw machines. • Any other condition that could adversely affect the safe •...
  • Page 17 NOTE: The temperature controller of the CBC/2.MR Maksiwa Edgebander is programmable for a maximum temperature of 220°C, Maksiwa does not recommend working with glues of high temperatures, as they overwork electrical components.

  • Page 18: First Tests

    5 Operation 5.2 First Tests Only proceed at this point if you have read the entire manual and are confident in operating the equipment. If necessary, contact the manufacturer. With all the adjustments made, the machine adjusted and set to the correct working temperature, you can start the first work tests.
  • Page 19 5 Operation shown in the following figure: If you want to decrease the thickness of glue, slightly turn glue knob (B) counterclockwise. If you want to increase the thickness of glue, turn glue knob (B) clockwise. Note that small changes (about 1/4 of a turn) already cause a considerable change in glue thickness.

  • Page 20: Maintenance

    If the glue applicator of your CBC/2.MR Maksiwa Edgebander is out of square, you can easily adjust it by following these steps: •...

  • Page 21: Exchange Glue Pot

    6 Maintenance the glue melts, making cleaning the glue roller. As soon as the glue is melted, turn off the machine. • Place a square on the table guides, push against the glue roller. If any point of square is not touching the glue roller, it is necessary to make the following adjustment: •...
  • Page 22 6 Maintenance • After removing the Glue Pot, place the lock (B) as shown below: • Move the other glue pot into place, coupling it to the equipment, as shown below: • Attach the glue pot assembly again to the machine body and tighten the knob (C) as shown below...

  • Page 23: Maintanamce Schedule

    Check for wear or damage to buttons and electrical cable. • Check the wear of the knife. Electric panel Never perform maintenance to the electrical panel with the machine on or plugged in. Look for Maksiwa authorized technical assistance when you need to handle the electrical panel.

  • Page 24: Explode View

    7 Exploded View 7 Exploded View...
  • Page 25 7 Exploded View Item Parts Name STRUCTURE ASSEMBLY CONTROL PANEL SET RIGTH MOBILE TABLE ASSEMBLY FRONT TABLE SET LEFT MOBILE TABLE ASSEMBLY OUTPUT BASE ARTICULATOR SUPPORT SET EDGE RIBBON CUTTING SET EDGE TAPE TRAY ENTRY GUIDE FLAT HEAD SOCKET HEAD SCREW 3/8X3/4 MOBILE TABLE LOCK HEX NUT 1/2”...
  • Page 26 7 Exploded View Observation: The rigth and left tables have the same assembly.
  • Page 27 7 Exploded View 7 Exploded View Item Parts Name FLAT WASHER M12 ZINC PLATED FLAT WASHER M8 ZINC PLATED HEX CAP SCREW M6 X 16 ZINC PLATED FLAT WASHER M6 ZINC PLATED LEFT MOBILE TABLE GLUE APPLICATION SYSTEM MOTOR SUPPORT LEFT BACK PROTECTION SWITCH REVERSIBLE CONTACT 10A EDGE TAPE GUIDE...
  • Page 28 Form. Des. 1 : 1 Aprov. Esc. Conjunto: MAKSIWA IND. E COM. DE MÁQUINAS LTDA. CBC.MR/2.MR RUA NELSON ARGENTA, 436 - COLOMBO - PR - BRASIL FONE/FAX: [55] (41) 3621-3218 / 9912-2241 www.maksiwa.com.br - maksiwa@maksiwa. c om.br Parte: Ref. Orig.
  • Page 29 Form. Des. 1 : 1 Aprov. Esc. Conjunto: MAKSIWA IND. E COM. DE MÁQUINAS LTDA. CBC.MR/2.MR RUA NELSON ARGENTA, 436 - COLOMBO - PR - BRASIL FONE/FAX: [55] (41) 3621-3218 / 9912-2241 www.maksiwa.com.br - maksiwa@maksiwa. c om.br Parte: Ref. Orig.
  • Page 30 7 Exploded View N° REF 4131 Item Tratamento Qtde A - 2 Form. Fernandes Des. 1 : 1 Aprov. Esc. Conjunto: CBC.E/MR/2.MR Parte: GLUE APPLICATION SYSTEM...
  • Page 31 7 Exploded View Item Parts Name HEX CAP SCREW M6X10 ZINC PLATED FLAT WASHER M6 ZINC PLATED HEX SOCKET HEAD CAP SCREW M6X25 ZINC PLATED MACHINE SCREW PHILLIPS M6X12 ZINC PLATED HEX NUT M6 ZINC PLATED BOX GLUE GLUE SYSTEM FIXER PRESSURE BASE GLUE SYSTEM BEARING BOTTOM HOUSING LOWER RING...
  • Page 32 7 Exploded View XXXXXX XX/XX/16 ALEXAN LIBERADO PARA PRODUÇÃO XX/0X/16 JEAN NATUREZA DAS ALTERAÇÕES Nº. CAP DATA ITEM...
  • Page 33 7 Exploded View Item Parts Name HEX CAP SCREW M6X10 ZINC PLATED FLAT WASHER M6 ZINC PLATED RESISTANCE CARTRIDGE PRESSURE BASE SCRAPER GLUE SHAFT FIXED SCRAPER ADJESTMENT GLUE SYSTEM GUIDE GLUE BUILDING PLATE GLUE CLOSING PLATE ADJUSTEMENT WASHER SCRAPER ADJUSTMENT HANDLE BUTTON M5X75 COMPRESSION SPRING LENGHT 55MM ZINC PLATED FLAT WASHER 1/4”...
  • Page 34 Form. Des. 1 : 1 Aprov. Esc. Conjunto: MAKSIWA IND. E COM. DE MÁQUINAS LTDA. CBC/2.MR RUA NELSON ARGENTA, 436 - COLOMBO - PR - BRASIL FONE/FAX: [55] (41) 3621-3218 / 9912-2241 www.maksiwa.com.br - maksiwa@maksiwa. c om.br Parte: Ref. Orig.
  • Page 35 A - 2 Form. Fernandes Des. 1 : 1 Aprov. Esc. Item Parts Name Conjunto: MAKSIWA IND. E CBC/2.MR RUA NELSON ARG FONE/FAX: [5 www.maksiwa.co BLIND REVIT 3,2X10MM Parte: Ref. Orig. ELECTRICAL PANEL SET ELECTRICAL PANLE SET LARGER CABLE DUCTS...
  • Page 36 A - 2 Fernandes 26/08/13 Form. Des. 1 : 1 Aprov. Esc. Conjunto: MAKSIWA IND. E COM. DE MÁQ CBC.E/.MR/.2MR RUA NELSON ARGENTA, 436 - COLOMBO FONE/FAX: [55] (41) 3621-3218 / 99 www.maksiwa.com.br - maksiwa@m Parte: Ref. Orig. Des.Nr. EDGE TAPE GUIDE...
  • Page 37 7 Exploded View Item Qtde Fernandes Des. Aprov. Conjunto: CBC. Item Parts Name Parte: HEX CAP SCREW M6X16 ZINC PLATED EDGE RIBB HEX CAP SCREW M6X10 ZINC PLATED HEX NUT M6ZINC PLATED HEX SOCKET HEAD CAP SCREW M8X20 ZINC PLATED SOCKET SET SCREW CUP POINT M8X10 TRACTION SPRING ZINC PLATED LENGHT 29MM FLAT HEAD SOCKET CAP SCREW M6X10 ZINC PLATED...
  • Page 38 Form. Des. 1 : 1 Aprov. Esc. Conjunto: MAKSIWA IND. E COM. DE MÁQUINAS LTDA. CBC_2MR RUA NELSON ARGENTA, 436 - COLOMBO - PR - BRASIL FONE/FAX: [55] (41) 3621-3218 / 9912-2241 www.maksiwa.com.br - maksiwa@maksiwa. c om.br Parte: Ref. Orig.
  • Page 39 7 Exploded View Item Qtde FERNANDES 23/08/13 Des. Aprov. Conjunto: CBC/2.MR Parte: MOTOR SUPP XXXXXX XX/XX/16 ALEXANDRE MARCOS LIBERADO PARA PRODUÇÃO XX/0X/16 MARCOS JEAN ITEM NATUREZA DAS ALTERAÇÕES Nº. CAP DATA NOME APROV.
  • Page 40 7 Exploded View Item Parts Name HEX CAP SCREW M6X16 ZINC PLATED HEZ NUT M6 ZINC PLATED SOCKET SET SCREW CUP POINT M8X10 FLAT WASHER 1/4” ZINC PLATED GEAR SPACER HEZ SOCKET HEAD CAP SCREW M6X12 ZINC PLATED MOTOR SUPPORT SET MOTO REDUCER COMPACT 24V DC PROLONGER AXIS BEARING HOUSING OF DRIVING ROLL...

  • Page 41: Wiring Diagram

    8 Wiring Diagram 8 Wiring Diagram...
  • Page 42 8 Wiring Diagram Item Name list- CBC.2/MR Item Descrption Application MAIN ON/OFF SWITCH Main Power CIRCUIT BREAKER Over Current Protection MAIN CONTACTOR 24V AC General Power PRIMARY GLUE POT CONTACTOR 24V AC Primary Glue Pot Heating SECONDARY GLUE POT CONTACTOR 24V AC Secondary Glue Pot Heating MOTOR CONTACTOR 24V AC Primary and Secondary Motor Power...
  • Page 43 8 Wiring Diagram...
  • Page 44 8 Wiring Diagram...

  • Page 45: Warranty Terms

    4. In case an exchange of machine is needed, please return the defective part or machine to MAKSIWA. 5. All workplace adaptations for the equipment are under the responsibility of the machine owner.
  • Page 46 Imported by: Maksiwa International Inc. 4100 N Powerline Rd, Suite D3 Pompano Beach, Florida ZIP Code: 33073 Telephone: +1 (754) 205-6717 | Call us free: +1 (844) 319-6594 E-mail: tech@maksiwa.com www.maksiwa.com...
