Summary of Contents for MAKSIWA LDF
- Page 1 Combination Belt and Disc Sander 6” x 9” INSTRUCTION MANUAL Attention: Read this manual before using the machine.
- Page 2 9” which was developed with the Maksiwa’s highest standards of technology and quality. Your Sander allows you to have the highest productivity in woodworking. Besides a great finish, the LDF ensures that your work pieces come always precise. It should be noted that to use this machine with maximum efficiency, you should read and understand the instructions in this manual.
-
Page 3: Table Of Contents
Index 1. Safey Regulations................................04 1.1 Safety Instructions for All Tools........................04 1.2 Additional Safety Rules for Sanders.........................05 1.3 Electrical Connection............................06 2. Description..................................07 2.1.Specifications...............................07 2.2 Components................................08 3. Installation..................................09 3.1 Unpacking...................................09 3.2 Connection Test.................................13 4. Settings....................................14 4.1 Table Angle Adjustment............................14 4.2 Sandpaper Angle Adjustment..........................14 4.3 Adjusting the Angle Guide..........................15 5. -
Page 4: Safey Regulations
1 Safety Regulations Important information you should know: Only work with suitable sandpaper. Inappropriate sandpaper does not result in a good finish and overload the engine. ALWAYS USE PROPER PROTECTIVE EQUIPMENT WHEN OPERATING THIS EQUIPMENT. ATTENTION: When using power tools, always follow safety precautions to reduce the risk of fire, electric shock and personal injury, including the following. -
Page 5: Additional Safety Rules For Sanders
• Only use recommended accessories. Refer to the instruction manual to check the recommended accessories. Improper use of accessories can cause a risk of accident. • Never step on the tool. A serious accident can occur if the tool is tilted or if the tool is touched accidentally. -
Page 6: Electrical Connection
1.3 Electrical Connection The MAKSIWA LDF Sander has a three-phase motor with connection option 220 and 380V. To avoid risks of motor burning, check the electrical voltage of your before starting the machine. If necessary, changing the electrical connection of the motor with the assistance of a specialized technician. -
Page 7: Description
2 Description Place the machine on a smooth, flat surface. Check the figures and pay attention to the description of the parts to familiarize yourself with its different components. The next section will deal with the necessary adjustments for a good functioning of the machine, and will refer to the termination that goes along with the illustrations. -
Page 8: Components
2.2 Components Adjustment Feet (x 4) 2. Cabinet Door 3. Cabinet 4. Output for dust Collector (ø 2 ½ ’’) 5. Table Angle Square 6. Half Moon Disc or Tape Sanding Table 8. Disc Sanding (9 ‘or 230mm) 9. Stop 10. -
Page 9: Installation
3.1 Unpacking Due to modern mass production techniques, the MAKSIWA LDF sander is unlikely to have defect or a part is missing. If you find something wrong, don’t use the tool until parts are replaced, or failure is corrected. - Page 10 5. Turn the base over and install the 4 rubber feet (a) in every corner. Place the base in the correct position on smooth and level surface and check that the enclosure It is stable without oscillating. If necessary, turn again, and adjust the feet so that the cabinet does not swing when in the correct position.
- Page 11 9. To install the support table in front of the sandpaper Disc, follow these procedures: insert the Support (a) in the corresponding hole and tighten the 2 Allen screws (b) with a 5mm wrench. Slide the table (c) by inserting it into the support bar (a) until the table is at most 2mm from the sandpaper.
- Page 12 11. Place the Angle guide (A) in the groove (B) of the table, as the figure below. 12. Install the dust collector outlet for the tape sandpaper as follows: position the Collector Box (A) of to fit with the Phillips screw holes (B) and (C). If necessary, this equipment comes with a adapter (D) from 2 ½...
-
Page 13: Connection Test
To test, follow these steps: Read the entire instruction manual first, to that you are familiar with all the controls and functions of the MAKSIWA LDF sander. 2. Connect the machine to the power source. 3. Turn the switch to the ON position. The sander must run smoothly, with little or no vibration. -
Page 14: Settings
4 Settings This machine can perform many types of operations that are outside the scope of this manual. Many of these operations can be dangerous or lethal if done incorrectly. The instructions in this section are written with the understanding that the operator has the knowledge and skills necessary to operate this machine. -
Page 15: Adjusting The Angle Guide
the ribbon at the desired angle with the aid of the scale (B). For hold in the chosen position, retighten the nut hexagonal (A). See the following figure. If you wish reposition the tape file perfectly in the direction horizontal, lower the tape assembly completely until touch the stop that is located under the assembly part mentioned. -
Page 16: Operations
5 Operations There are a series of operational guidelines for the MAKSIWA LDF Combination Belt and Disc Sander that must be followed. These guidelines aim to increase the life of your equipment and offer safe and risk-free work for the operator. This product is designed to perform operations on straight, curved, radial and chamfered parts in wood, plastics, metals and ceramics. -
Page 17: Disk Sanding Operations
6.1 Table and Base Cleaning the LDF sander is relatively easy with a vacuum cleaner to remove wood chips in excess and sawdust, and dust with a dry cloth. If there is any resin, use a resin remover and a clean cloth to remove it. -
Page 18: Lubrication
6.2 Lubrication Since all bearings are shielded and have permanent lubrication, just leave them this way until they need to be replaced. Do not lubricate. For the other items on this machine, an application occasional electric machine oil is all that is required. Before applying the lubricant, clean the sawdust. Its objective is to achieve adequate lubrication. - Page 19 3. Remove the Stop (A) from the figure below, removing the Allen screw (B) and remove the Collector Box (C) removing the 3 Phillips-type screws (D). 4. Rotate the lever (A) clockwise in the figure below, to reduce the tension of the sandpaper and remove the sandpaper tape as shown.
-
Page 20: Adjusting Sanding Tape Axis
6.5 Adjusting Sanding Tape Axis Your MAKSIWA LDF sander is designed with the axis centralization mechanism. The tape sander must run centered and properly drawn between the two axes. If any adjustments are necessary, follow the following steps: Turn on the machine. -
Page 21: Engine Belt Replacement
6.6 Engine Belt Replacement Your MAKSIWA LDF sander is equipped with a type V belt that can stretch or lacerate after extensive use of the equipment and may need to be re-tensioned or replaced with a new one. To replace and tension the belt follow the following instructions: Turn off the machine and remove the plug from the outlet to avoid accidents. -
Page 22: Grinding Quality
Repair or replace the extension if necessary. 8 Terms of Warranty MAKSIWA assures the owner that their equipment, identified by the Serial number issued on the Warranty Terms. The equipment under warranty, for two (2) years, is as followed: The warranty period begins on the date of the Warranty Terms below. - Page 23 9. MAKSIWA is not responsible for lost productivity, direct or indirect damages caused to the owner of the equipment or to third parties, or any other expense, including lost profits.
- Page 24 Imported by: Maksiwa International Inc. 4100 N Powerline Rd, Suite D3 Pompano Beach, Florida ZIP Code: 33073 Telephone: +1 (754) 205-6717 | Call us free: +1 (844) 319-6594 E-mail: customer.service@maksiwa.com www.maksiwa.com...
