Contents
1 Preparing for installation ·········································································· 1-1
Safety recommendations ································································································································ 1-1
Examining the installation site ························································································································· 1-1
Temperature/humidity ····························································································································· 1-2
Cleanliness ·············································································································································· 1-2
Corrosive gas limit ··································································································································· 1-3
EMI ·························································································································································· 1-3
Laser safety ············································································································································· 1-4
Installation tools ·············································································································································· 1-4
2 Installing the switch ·················································································· 2-1
Installing the switch in a 19-inch rack·············································································································· 2-3
Installation methods ································································································································ 2-3
Installation procedure at a glance ··········································································································· 2-4
Installation accessories ··························································································································· 2-4
Rack-mounting the switch by using front mounting brackets ·································································· 2-6
Rack-mounting the switch by using front and rear mounting brackets ···················································· 2-8
Rack-mounting the switch by using front mounting brackets and extension brackets and rails ··········· 2-12
Mounting the switch on a workbench ············································································································ 2-14
Grounding the switch ···································································································································· 2-15
Grounding the switch with a grounding strip ························································································· 2-15
Grounding the switch with a grounding conductor buried in the earth ground ······································ 2-17
Verifying the connection after grounding the switch·············································································· 2-17
Installing and removing a fan tray ················································································································· 2-18
Installing a fan tray ································································································································ 2-18
Removing a fan tray ······························································································································ 2-19
Installing and removing a power supply ········································································································ 2-20
Installing a PSR250-12A, PSR250-12A1, or PSR450-12 power supply ··············································· 2-21
Installing a PSR180-12A-F or PSR180-12A-B power supply ································································ 2-22
Removing a PSR250-12A or PSR250-12A1 power supply··································································· 2-23
Removing a PSR450-12D power supply ······························································································· 2-24
Removing a PSR180-12A-F or PSR180-12A-B power supply ······························································ 2-25
Connecting the power cord ··························································································································· 2-26
Connecting the power cord for a PSR250-12A or PSR250-12A1 power supply··································· 2-26
Connecting the power cord for a PSR180-12A-F or PSR180-12A-B power supply ······························ 2-27
Connecting the DC power cord for a PSR450-12D power supply ························································ 2-28
Installing and removing an expansion card ··································································································· 2-29
Installing an expansion card·················································································································· 2-29
Removing an expansion card ················································································································ 2-31
Verifying the installation ································································································································ 2-31
3 Accessing the switch for the first time ······················································ 3-1
Connecting the switch to a configuration terminal··························································································· 3-1
Connecting a DB9-to-RJ45 console cable ······························································································ 3-2
Connecting a USB-to-RJ45 console cable ······························································································ 3-3
Connecting a micro USB console cable ·································································································· 3-5
Setting terminal parameters ···························································································································· 3-7
Starting the switch ··········································································································································· 3-7
Pre-start checklist ···································································································································· 3-7
Powering on the switch ··························································································································· 3-8
4 Setting up an IRF fabric ··········································································· 4-1
IRF fabric setup flowchart ······························································································································· 4-1
Planning IRF fabric setup ································································································································ 4-2
Planning IRF fabric size and the installation site ····················································································· 4-2
Identifying the master switch and planning IRF member IDs ·································································· 4-2
Planning IRF topology and connections·································································································· 4-3
i
Advertisement
Table of Contents
Related Manuals for H3C S6520X-30QC-EI
Summary of Contents for H3C S6520X-30QC-EI
-
Page 1: Table Of Contents
Contents 1 Preparing for installation ·········································································· 1-1 Safety recommendations ································································································································ 1-1 Examining the installation site ························································································································· 1-1 Temperature/humidity ····························································································································· 1-2 Cleanliness ·············································································································································· 1-2 Corrosive gas limit ··································································································································· 1-3 EMI ·························································································································································· 1-3 Laser safety ············································································································································· 1-4 Installation tools ·············································································································································· 1-4 2 Installing the switch ·················································································· 2-1 Installing the switch in a 19-inch rack··············································································································... - Page 2 Identifying physical IRF ports on the member switches ·········································································· 4-4 Planning the cabling scheme ·················································································································· 4-5 Configuring basic IRF settings ························································································································ 4-8 Connecting the physical IRF ports ·················································································································· 4-8 Verifying the IRF fabric setup ·························································································································· 4-8 5 Maintenance and troubleshooting ···························································· 5-1 Power supply failure ········································································································································...
-
Page 3: Preparing For Installation
Preparing for installation This document is applicable to the following Ethernet switches: • S6520X-30QC-EI • S6520X-54QC-EI • S6520X-30HC-EI • S6520X-54HC-EI • S6520X-30HF-EI • S6520X-54HF-EI • S6520X-30QC-HI • S6520X-54QC-HI • S6520X-30HC-HI • S6520X-54HC-HI • S6520X-30HF-HI • S6520X-54HF-HI Safety recommendations To avoid any equipment damage or bodily injury caused by improper use, read the following safety recommendations before installation. -
Page 4: Temperature/Humidity
• Identify the airflow designs of neighboring devices, and prevent hot air flowing out of the neighboring device from entering the device. • The rack is sturdy enough to support the switch and its accessories. • The rack or workbench is reliably grounded. To ensure correct operation and long service life of your switch, install it in an environment that meets the requirements described in the following subsections. -
Page 5: Corrosive Gas Limit
Corrosive gas limit Corrosive gases can accelerate corrosion and aging of metal components. Make sure the corrosive gases in the equipment room do not exceed the concentration limits as shown in Table1-2. Table1-2 Corrosive gas concentration limits in the equipment room Average concentration (mg/m Maximum concentration (mg/m 0.01... -
Page 6: Laser Safety
• If AC power is used, use a single-phase three-wire power receptacle with protection earth (PE) to filter interference from the power grid. • Keep the switch far away from radio transmitting stations, radar stations, and high-frequency devices. • Use electromagnetic shielding, for example, shielded interface cables, when necessary. •... -
Page 7: Installing The Switch
Installing the switch CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence. - Page 8 Figure2-1 Hardware installation flow Start Install the switch Ground the switch Install fan trays Install power supplies Connect the power cords Verify the installation Turn on the circuit Troubleshoot the switch breakers Turn off the circuit Operating correctly? breakers Install expansion cards? Install expansion cards Operating correctly?
-
Page 9: Installing The Switch In A 19-Inch Rack
Installing the switch in a 19-inch rack Installation methods Table2-2 Installation methods Installation Applicable Installation Requirements and guidelines method switch models procedure • Select an installation position for the front mounting brackets as required: near the power supply side or port S6520X-30HF-EI side. -
Page 10: Installation Procedure At A Glance
Table2-3 Installation accessories Rear mounting Front mounting 1U extension rail kit brackets and shoulder Switch model brackets (as shown in (as shown in screws (as shown in Figure2-5) Figure2-7) Figure2-6) S6520X-30QC-EI S6520X-54QC-EI S6520X-30QC-HI S6520X-54QC-HI Provided Provided Optional S6520X-30HC-EI S6520X-54HC-EI S6520X-30HC-HI S6520X-54HC-HI S6520X-30HF-EI... - Page 11 Figure2-5 Front mounting bracket (1) Screw hole for attaching the bracket to the switch (2) Screw hole for attaching the bracket to the rack (3) M4 screw Figure2-6 Rear mounting bracket and shoulder screw (1) Screw hole for attaching the bracket to the rack (2) Shoulder screw Figure2-7 1U extension rail kit (1) Extension bracket...
-
Page 12: Rack-Mounting The Switch By Using Front Mounting Brackets
Rack-mounting the switch by using front mounting brackets Attaching the front mounting brackets to the switch The switch has one mounting position near the network ports and the other mounting position near the power supplies for the front mounting brackets. Select one position as needed. To attach the front mounting brackets to the chassis: Place the wide flange of the mounting bracket against the chassis side panel. - Page 13 Figure2-9 Attaching the front mounting brackets to the power supply-side mounting position (S6520X-30HF-EI switch as an example) Mounting the switch in the rack This task requires two people. To mount the switch in the rack: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Verify that the front mounting brackets have been securely attached to the switch chassis.
-
Page 14: Rack-Mounting The Switch By Using Front And Rear Mounting Brackets
Figure2-11 Mounting the switch in the rack (power supply-side mounting position for the front mounting brackets, S6520X-30HF-EI switch as an example) Rack-mounting the switch by using front and rear mounting brackets Attaching the front mounting brackets and shoulder screws to the switch The switch provides two installation positions on its side for the front mounting brackets. - Page 15 Figure2-12 Attaching the front mounting brackets and shoulder screws to the chassis (S6520X-30QC-EI switch as an example) Attaching the rear mounting brackets to the rack Determine the switch installation position in the rack. Install cage nuts (user-supplied) in the rear rack posts. Make sure the corresponding cage nuts on the left and right rear rack posts are at the same height.
- Page 16 Figure2-14 Attaching the rear mounting brackets to the rack with the wide flange outside the rack Mounting the switch in the rack Wear an ESD wrist strap. Make sure the strap makes good skin contact and is reliably grounded. Make sure the front mounting brackets and shoulder screws are securely attached to the two sides of the switch.
- Page 17 Figure2-15 Mounting the switch in the rack (with the wide flange of the rear mounting brackets inside the rack, S6520X-30QC-EI switch as an example) Figure2-16 Mounting the switch in the rack (with the wide flange of the rear mounting brackets outside the rack, S6520X-30QC-EI switch as an example)
-
Page 18: Rack-Mounting The Switch By Using Front Mounting Brackets And Extension Brackets And Rails
Rack-mounting the switch by using front mounting brackets and extension brackets and rails Attaching the extension brackets to the chassis Place the wide flange of the mounting bracket against the chassis side panel. Align the mounting bracket installation holes with the appropriate screw holes in the chassis. Use the provided M4 screws to attach the mounting bracket to the chassis. - Page 19 Figure2-18 Installing the extension rails Mounting the switch in the rack This task requires two people. To mount the switch in the rack: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Verify that the mounting brackets and extension brackets have been securely attached to the switch chassis.
-
Page 20: Mounting The Switch On A Workbench
Figure2-19 Mounting the switch in the rack (port-side mounting position for the front mounting brackets, S6520X-54HF-EI switch as an example) Mounting the switch on a workbench IMPORTANT: • Reserve a minimum clearance of 10 cm (3.9 in) around the chassis for heat dissipation. •... -
Page 21: Grounding The Switch
• Correctly connecting the grounding cable is crucial to lightning protection and ESD and EMI protection. You must connect the grounding cable correctly and reliably for the switch. • For information about lightning protection for the switch, see H3C Network Devices Lightning Protection Guide. - Page 22 Use the grounding screw to attach the ring terminal of the grounding cable to the grounding screw hole. Fasten the screw. IMPORTANT: Orient the grounding cable as shown in Figure2-22 so that you can easily install or remove the removable components. Figure2-22 Connecting the grounding cable to the chassis (1) Grounding screw (2) Ring terminal...
-
Page 23: Grounding The Switch With A Grounding Conductor Buried In The Earth Ground
Grounding the switch with a grounding conductor buried in the earth ground If the installation site does not have grounding strips, but earth ground is available, hammer a 2.5 m (8.20 ft) or longer angle iron or steel tube into the earth ground to act as a grounding conductor. Make sure a minimum of 0.7 m (2.30 ft) is left between the top of the grounding conductor and the ground. -
Page 24: Installing And Removing A Fan Tray
For information about resistance measurement, see H3C Network Devices Lightning Protection Guide. Installing and removing a fan tray CAUTION: •... -
Page 25: Removing A Fan Tray
Figure2-25 Installing a fan tray IMPORTANT: • In versions earlier than Release 6326 (not inclusive) or Release 65xx versions earlier than Release 6525 (not inclusive), you must use the command to set the fan prefer-direction preferred airflow direction of the switch to be consistent with that of the fan trays the first time you log in to the switch. -
Page 26: Installing And Removing A Power Supply
Figure2-26 Removing a fan tray Installing and removing a power supply The switch provides two power supply slots. It comes with power supply slot PWR1 empty and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for the switch as required. - Page 27 Installing a PSR250-12A, PSR250-12A1, or PSR450-12 power supply The installation procedure is the same for the PSR250-12A, PSR250-12A1, and PSR450-12D power supplies. The following procedure installs a PSR250-12A1 power supply. To install a PSR250-12A1 power supply: Wear an ESD wrist strap. Make sure the strap makes good skin contact and is reliably grounded.
-
Page 28: Installing A Psr180-12A-F Or Psr180-12A-B Power Supply
Figure2-30 Installing a power supply Installing a PSR180-12A-F or PSR180-12A-B power supply The installation procedure is the same for the PSR180-12A-F and PSR180-12A-B power supplies. The following procedure installs a PSR180-12A-B power supply. To install a PSR180-12A-B power supply: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. Remove the filler panel from the target power supply slot as follows: a. -
Page 29: Removing A Psr250-12A Or Psr250-12A1 Power Supply
Install the filler panel over the empty power supply slot to prevent dust and ensure good ventilation if you install only one power supply. Figure2-32 Installing a power supply Removing a PSR250-12A or PSR250-12A1 power supply The removal procedure is the same for the PSR250-12A and PSR250-12A1 power supplies. The following procedure removes a PSR250-12A1 power supply. -
Page 30: Removing A Psr450-12D Power Supply
Figure2-33 Removing a power supply Removing a PSR450-12D power supply Wear an ESD wrist strap. Make sure the strap makes good skin contact and is reliably grounded. Remove the power cord from the power supply. As shown in Table3-2, use a flathead screwdriver to loosen the two screws on the power cord connector and then pull the connector out. -
Page 31: Removing A Psr180-12A-F Or Psr180-12A-B Power Supply
Figure2-34 Removing the power cord from a PSR450-12D power supply (1) Use a flathead screwdriver to loosen the two screws on the power cord connector (2) Pull the power cord connector out Removing a PSR180-12A-F or PSR180-12A-B power supply The removal procedure is the same for the PSR180-12A-F and PSR180-12A-B power supplies. The following procedure removes a PSR180-12A-B power supply. -
Page 32: Connecting The Power Cord
Figure2-35 Removing a power supply Connecting the power cord Connecting the power cord for a PSR250-12A or PSR250-12A1 power supply The power cord connection procedure is the same for the PSR250-12A and PSR250-12A1 power supplies. The following procedure connects the power cord for a PSR250-12A1 power supply. To connect the power cord for a PSR250-12A1 power supply: Wear an ESD wrist strap. -
Page 33: Connecting The Power Cord For A Psr180-12A-F Or Psr180-12A-B Power Supply
Figure2-36 Connecting the power cord for a PSR250-12A1 power supply Connecting the power cord for a PSR180-12A-F or PSR180-12A-B power supply The power cord connection procedure is similar for the PSR180-12A-F and PSR180-12A-B power supplies. The following procedure connects the power cord for a PSR180-12A-B power supply. To connect the power cord for a PSR180-12A-B power supply: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded. -
Page 34: Connecting The Dc Power Cord For A Psr450-12D Power Supply
Figure2-37 Connecting a power cord (1) Figure2-38 Connecting a power cord (2) Connecting the DC power cord for a PSR450-12D power supply Correctly orient the DC power cord connector and insert it into the DC power input receptacle on the power supply, as shown by callout 1 in Figure2-39. If you orient the DC power cord connector upside down, you cannot insert it into the DC power input receptacle. -
Page 35: Installing And Removing An Expansion Card
• You can install or remove an expansion card when the switch is operating correctly. Do not install or remove an expansion card while the switch is starting up. The S6520X-30QC-EI, S6520X-54QC-EI, S6520X-30HC-EI, S6520X-54HC-EI, S6520X-30QC-HI, S6520X-54QC-HI, S6520X-30HC-HI, and S6520X-54HC-HI switches each provide two expansion slots on the rear panel. - Page 36 Figure2-40 Removing the filler panel from the target expansion slot Unpack the expansion card. (Optional.) If the expansion card has an ejector lever, perform the following steps to install it: a. Fully open the ejector lever, as shown by callout 1 in Figure2-41. b.
-
Page 37: Removing An Expansion Card
(Optional.) If the expansion card does not have an ejector lever, perform the following steps to install it: a. Gently push the expansion card into the slot along the guide rails until the expansion card has good contact with the chassis. See callout 1 in Figure2-42. b. - Page 38 NOTE: For information about lightning protection for the switch, see H3C Lightning Protection Guide. 2-32...
-
Page 39: Accessing The Switch For The First Time
As a best practice, use a serial console cable for connection. The switch is not provided with a serial console cable or a micro USB console cable. Purchase a serial console cable from H3C or prepare a micro USB console cable yourself. Table3-1 Connection methods and console cables... -
Page 40: Connecting A Db9-To-Rj45 Console Cable
Configuration Connection Applicable Console cable Switch-side terminal-side method switch models type connector connector S6520X-54HC-HI Connecting a DB9-to-RJ45 console cable CAUTION: Follow these guidelines when you connect a DB9-to-RJ45 console cable: • Identify the mark on the serial console port and make sure you are connecting to the correct port. •... -
Page 41: Connecting A Usb-To-Rj45 Console Cable
Click the following link, or copy it to the address bar on your browser and download the USB-to-RJ45 console driver. http://www.h3c.com/en/home/USB_to_RJ45_Console/ View the TXT file Read me in the Windows folder to check whether the Windows system of the configuration terminal supports the driver. - Page 42 Figure3-4 Driver installation wizard Click Finish after the drive installation is completed. Figure3-5 Finishing the driver installation...
-
Page 43: Connecting A Micro Usb Console Cable
Click the following link, or copy it to the address bar on the browser to log in to download and install the USB console driver on the configuration terminal. http://www.h3c.com/en/home/USB_Console/ Select a driver program according to the operating system you use: XR21V1410_XR21B1411_Windows_Ver1840_x86_Installer.EXE—32-bit operating... - Page 44 Figure3-7 Device Driver Installation Wizard Click Continue Anyway if the following dialog box appears. Figure3-8 Software Installation Click Finish.
-
Page 45: Setting Terminal Parameters
Figure3-9 Completing the device driver installation wizard Setting terminal parameters To configure and manage the switch through the console port, you must run a terminal emulator program, such as TeraTermPro, on your configuration terminal. You can use the emulator program to connect a network device, a Telnet site, or an SSH site. -
Page 46: Powering On The Switch
After the startup process is completed, you can access the CLI to configure the switch. For more information about the configuration commands, see H3C S6520X-EI & S6520X-HI Switch Series Configuration Guides and H3C S6520X-EI & S6520X-HI Switch Series Command... -
Page 47: Setting Up An Irf Fabric
Setting up an IRF fabric You can use H3C IRF technology to connect and virtualize S6520X-EI or S6520X-HI switches into a large virtual switch called an "IRF fabric" for flattened network topology, and high availability, scalability, and manageability. An S6520X-EI or S6520X-HI switch can set up an IRF fabric only with switches from the same switch series. -
Page 48: Planning Irf Fabric Setup
CLI of the master switch. IRF member switches automatically elect a master. You can affect the election result by assigning a high member priority to the intended master switch. For more information about master election, see H3C S6520X-EI & S6520X-HI Switch Series Virtual Technologies Configuration Guide. -
Page 49: Planning Irf Topology And Connections
Planning IRF topology and connections You can create an IRF fabric in daisy chain topology or more reliable ring topology. In ring topology, the failure of one IRF link does not cause the IRF fabric to split as in daisy chain topology. Instead, the IRF fabric changes to a daisy chain topology without interrupting network services. -
Page 50: Identifying Physical Irf Ports On The Member Switches
24 × SFP+ ports on the front panel • 2 × QSFP+ ports on the front panel • The following ports provided on the expansion cards: • S6520X-30QC-EI 5G/2.5G/1000BASE-T Physical ports on interface autosensing Ethernet ports modules and the front panel can be S6520X-30QC-HI bound to the same IRF logical 10G/5G/2.5G/1000BASE-T... -
Page 51: Planning The Cabling Scheme
Chassis Candidate physical IRF ports Use restrictions • 24 × SFP+ ports on the front panel • 2 × QSFP28 ports on the front panel • The following ports provided on the expansion cards: S6520X-30HC-EI 5G/2.5G/1000BASE-T S6520X-30HC-HI autosensing Ethernet ports 10G/5G/2.5G/1000BASE-T ... - Page 52 For a long-distance IRF connection, use SFP+/QSFP+/SFP28/QSFP28 transceiver modules and optical fibers. The following subsections describe several H3C recommended IRF connection schemes by using SFP+ cables and SFP+ transceiver modules and fibers. All these schemes use a ring topology. IMPORTANT: In these schemes, all physical IRF ports are located on the same side.
- Page 53 Figure4-5 IRF fabric topology...
-
Page 54: Configuring Basic Irf Settings
• Execute the command to verify the basic IRF settings. display irf configuration For more information about configuring basic IRF settings, see H3C S6520X-EI & S6520X-HI Switch Series Virtual Technologies Configuration Guide. Connecting the physical IRF ports twisted pair/SFP+/QSFP+/SFP28/QSFP28... - Page 55 To avoid IP address collision and network problems, configure a minimum of one multi-active detection (MAD) mechanism to detect the presence of multiple identical IRF fabrics and handle collisions. For more information about MAD detection, see H3C S6520X-EI & S6520X-HI Switch Series Virtual Technologies Configuration Guide.
-
Page 56: Maintenance And Troubleshooting
Maintenance and troubleshooting Power supply failure The S6520X-30QC-EI, S6520X-54QC-EI, S6520X-30HC-EI, S6520X-54HC-EI, S6520X-30QC-HI, S6520X-54QC-HI, S6520X-30HC-HI, and S6520X-54HC-HI switches support PSR250-12A, PSR250-12A1, and PSR450-12D power supplies. These switches each provide two power supply status LEDs PWR1 and PWR2, and the PSR250-12A, PSR250-12A1, and PSR450-12D power supplies each provide a status LED. -
Page 57: Configuration Terminal Display Issues
Verify that the power supply is supplying power to the switch correctly. Verify that the console cable is correctly connected. Verify that the console cable does not have any issues and the terminal settings are correct. If the issue persists, contact H3C Support. Garbled display Symptom The display on the configuration terminal is garbled.
