4B RG1V56A Operation Manual

Rotary level indicator

Advertisement

Quick Links

RG1
ROTARY LEVEL INDICATOR
INSTALLATION INSTRUCTIONS
OPERATION MANUAL
Part No's RG1V56A, RG1V4A
www.go4b.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG1V56A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for 4B RG1V56A

  • Page 1 ROTARY LEVEL INDICATOR INSTALLATION INSTRUCTIONS OPERATION MANUAL Part No’s RG1V56A, RG1V4A www.go4b.com...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS CUSTOMER SAFETY RESPONSIBILITIES Page 4 - 5 PRODUCT OVERVIEW Page 6 SPECIFICATIONS Page 6 DIMENSIONS Page 6 INSTALLATION Page 7 STANDARD WIRING DIAGRAM Page 8 TESTING AND COMMISSIONING Page 10 TROUBLESHOOTING GUIDE Page 10 PARTS AND ACCESSORIES Page 11 PRODUCT WARRANTY Page 15...
  • Page 4: Customer Safety Responsibilities

    The proper installation and maintenance of all our products is the responsibility of the user unless you have asked 4B to perform these tasks. B. All installation and wiring must be in accordance with Local and National Electrical Codes and other standards applicable to your industry.
  • Page 5 3. SELECT A QUALIFIED AND COMPETENT INSTALLER Correct installation of the product is important for safety and performance. If you have not asked 4B to perform the installation of the unit on your behalf, it is critical for the safety of your operation and those who may perform work on your operation that you select a qualified and competent electrical installer to undertake the installation.
  • Page 6: Product Overview

    When the level of the material reaches normal levels again, the motor returns to its initial position and restarts. SPECIFICATIONS Power Supply - RG1V56A: 110/240 VAC, RG1V4A: 24 VDC Operating Temp. - -20° C up to +70°C Output - Change over relay 10 A at 250 VAC.
  • Page 7: Installation

    If this check reveals anything irregular, the level gauge must be reported back to 4B. 4B level gauges can be installed in any position. With the shaft in a horizontal or vertical position, the level gauge must be mounted with cable glands on the right hand side (Figure 1).
  • Page 8: Standard Wiring Diagram

    Figure 3 - Earthing detail. NOTE 4B Rotary level indicators need no routine maintenance. Possible extraordinary maintenance is restricted to replacing parts that are deteriorated by use. The gauge must not be lubricated, the shaft, the only moving part is mounted on ball bearings with permanent lubrication.
  • Page 9 Figure 4 - 110/240 VAC Wiring detail. Figure 5 - 24 VDC Wiring detail. PAGE 9...
  • Page 10: Testing And Commissioning

    TESTING AND COMMISSIONING 1. Follow the safety rules below when installing this product. 2. Check that the unit is correctly installed (see standard wiring diagram). WARNING All the appropriate safety precautions must be taken when electrically operated equipment is used, in order to reduce the risk of fire outbreaks, electric shock and injuries to persons.
  • Page 11: Parts And Accessories

    PARTS & ACCESSORIES PADDLES Part number Description Picture Single vane screw in NYLON RG1SP1 ø120 x 100 mm. 3 Vanes NYLON screw ø120 x RG1SP3 65 mm. Single vane screw in Stainless RG1SP1-SS steel ø120 x 100 mm. 4 Vanes Stainless steel screw RG1SP4-SS ø100 x 60 mm.
  • Page 12 PARTS & ACCESSORIES EXTENSIONS Part number Description Picture Stainless steel extension without RG1EXT-0500-SS rod guard 500 mm (0.5 m) long. Stainless steel extension without RG1EXT-1000-SS rod guard 1000 mm (1 m) long. Stainless steel extension without RG1EXT-1500-SS rod guard 1500 mm (1.5 m) long.
  • Page 13 PARTS & ACCESSORIES EXTENSIONS Part number Description Picture RG1EXT- Stainless steel flexible extension 2000-SS-W MOUNTING BRAKETS / FLANGES Standard aluminium flange. External diameter 203 mm, RG1MP1 holes centers ø178 mm, 6 equidistant ø7,5 holes. RG1- Iron sleeve 2”1/2 BSPP / Gas TUBE-2.5”...
  • Page 14 PARTS & ACCESSORIES PADDLES SELECTION TABLE Part number Description Selection criteria SUGGESTED MATERIAL DENSITY[kg/dm3]: between 0.6 and 0.9 Single vane screw in NYLON RG1SP1 MIN. INSTALLATION HOLE DIMENSION[mm]: ø120 x 100 mm. For medium weight materials. SUGGESTED MATERIAL DENSITY[kg/dm3]: between 0.3 and 0.5 3 Vanes NYLON screw ø120 x RG1SP3 MIN.
  • Page 15: Product Warranty

    AS 4B TO THE ORIGINAL PURCHASER AGAINST DEFECTS IN WORKMANSHIP OR MATERIALS UNDER NORMAL USE FOR ONE (1) YEAR AFTER DATE OF PURCHASE FROM 4B. ANY PRODUCT DETERMINED BY 4B AT ITS SOLE DISCRETION TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP AND RETURNED TO A 4B BRANCH...
