CONTROL BOXES AND LIFT STRUCTURE TO UNIT
Item Part No.
1 Page 42
2 39345
3 38382
4 38383
5 Page 40
6 39427
7 Page 38
8 Page 70
9 60249
10 60248
11 60527
12 63111
38108 ORG
Qty Description
1 Assembly, lift structure
4 Washer, .312 flat
4 Washer, M8-312 split lock
4 Screw, M8-1.25 x 20 hex, G8.8
1 Assembly, connection box
4 Screw, .312-18 x .75 hex
1 Assembly, control box
1 Assembly, skid
6 Nut, .750-10 hex, G8
6 Washer, .750 split lock
12 Washer, .750 flat - 1.50/.125
6 Screw, .750-10 x 2.250 flg hex, G8
MGG200/200G Parts Manual
