Page 1: Parts List
™ ReliaVac PARTS LIST Nilfi sk-Advance MODEL 56648069 11/04 revised 7/05 FORM NO. 56042456... - Page 3 04-11 TABLE OF CONTENTS 05-3 ReliaVac ™ DESCRIPTION Base Assembly ... 2-3 Handle Assembly ... 4-5 Wiring Diagram ... 5 Use the 8 digit numbers from the “Ref. No.” columns in this parts list. Specify the model and serial number of the machine. Use the space below to record the model and serial number for future reference.
-
Page 4: Base Assembly
BASE ASSEMBLY ReliaVac Rear R.H. Vac Motor mounting screw should be .625" long FORM NO. 56042456 ™ 18 18 Remaining 3 Vac Motor mounting screws should be .75" long 04-11 05-1... - Page 5 Guard, Furn--Clear Blue, 31.00l 56630395 Pedal, Foot--Uprt, White 56648420 Pulley and Fan Kit 56630561 Carbon Brush, Mtr 56630620 Spring, Ext .275d 1.50l .024wd 56052964 Magnet, Permanent 56630325 Upright Vacuum Accessory Kit * = Not Shown ** = Not Included (optional) FORM NO. 56042456...
- Page 6 HANDLE ASSEMBLY ReliaVac FORM NO. 56042456 ™ 04-11 05-3...
-
Page 7: Handle Assembly
04-11 HANDLE ASSEMBLY 05-7 ReliaVac ™ Item Ref. No. Qty Description 56648417 Power Cord Assembly (see #11 on page 3) 56648421 Hook Assembly 56648424 Handle Assembly 56648423 Bag Assembly 56648429 Grip, Handle—Dark Gray 56035451 Asm, Bag Zip Gray TYT HD Com 56637120 A/R Disposable Paper Bag (pkg of 10) 56039515...
