Memphis SE3200.1D Quick Start Manual

C R O S S O V E R A N D C O N T R O L S
Low Level Output: (MONO Amps) Use this output connection to feed the audio signal to additional amplifiers.
Gain: The gain control is NOT a volume control. The gain control adjusts the amount of signal required to drive the
amplifier to full output. With the gain at full clockwise rotation, less signal voltage is required to drive the amp to full
output. With the gain at full counter clockwise rotation, more signal voltage is required to drive the amp to full output.
For optimal performance, set the gain control to minimum
Low Pass Filter (LPF): The Lowpass crossover/filter is designed to remove high frequency information from a speaker.
This is generally used to prevent mid bass speakers or subwoofers from trying to reproduce mid and high frequency
information that they are not designed to reproduce. The crossover frequency is adjustable from 50Hz to 250Hz and
uses a 12dB per octave slope. To engage the LPF slide the switch to the position marked LPF. Frequency selection is
made by rotating the dial: clockwise raises the frequency and counter clockwise lowers the frequency. Most
subwoofers should be set between 80Hz and 100Hz depending on how low the mid-bass or midrange drivers are capable
of playing.
Full Range: Sliding the selector switch to this position turns off all crossovers and allows a full range signal to pass.
The flat position should be selected when using outboard electronic crossovers.
8 0 0 . 4 8 9 . 2 3 0 0
w w w . m e m p h i s a u d i o . c o m
1 2 2 G a y o s o A v e .
M e m p h i s , T N , U S A
@ M E M P H I S A U D I O
@ M E M P H I S C A R A U D I O U S A
SE3200.1D
D E S I G N E D
A N D D E V E L O P E D
I N T H E U N I T E D S T AT E S
A U D I O S I N C E 1 9 6 5
MODEL: SE3200.1D
MONO AMPLIFIER
