2. SPECIFICATIONS

2.1 General Specifications
Display
Status Indicators
LED display span
Indicating Accuracy
Sampling Time
Memory
Meter Enclosure
Front Panel
Power Supply
Power Consumption
Insulation Resistance
Noise Rejection
Operating Temperature / Humidity
Storage Temperature
Dimensions (Cutout)
2.2 Input Specifications
Thermocouple input
(Programmable)
RTD input
Current input
Voltage input
Thermocouple Ranges
Type K
Type J
Type B
Type T
Type E
Type R
Type S
Type N
RTD PT100 input ranges
Linear input range
Temperature Stability
Repeatability
48VTR English 9/00
Dual 7-segment 4-digit LED Displays: Red (PV),
Green (SV)
For Control output, Alarm output, Over range, Auto-
Tune, and Open Input
-1999 to 9999 counts max (Programmable)
+0.2% Full Scale +1 digit
1 reading per 0.25 seconds
Nonvolatile type
ABS Plastic
Lexan (Drip and Dust Proof; IEC IP55, NEMA
Equivalent)
85 to 260VAC 50/60 Hz (automatic switching)
6 Watts
>50MΩ
Common Mode: 110 db typical; Normal Mode: 50 db
typical
14 to 122
-4 to 140
1.77 x 1.77" ±0.02" (45.0 x 45.0mm ±0.5mm)
Types: J, K, T, E, B, R, S, N; Cold Junction Compensation
Thermocouple Break Protection: Upscale and Downscale
Lead Wire Effect: 0.015%/ohm (Input impedance: 10 megohm)
Pt 100 ohm (DIN, JIS); RTD Break Protection: Upscale and
Downscale
Lead Wire Effect: 0.015/ohm
(automatically compensates if one lead wire is < 5 Ω)
4-20mA DC (2.7Ω input impedance)
1-5V DC
o
-58 to 2498 F (-50 to 1370
o
-58 to 1830 F (-50 to 1000
o
32 to 3272 F (0 to 1800
o
-454 to 752 F (-270 to 400
o
-58 to 1382 F (-50 to 750
o
32 to 3182 F (0 to 1750
o
32 to 3182 F (0 to 1750
o
-58 to 2372 F (-50 to 1300
o
-392 to 932 F (-200 to 500
-1999 to 9999 display span (for 4-20mA, 1-5V, or special DC
input).
o
5uV/ C typical
o
0.83 C (Thermocouple); 0.2
Ver. 2.7 1
o o
F (-10 to 50 C); 90% RH max.
o o
F (-20 to 60 C)
o
C)
o
C)
o
C)
o
C)
o
C)
o
C)
o
C)
o
C)
o
C); (DIN or JIS)
o
C (RTD); 1 digit (Linear)
