ROOMS TO GO 672MS Assembly Instruction

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts, which
may have come loose inside carton during shipment. Identify and count all parts and compare with the parts list below.
COMPONENT
No.
Top
A
Shelf plate
B
Bottom plate
C
Back plate
D
Step 1
ASSEMBLY INSTRUCTION
6 672MS - CORNER TV
#
ASSEMBLY INSTRUCTION :
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast and easy assembly
4. Hand fasten all bolts before tightened with Allen wrench
Q'ty No.
1
E
1
F
1
G
1 H
COMPONENT
Beside ( L)
Beside ( R)
Legs
Legs
D
F
HARDWARE LIST
Q'ty No.
1 Allen key k4
1
Bolt M6x25
2
1
3 Bolt M6x15
Spring washers
4
3
5 Flat washers
2
Screws M3.5x15
6
A
Q'ty
1
12
13
13
13
3
Page 1/3
